Boss Audio Systems 612UA User Manual

Mp3-compatible digital media am/fm receiver with usb and sd memory card ports and front panel aux input
Hide thumbs
1
2
3
4
5

Advertisement

Quick Links

04.2011
BAND
AST
VOL
PWR/SEL
1
2
3
4
5
6
USB
-10
+10
RESET

Advertisement

loading

Related Manuals for Boss Audio Systems 612UA

Summary of Contents for Boss Audio Systems 612UA

  • Page 1 04.2011 BAND PWR/SEL RESET...

  • Page 2: Panel Function

    Panel Function MODE BAND PWR/SEL 1. PWR/SEL/VOL (power/mode select/volume button) 2. BAND/AST (band switch/station auto scan &store) 3. MODE/CLOCK (mode shift/clock time display & setup) STATION SCANNING/REWIND/TURN UP STATION SCANNING/REWIND/TURN DOWN 6 Number button (play/pause) 7.Number button (track browse & playback) 8.Number button (repeat playback) 9.Number button...

  • Page 3: Modes

    INSTRUCTIONS 1. PWR/SEL/VOL (power/mode select/volume button) After the unit getsconnected to the power supply, short press the button to turn The unit on,long press it to turn the unit off.Repeatedly short press SEL button to select your desired mode in the following sequence VOL→BASS→TRE→BAL→FAD→LOUD→EQ→ST→BEEP→AREA (USA: America/EUR: Europe) Work with VOL button, rotate it to make adjustment.

  • Page 4: Wiring Diagram

    INSTRUCTIONS -08- STATION SCANNING/REWIND/TURN UP In radio mode, short press the button to automatically scan station downward, long press the button to scan station downward manually. Inplayback mode, short press the button to select song downward, long press the button to perform fast forward playback. STATION SCANNING/REWIND/TURN DOWN In radio mode, short press the button to automatically scan station upward, long press the button to scan station upward manually.

  • Page 5: Performance Figure

    INSTRUCTIONS 10.Long press to select the previous foldershort press to play the song Under FM radio status, short press the button to get into the corresponding stored radio channels; under AM radio status, short press the button to get into the corresponding stored channels. After searching for a station manually, hold the button for 2 seconds to save the station in the number button 5’s position.
