Arlotto Pano360 User Manual

360/180º panoramic camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
360/180º Panoramic Camera User Manual
Version 1.0
February
2013
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pano360 and is the answer not in the manual?

Questions and answers

Related Manuals for Arlotto Pano360

Summary of Contents for Arlotto Pano360

  • Page 1 360/180º Panoramic Camera User Manual Version 1.0 February 2013...

  • Page 2: Table Of Contents

    Table of Contents Product Overview …………………………………………………………………………………… 3 Features and Benefits ……………………………………………………………………………… 3 Getting Started ………………………………………………………………………………………. 4 Introduction to Pano360, 360º Surveillance …………………………………………………...…. 5 Introduction to Pano360, 180º Surveillance …………………………………………………….. 11 Camera Configuration and Panoramic Image Alignment ……………………………………….20 Panoramic Image Alignment ……………………………………………………………………….22 DVR Setup and Configuration ………………………………………………………………….…..27...

  • Page 3: Product Overview

    Product Overview Pano360 is a wide-angle surveillance system to record panoramic cameras. The Pano360 includes all of the necessary components for recording, viewing and perform digital PTZ. Features and Benefits  Each camera’s video runs on its maximum resolution. All in High Quality Jpeg/Motion Jpeg compression.

  • Page 4: Getting Started

    Remote Pack: Pack the camera configuration to WIN32 portable EXE file for remote viewing, without install Pano360 system program. Setup Root password: Maintain the root password. Pano360 has only 1 administrator account accept. NVR Backup: Backup DVR file into remote storage.

  • Page 5: Introduction To Pano360, 360º Surveillance

    Introduction to Pano360, 360-Degree Surveillance Source Image: This image shows 360 Degree Source Image format. 360-Degree Camera Layout...
  • Page 6 Pano360 Provides Various Showing Method, Press Mouse Right Button on Screen Select Showing Method you want. Quad View with Source Image: One Source Image and 3 PTZ Controllable Sub-Windows Object Video Screen Layout.
  • Page 7 Quad View with 4 PTZ Controllable Sub-Window: Four PTZ Controllable Sub-Window, with Top-Left Sub-Window can be defining has AUTO-PAN property. Object Video Screen Layout.
  • Page 8 Cylindrical 360: Two 180 X 90 Sub-Window, The viewing area cover entire scene. Object Video Screen Layout.
  • Page 9 Global + Two 3D PTZ: A 360 X 90 Entire Scene and Two PTZ controllable Sub-Window, with Top-Left Sub-Window can be defining has AUTO-PAN property. Object Video Screen Layout.
  • Page 10 2D Global + One 3D PTZ: A 360 X 90 Entire Scene and Two PTZ controllable Sub-Window. The Upper Sub-Window can be defining has AUTO-PAN property. Object Video Screen Layout.

  • Page 11: Introduction To Pano360, 180º Surveillance

    Introduction to Pano360 180 Degree Surveillance 180-Degree Surface-Mount Source Image(Surface Mount) 180-Degree Surface-Mount Camera Layout...
  • Page 12 180-Degree Surface-Mount: (Strip View, 2 PTZ Sub-Windows) Object Video Screen Layout.
  • Page 13 180-Degree Surface-Mount: (Single Undistorted Object Image) Object Video Screen Layout.
  • Page 14 180-Degree Gallery: (Surface-Mount, Single Cylindrical Output) Object Video Screen Layout. This Picture shows 180 Degree Cylindrical Object Image Generated by Pano360.

  • Page 15: Camera Layout

    180-Degree Source Image: (Wall-Mount) Camera Layout.
  • Page 16 180-Degree Wall-Mount: (Strip View, 2 PTZ Sub-Windows) Object Video Screen Layout.
  • Page 17 180-Degree Wall-Mount: (Quad View, 3 PTZ + 1 Cylindrical Entire Viewing) Object Video Screen Layout.
  • Page 18 180-Degree Wall-Mount: (Quad View, 4 PTZ Sub-Windows) Object Video Screen Layout.
  • Page 19 180-Degree Gallery: (Wall-Mount, Single Cylindrical Output) Object Video Screen Layout.

