Page 1: Table Of Contents
KL72TT Twin-tub Washing Machine with Pump Please read this manual carefully before using. Retain it for future reference Please check if the power receptacle has good earthing condition before using to guarantee your safety. The manufacturer will not bear the responsibility for those risks occurred from not obeying this manual.
Page 2: Names Of The Parts
Names of the parts Buzzer Water-filling entrance Water inlet selector handle Wash selector Wash timer Control panel Overflow filter Quick water-filling entrance Drain hose surpport Water level adjusting lever Lint filter(installed by user) Pulsator Wash tub Drain hose Wash tub cover Base frame Accessories Water-filling jointer...
Page 3: Safety Precautions
Safety precautions Please insert the power cord into special receptacle with rated voltage.Be sure to use single-phase three pins receptacle. The earthing terminal of the receptacle must be earthed reliably.If possible,please adopt electric leakage protector. Earth If the supply cord is damaged, it must be replaced by the manufacturer,it s service agent or similarly qualified persons in order to avoid a hazard.
Page 4 Safety precautions Do not stretch hands into the working machine. It is dangerous even if the rotation is slow. Take special care of the children. Do not put any hot or heavy items ( such as the kettle with hot water ) on the washing machine.
Page 5: Installation And Adjustment
Installation and adjustment Please install and adjust the machine according to the requirement of the manual. It is very important to your security and correct operating the machine. The drainage shall be smooth with the drain hose. 1.The height of the drain hose shall be not be smooth enough and cause incomplete drainage.
Page 6 How to change the direction of the drain hoses Figure 1 indicates the ex factory installation position of the drain hose. Extend the drain hose from the side of spin tub. Take off the drain hose from the hanging hole of the cabinet. Pull the drain hose fixing hook outwards gently to take out the drain hose from the two fixing hooks.
Page 7: Introduction Of The Major Functions
Introduction of the major function The machine has good comprehensive performance, and nice appearance. It adopts streamline appearance and full plastic shell, which will never get rust. For the design on safety and reliability, it adopts the wash shelf, spin shelf and water reception groove design, and reduces the unfavorable influence on the electrical component by the vapor.
Page 8: Preparation Before Washing
Preparation before washing Pay attention to followings before washing the laundries Check C l e a r t h e the laundries pocket. Take has special out the coins, requirement sand, hairpins on washing etc. a. Check if the laundries are applicable for washing with machine. b.
Page 9: The Musts In Washing
The musts in washing Reference weight of the laundries Working suit up,down cotton,about 1120g Blanket cotton,about 900g Pajamas Shirt cotton,about 300g Undershirt cotton,about 180g The capacity of washing and spinning of the machine refer to the largest weight of the standard laundries under dry condition that can be washed or spinned in one time.
Page 10: Usage Of The Detergent
Usage of the detergent How to use the whitener Fill water to decided level. Dilute the whitener with container. Pour it slowly into the washing tub. Avoid using whitener on laundries with color or pattern as they are prone to lose color. The whitener shall not touch the laundries directly.
Page 11: Washing Sequence
Washing sequence Wash timer Wash selector (To set to below 2 minute, (Strong current, first set to 5 minute then standard current) turn it back. it can increase the service life of the timer). STRONG STANDARD WASH SELECTOR WASH TIMER Wash 1.Water-filling selector (1) Set the water-filling selector at the "WASH"...
Page 12 Midway spinning Put the laundries into the spin tub evenly and smoothly. Spin (1) Put the gland in properly. Please put in the gland properly even if the laundries quantity is small. Push Gland The laundries Proper are slanting (2) Close the inner and outer cover of the spin tub. (3) Spin for 1-2 minutes.
Page 13 Rinsing Rinse with water-filing 1.Put the laundries into the wash tub. Select suitable current according to the laundries. 2.Adjust the water level Set the water level with water level adjusting lever according to the laundries quantity. Then fill suitable water continuously. 3.Rinse Adjust the wash timer to 5-7 minutes to do rinsing.
Page 14 Spinning 1. Put the laundries into the spin tub evenly and smoothly. 2. Press the gland in the tub properly. Close the inner and outer cover of the spin tub. 3. Spin Select suitable spin time according to the laundries, and do spinning. During spinning, if there's abnormal sound, it is generally owing to slanting placement of the laundries.
Page 15: Disposal After Washing
Disposal after washing After using, please clean the lint and foreign materials of the lint filter and overflow filter in time. Otherwise it may influence your using the machine. Please first pull off the power plug from the receptacle before cleaning. Cleaning the lint filter The lint filter must be used during washing.
Page 16 Cleaning the overflow filter 2. Take off the corrugation pipe. Dismantle the upper part of the corrugation pipe inside overflow filter ( as indicated in Figure 1). 3. Cleaning the overflow filter Clean the lint around the filter and flush with tap water. 4.
Page 17: Trouble-Shooting* Answers To Question
Trouble-shooting Answer to question If the laundries fall to the outer side of the spin tub If the laundries fall to the outer side of the spin tub, please take them out immediately. 1.Dismantle As indicated in the figure, push the point marked with "...
Page 18 Trouble-shooting Answer to question (If there's breakdown, please pull off the power plug before checking) The following phenomena are not breakdowns sometimes. Please confirm again before sending it to repair. If there are real breakdowns, please come to the special maintenance department or after-sale service department of our company.
Page 19: Packing List
Packing list User's manual Water inlet hose Water-filling jointer Gland Lint filter Twin-tub washing machine...
Page 20: Specification
Rated washing capacity kg Rated spinning capacity kg Rated input power W Dimensions(mm) Wash pattern Weight kg Injection pressure Twin-tub washing machine with pump KL72TT Rated voltage 220V~, Rated frequency 50Hz Maximum/55L Medium/46L Minimum/36L Wash 320 Spin210 L810 W460 H926 New current 0.02MPa~0.2MPa...
