35.292.941…KF 820G.qxd 03/01/2005 16:30 Página 2 Dear customer, Please read these operating instructions carefully and pay particular attention to the safety notes indicated in the first pages. We recommend that you keep this instruction booklet for future reference and pass it on to any future owners. Transport damages When unpacking the appliance, check that it is not damaged.
35.292.941…KF 820G.qxd 03/01/2005 16:30 Página 4 Warnings The following warnings are provided in the interests of overall safety. You must read them carefully before installing or using the appliance. Installation • Leave the porthole door slightly ajar when the appliance is not in use. This preserves the door •...
35.292.941…KF 820G.qxd 03/01/2005 16:30 Página 5 Child safety • Keep all detergents in a safe place out of children’s reach. • Children are often not aware of how dangerous • Make sure that children or pets do not climb into electrical appliances can be.
35.292.941…KF 820G.qxd 03/01/2005 16:30 Página 6 Technical specifications DIMENSIONS Height 85 cm Width 60 cm Depth 60 cm MAXIMUM LOAD Cotton 5 kg Synthetics 2 kg Delicates 2 kg Woollens 1 kg SPIN SPEED 800 rpm max. POWER SUPPLY VOLTAGE/FREQUENCY 230 V/50 Hz TOTAL POWER ABSORBED 2100 W...
35.292.941…KF 820G.qxd 03/01/2005 16:30 Página 7 Installation Transit security bars Hydraulic connection Before starting the machine up, the transport There should be a COLD WATER tap near the security bars must be removed as follows: washing machine with a screwing on connection You are advised to keep all the transport security pipe of ⁄...
35.292.941…KF 820G.qxd 03/01/2005 16:30 Página 8 1,5 m. Max. IMPORTANT: The distance from the floor to the Electrical connections highest part of the hose should be between 60 to Before plugging the appliance make sure that: 90 cm. (It is advised to be between 60 and 70 cm). 1º.
35.292.941…KF 820G.qxd 03/01/2005 16:30 Página 9 Your new washing machine This new machine meets all modern requirements for effective treatment of laundry with low water, energy and detergent consumption. • The temperature selector dial will allow you to choose the most suitable temperature for your laundry. •...
35.292.941…KF 820G.qxd 03/01/2005 16:30 Página 10 Control panel 1. Programme chart 6. Temperature selector It will help you to choose the most suitable washing This control allows you to select the temperature of programme for your laundry. the washing cycle in accordance with the kind of clothes to be washed.
35.292.941…KF 820G.qxd 03/01/2005 16:30 Página 11 Laundry weights Washing hints The following weights are indicative: bathrobe 1200 g Sorting the laundry napkin 100 g Follow the wash code symbols on each garment quilt cover 700 g label and the manufacturer’s washing instructions. Sort the laundry as follows: sheet 500 g...
35.292.941…KF 820G.qxd 03/01/2005 16:30 Página 12 Ink: depending on the type of ink, moisten the fabric Quantity of detergent to be used first with acetone (*), then with acetic acid; treat any The type and quantity of detergent will depend on residual marks on white fabrics with bleach and then the type of fabric, load size, degree of soiling and rinse thoroughly.
35.292.941…KF 820G.qxd 03/01/2005 16:30 Página 13 International wash code symbols These symbols appear on fabric labels, in order to help you choose the best way to treat your laundry. Energetic wash Max. wash Max. wash Max. wash Max. wash temperature temperature temperature temperature...
35.292.941…KF 820G.qxd 03/01/2005 16:30 Página 14 4. Select the temperature Operating sequence Turn the dial to the required setting. Before washing your first load of laundry, we recommend that you run a cotton cycle at 60°C, with the machine empty, in order to remove any manufacturing residue from the drum and tub.
35.292.941…KF 820G.qxd 03/01/2005 16:30 Página 15 7. At the end of the programme The machine stops automatically. The mains on light goes out. If you have selected a programme which ends with the water of the last rinse left in the tub, drain the water before opening the door.
35.292.941…KF 820G.qxd 03/01/2005 16:31 Página 18 Maintenance 1. Bodywork 3. Cleaning of the drainage area Clean the outside of the machine with warm water The drainage area must be cleaned if the pump has and a neutral, non-abrasive household detergent. been blocked with objects such as buttons, safety Rinse with clean water and dry with a soft cloth.
35.292.941…KF 820G.qxd 03/01/2005 16:31 Página 19 4. The water inlet hose filter 6. Frost precautions If the machine is installed in a place where the If your water is very hard or contains traces of lime temperature could drop below 0°C, proceed as deposit, the water inlet filter may become clogged.
35.292.941…KF 820G.qxd 03/01/2005 16:31 Página 20 Something not working? Problems which you can resolve yourself. Problem Possible cause • The machine does not start up: • The door is not firmly closed. • The machine is not plugged in or there is no power at the socket.
Page 21
35.292.941…KF 820G.qxd 03/01/2005 16:31 Página 21 If you are unable to identify or solve the problem, contact our service centre. Before telephoning, make a note of the model, serial number and purchase date of your machine: the Service Centre will require this information.
