- Page 1 Created 10/2010 18212.2i © 2010 Horizon Hobby, Inc. ECX1000UK, ECX1000EU, ECX1100EU, ECX1100UK...
- Page 2 1/10 electrIc stadIuM truck Congratulations on your purchase of the Electrix RC InstructIon Manual Circuit Stadium Truck. This 1/10 scale model introduces you to the sport of RC driving. BedIenungsanleItung Herzlichen Glückwunsch zum Kauf des RC Circuit Stadium Truck. Dieses 1/10 Scale Model öffnet Ihnen die Welt des RC Car Sports.
-
Page 3: Safety Precautions And Warnings
NOTICE All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, Inc. For up-to-date product literature, visit http://www.horizonhobby.com and click on the support tab for this product. Meaning of Special Language: The following terms are used throughout the product literature to indicate various levels of potential harm when operating this... -
Page 4: Table Of Contents
table of contents Safety Precautions and Warnings .................................... 1 Specifications..........................................2 Operation Components ........................................3 Installing Vehicle Battery, Antenna Tube, and Body ............................3 Transmitter Controls ......................................4 Charging the Battery ......................................5 Installing Transmitter Battery ..................................... 5 Getting Started ........................................6 Finishing ..........................................6 Operation ..........................................7 Maintenance Setting the Gear Mesh ....................................... 8 Shock Cleaning/Maintenance ..................................... -
Page 5: Components
components included items AA (8) ECX1075 Battery Charger ECX1075AU Battery Charger (AU) ECX1075EU Battery Charger (EU) Electrix RC Circuit ECX1075UK Battery Charger (UK) 1/10 Stadium Truck Note: Charger power outlet ECX1000 terminals not shown. 7.2V NiMh battery Antenna Tube (DYN1050) Transmitter ECX1087 installing Vehicle battery, antenna tube and body • Turn the thumb nuts on the chassis to remove the battery strap holding the battery. -
Page 6: Transmitter Controls
transmitter controls aM 27 Mhz transMItter crystal reverse sWItch AM Transmitter Crystal AM Receiver Crystal antenna (RX) (RX) Pull antenna out to its Part # Description full length for best results ECX1081 Crystal Set 1 26.995 (ECX1067 Antenna Only) ECX1082 Crystal Set 2 27.045 ECX1083 Crystal Set 3 27.095 ECX1084 Crystal Set 4 27.145 Note: Paired AM crystals must be... -
Page 7: Charging The Battery
charging the battery Note: The vehicle battery charger produces 300 milliAmps per hour. Divide the mAh capacity on the label of a battery by 300 to know how long battery charging will require. For example, an 1800 mAh battery requires six (6) hours to charge. -
Page 8: Getting Started
getting started 2. Connect battery (page 3) to Electronic Speed Con- 1. Extend Antenna and Power on Transmitter trol (ESC) and power on the ESC 4. Start driving slowly and if the vehicle does not 3. Do a Test of Transmitter’s control of vehicle go straight, adjust steering trim dial on Transmitter with vehicle wheels off ground Note: Seat motor brushes by driving smoothly on a flat surface during use of the first battery charge. -
Page 9: Operation
operation Always turn on your transmitter before you turn on the receiver in the car. Always turn off the receiver before turning your transmitter off. ALWAYS operate vehicle in a wide open area. Operating the vehicle in a small space or indoors can cause overheating at low speeds. Operating at low speed makes heat in the electronic speed control (ESC). Overheating can damage the vehicle and failure may result. Motor care • Seat motor brushes by driving smoothly on a flat surface during use of the first battery charge. • Prolong motor life by preventing overheat conditions. Undue motor wear results from frequent turns, stops and starts, pushing objects, driving in deep sand and tall grass and driving continuously up hill. • Over temperature protection is installed on the ESC to prevent circuit damage, but cannot protect the motor from driving against heavy resistance. -
Page 10: Setting The Gear Mesh
setting the gear mesh Gear mesh has already been set at the factory, and setting it is only necessary when changing motors or gears. Proper gear mesh (how gear teeth meet) is important to the performance of the vehicle. When gear mesh is too loose, the spur gear could be damaged by the pinion gear of the motor. -
Page 11: Parts Diagram
parts diagram recommended items Cross wrench Long nose pliers Screwdriver (small) Hex wrench MaIn chassIs M3x25 ECX1068 M3x10 M3x12 M3x10 M3x10 Part # Description ECX1017 Main Chassis M3x25 ECX1028 Servo Saver Set ECX1029 ECX1092 ECX1029 Top Plate ECX1050 ECX1058 ECX1050 Set Screw M3x12 (4) ECX1088 ECX1053... -
Page 12: Front Suspension
parts diagram front susPensIon ECX1020 ECX1093 M3x25 M3x12 M3x12 Part # Description M3x13 ECX1005 Chrome wheel ribbed tire (2) ECX1046 M3x12 ECX1046 ECX1015 Wheel Bearing Set M3x12 M3x16 ECX1044 ECX1018 Front Suspension Arm Set ECX1035 ECX1020 Shock Tower Set ECX1058 ECX1090 ECX1018 M2.5x4 M3x16 ECX1089... -
Page 13: Wheel Assembly
wheel assembly rear Wheel front Wheel detaIl of drIve hex Note: When installing wheel, make sure drive hex is aligned with the drive pin. When the drive hex is removed, the drive pin can fall out of the axle. electrical layout Note: For correct operation, Channels 1 AM Receiver ECX1070... -
Page 14: Electronic Speed Control (Esc)
electronic speed control (esc) Continuous green light Green light is signal for Forward. Red light is signal for Reverse. Continuous red light Red light flashing with beep is signal that a transmitter is not being received. beep beep beep Red light flashing twice with beeps is signal that vehicle battery is low. -
Page 15: Warranty Information
For questions or assistance, please direct your email to Exclusive Warranty- Horizon Hobby, Inc., (Horizon) warranties productsupport@horizonhobby.com, or call 877.504.0233 toll that the Products purchased (the “Product”) will be free from free to speak to a Product Support representative. -
Page 16: Contact Information
No. HH2010060707 Product(s): NYA CIRCUIT 1/10TH STADIUM TRUCK Item Number(s): ECX1000UK, ECX1000EU, ECX1100EU, ECX1100UK Equipment class: The object of declaration described above is in conformity with the requirements of the specifications listed below, following the provisions of the European R&TTE directive 1999/5/EC: EN 300-220 Technical requirements for Radio equipment.
