Summary of Contents for Kogan KALED40XXXTB
-
Page 2: Table Of Contents
Contents Caution Safety Information Names of each part 4 - 5 Front View Accessories Back View Remote Control 6 - 7 Basic Operation 10-15 OSD Menu 1. Picture menu 2. Sound menu 3. Channel menu 4. Feature menu 14-15 5. Setup menu Multimedia Operation 16-18 Important Unique Buttons... -
Page 3: Caution
Caution The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to the persons. The exclamation point within an equilateral triangle is intend to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. -
Page 4: Safety Information
Safety Information To ensure reliable and safe operation of this equipment, please carefully read all the instructions in this user guide, especially the safety information below . Electrical safety To prevent overload, don't share the same mains supply socket with too many other items of equipment. - Page 5 Safety Information IMPORTANT INFORMATION Use cabinets or stands recommended by the manufacturer of the television. Only use furniture that can safely support the television. Ensure that the television is not overhanging the edge of the supporting furniture. Do not place the television on tall furniture (for example, cupboards or bookcases) without anchoring both the furniture and the television to a suitable support.
-
Page 6: Names Of Each Part
Names of each part Front View : Turn on/standby the TV set. : To switch the signal source. MENU: Display/exit the OSD menu. -: Adjust the volume. + CH - : Scan through channels. POWER INFO SOURCE AUDIO I/II MENU EXIT ENTER INDEX... -
Page 7: Back View
Names of each part Back View AV/YPbPr R/L YPbPr HDMI _________... -
Page 8: Remote Control
Remote Control Remote Control The buttons of the remote control are as following: : Power, switch on or off TV set. 2. INFO: Press to display the current program information on the screen. : Go to the index page. : Press to mute or restore sound. 4. - Page 9 Remote Control Remote Control 19. COLOUR BUTTONS: Red/ green/ yellow/ blue key navigation link. : Fast reverse (in USB mode). : Fast forward (in USB mode). : Previous (in USB mode). : Next (in USB mode). 20. STILL: Press to hold the picture. : Hold the teletext page on display, press again to release.
-
Page 10: Basic Operation
Basic Operation QUICK START GUIDE • Connection 1. Connecting the mains and antenna. 2. Press Power button on the remote to turn on the TV. • First Time Setup When the TV is initially powered on, a sequence of on-screen prompts will assist in configuring basic settings. -
Page 11: Basic Operation 8
Basic Operation Volume adjustment • Press the VOL+/- button to adjust the volume. • If you want to switch the sound OFF, press the • You can release mute by pressing the or increase the volume. Changing the Input Source You can select the input source by pressing the SOURCE button on the remote control. -
Page 12: Osd Menu
OSD Menu Configuring the Picture Menu • Picture Mode You can select the type of picture that best corresponds to your viewing requirements. • Brightness Adjusts the base level of the signal in the picture. • Contrast Adjusts the signal level between black and white in the picture. -
Page 13: Sound Menu
OSD Menu Configuring the Sound Menu • Sound Mode You can select a sound mode to suit your personal preferences. • Treble Adjust the treble effect. Increases or decreases high-pitched sounds. • Bass Adjust the bass effect. Increases or decreases lower-pitched sounds. •... -
Page 14: Channel Menu
OSD Menu Configuring the Channel Menu • Auto Scan Press the ENTER button to enter sub-menu. Country: Press the◄/►button to select country. Mode: Press the◄/►button to select Mode: DTV+ATV, DTV, ATV. Start: Press the ENTER button to start the auto searching. •... -
Page 15: Feature Menu
OSD Menu Configuring the Lock System Menu • Enter Password The following items are only available if the password input is correct. Default password is 0000, and if you forget what you set, please call the service c enter. • Enable Channel Locks , Parental Rating and Lock... -
Page 16: Setup Menu
OSD Menu C onfiguring the Setup Menu • OSD Language Select your prefer red On Screen Display language. Audio Languages (In DTV mode) • Select your preferred audio language. (Available for digital channels if multiple audio languages are broadcast.) Press the▲/▼button to select Audio Languages, then press ENTE R button to enter sub-menu. -
Page 17: Osd Menu
OSD Menu • PVR Settings (In DTV mode) Press the▲/▼button to sel ect PVR Settings, then press ENTER button to enter sub-menu. It will check the USB. File Manager: To disp lay the Recorded list. Replay: Press the red button to replay a video. Delete One: Press the green button to delete a vide Delete All: Press the yellow button to delete all videos. -
Page 18: Multimedia Operation
Multimedia Operation sing USB mode • To Access/Quit USB mode 1. Connect a USB device. 2. Press SOURCE button to display the main menu. Use the ▲/▼ to highlight USB, and the ENTER button to access the USB mode. You may also use the signal source selection men u to exit from the USB mode. - Page 19 Multimedia Operation Bit Rate: up to MPEG-1 Layer 3 320Kbps *.mp3 Sample Rate: 32KHz, 44 .1KHz, MPEG-2 Layer 3 48KHz Music AAC(*.aac,*m4a) HE-AAC V1 HE-AA C V2 LPCM *.wav ADPCM 72x72 < B seline resolution < Baseline Mode 7680x4320 *.jpg Photo *.jpeg Progressive Mod...
- Page 20 Multimedia Operation hoto Press th e ◄/► button to select Photo in the main menu, then press ENTER button to enter. Press t he ◄/► button to select disk you want to watch, then press ENTER button to enter. Press t he CH+/- button to change page.
-
Page 21: Important Unique Buttons
Important Unique Buttons ttons PROGRAM GUIDE (In DTV mode) Press the EPG button to enter PROGRAM GUIDE menu. Press the button to set the parameters for recording. You can choose the time of the appointment to record you want. The unit is able to do schedule recording when TV is turning on or in standby mode. -
Page 22: Teletext
Teletext (Not available in Australia currently) Using the teletext feature • Display teletext 1. Select a TV station with a teletext signal. 2. Press the button to enter teletext mode. button twice to enter Mix mode. This function enables you to 3. -
Page 23: Trouble Shooting
Trouble shooting Troubleshooting Before contacting the customer service team, perform the following simple checks. If any problems persist, unplug the TV and calling for serving. PROBLEM POSSIBLE SOLUTION - Check whether the main plug has been connected to a wall outlet. No sound and picture - Check whether you have pressed the POWER button on the front of TV set. - Page 24 Trouble shooting NOTE: There is a problem in VGA mode (Only VGA mode applied). PROBLEM POSSIBLE SOLUTION - Adjust resolution, horizontal frequency, or vertical frequency. The signal is out of range. - Check it whether the signal cable is connected or loose.
-
Page 25: Specifications
Specifications Techincal Specifications B G/DK TV System PAL/SECAM 40" (diagonal) Screen size Resolution 1920 x1080 pixels (RGB) Aerial input Max Power Consumption... - Page 26 Instructions for the anti-overturning bracket: 1.The flat panel can overturn due to any external force, as shown in the following figure, which shall be prevented. 2. It is required to install 2 brackets on the rear cover of the flat panel. Bracket×2 Screws×2 3.