  • Page 20: Camera Configuration And Panoramic Image Alignment

    Camera Configuration and Panoramic Image Alignment Before you using Pano360 You must add IP Camera into this system and Install your Video/Camera Servers with specified IP Address. Configure You Network Camera with specified IP Add Arlotto camera Press “New” Button To insert new Camera / Video server into Pano360...
  • Page 21 Step 3: Select Arlotto camera, then press “OK” button. Where : (1) Camera’s IP Address. (2) Camera Web Streaming Port. (Default is 80) (3) Camera login account and password, by default user: admin / password: 123456 (4) Select 360º panoramic fish eye viewing type.

  • Page 22: Panoramic Image Alignment

    Panoramic Image Alignment Start Pano360 system program, Then press "Start Monitoring" button. Press the mouse right button on screen below, Click the right mouse then execute the "Mark Alignment Panoramic image" menu item.
  • Page 23 Align the circle to fit the Panorama Images.
  • Page 24 When the marked circle fit the panorama image, press right mouse button, Select OK Menu and exit the mark image program.
  • Page 25 Where, Fish eye Lens Field of View Angle. Convert Oval style (Some camera output oval Image, not rounded region) into rounded Image.
  • Page 26 Two Parameters Align the Panoramic image (1) Lens Degree of View: Input the Fisheye Lens Field of View Angle (in degree). (2) Ellipse/Circle Adjustment: Adjust parameter could convert Ellipse Fisheye Image into Circular Image, and can be exact match the Alignment White Circle.

  • Page 27: Dvr Setup And Configuration

    DVR Setup and Configuration Press “DVR Setup” Entering DVR configuration dialog:...
  • Page 28 Turn On/Off NAS Recording. And give subdirectory for NAS recording. Input NAS start up command, this command will let Windows system connect to NAS device. And “Auto connect NAS On System Startup” flag is on, Pano360 will run this script while Pano360 is start up.
  • Page 29 P.S.: Disable title annotate text from camera site, you should turn of the title annotates text from your camera site, before you using motion trigger recording. Annotate text will cause motion alert all the times.

  • Page 30: Dvr Playback

    DVR Playback...

  • Page 31: Export Dvr File And Snapshot To Portable Executable

    DVR Exporting: Launch “DVR Playback” Then Open DVR Management Dialog, Select “File -> Export DVR/Image” Menu. You may Export DVR File to Single EXE file (All Win32 Platform Portable Executable File), The Executable file is Auto-decompress Auto-Expand Auto-Run without install Pano360 System Program and Any other Pluggings or filters.

  • Page 32: Snapshot File Export

    Snapshot File Export on Main UI Screen, Select “File -> Export Snapshot Image”. Open Snapshot Viewer...

  • Page 33: Remote Pack And Web Publish

    Remote Pack and Web Publish Share Your Monitoring to Internet. Pano360 Provides two methods, Share your Monitoring Environment to Internet. Remote Pack...
  • Page 34 Remote Pack generated EXE file is a Compressed EXE file in ZIP format and an Auto Decompress and Auto Expand, Auto Run engine also includes in this EXE file. Remote site could run this program in all WIN32 Platform, without install Pano360 System Program. Web Publish: Descriptions for Web Publish: 1.
  • Page 35 Ordinal Fisheye Image (With DOV >= 180 Degree) (DOV: Lens Degree of View). With lens Projected Area should completed inside CCD/CMOS Sensor. See Figure Below: 360 Degree Camera Mounting: Pano360 is camera cell-mount system, but you may also put camera direction upside-down (Camera put on the ground toward to Sky).

  • Page 36: Using Dual Monitor In Single Pc

    Using Dual Monitor in Single PC Getting dual monitors to work correctly seems to be a hit or miss affair. In many cases, it's just a matter adding a second video card and monitor and rebooting the computer. In other cases, you need to do some cyber gymnastics to get things working correctly.

  • Page 37: System Requirement

    Channel”, You can run dual monitor in single PC now. System Requirement: Hardware Requirement Pano360 do not asked for special requirement in software and hardware. CPU: Pentium IV class and higher. RAM: 256 MB for WIN2K, 512 MB and above for WINXP, 1G for Vista.

This manual is also suitable for:

Pano180
