Page 2: Table Of Contents
CONTENTS Precautions..............................1 ..........................1 Lithium Battery Cell Warnings Use Caution s ............................1 Installation ..............................2-3 Uninstallation ............................2 Wiring Connections ..........................3 Uninstall the Main Unit ........................... 3 Control Panel Button Locations ........................4 Operation ..............................4-6 Power / SRC .................................................... -
Page 3: Precautions
PRECAUTIONS Lithium Battery Cell Warnings Cell leakage may cause damage to the remote control. Do not throw cells into as this may cause an explosion. Keep battery cells out of reach of children. Use cautions Be sure to lower the volume before switching off the unit or the ignition ksy. -
Page 4: Installation
INSTALLATION Installation Procedures First complete the electrical connections and then check for correctness. Installation Opening 2.05 inch 7.20 inch MOUNTING SLEEVE This unit can be installed in any dashboard Having an opening as shown above .The Dashboard should be 4.75mm-5.56mm thick in order to be able to support the unit. -
Page 5: Wiring Connections
INSTALLATION(CONT.) - Only use speakers with 4 ohms impedance. - Do not attach the control panel to the chassis before wiring is complete. - The maximum current of the auto antenna is 200mA. Wiring Connections WIRING DIAGRAM Fuse Purple + Rear Right Speaker Power B+ (Yellow) Purple/Black -... -
Page 6: Control Panel Button Locations
CONTROL PANEL BUTTON LOCATIONS REMOVE PANEL OPERATION 1.POWER/SRC RADIO,USB&CARD , AUX IN,modes (if there are USB and SD card inside the unit). RADIO , and AUX IN, when user... -
Page 7: Operation
OPERATION 8. CLK Press the CLK button once to display the real time, With time appearing on the display.Press and hold CLK button for more than 2 seconds until the time flashes. You can adjust the HOUR and MINUTE by pressing the button and button respectively and rotate the volume knob to adjust. -
Page 8: 15. Mute
OPERATION During USB or SD playback, short press the AMS button to enter track search mode, then rotate the VOL knob to track forward or backward; if no any operation in 5 seconds,it will play the current track. 15. MUTE 19. -
Page 9: Remote Control
REMOTE CONTROL(CONT.) Button Names and Locations Power button MUTE button CLK (clock) button LOUD (loudness) button AMS (automatic music search) button PREV (previous) button EQ (equalizer) button SRC (source) button RPT (repeat) or 3 button 10. INT (intro) or 2 button 11. -
Page 10: Troubleshooting
TROUBLESHOOTING A lot of static in broadcast Connect the battery cable to the terminal that is always live. -
Page 11: Specifications
SPECIFICATIONS General Power supply Requirement : DC 12V Maximum power output : 50W X 4CH Speaker impedance : 4 - 8 Ohm Unit Dimensions(WxHxD) : 7.0 X 2.0 X 3.8 inch Weight : 1.54 Lb (0.7 kg) Fuse : 15 A RADIO Frequency Range USA / EUROPE: 87.5 MHz - 107.9 MHz / 87.5 MHz - 108.0MHz...
