Arlotto AR6220 Quick Installation Manual

PACKAGING CONTAINS
1 2
Camera
Bracket
SETUP
1
Locate the place where the camera would be installed and
place the drill template to make the fixation drills. Also mark
the place where to drill the hole to pass the cables through
the wall.
2
Place the camera in the floor or a safe location and pass the
cables through the camera bracket.
3 Connect the bracket and tighten the screws until the retainers are
firmly seated.
4 Connect the cables and pass the cables through the wall hole.
AR6220/AR6230 Quick Installation Guide
3 4
Anchors/screws
5
Power adaptor CD
5
Tight correctly the bolts.
6 Use the drill template to make the drill location marks in the wall
and fix the bracket to the wall.
6 Connect the Ethernet cable and DC or POE power input to the
camera and proceed to find your network camera in your web
browser, if you would like to add audio, alarm trigger connection
or others please use included connections.
Once camera is connected to the network please open Internet
7
Explorer and go to "tools", then select "internet options", the click
on "security" tag and click again on "custom level". A new window
would be open. Scroll down the list and tick on prompt at
"download signed ActiveX controls" and "Download unsigned
ActiveX controls".
6
Drill template
