RespirAide R200T Service Manual

Electronic air purifier
Hide thumbs
Table of Contents

Advertisement

Quick Links

CONTENTS
PART I GENERAL DESCRIPTION ON AIR CLEANING
PART II AIR CLEANING TECHNOLOGY OF THE UNIT
PART III ELECTRICAL SYSTEM OF THE UNIT
PART IV UNIT DISPLAY
PART V TROUBLESHOOTING
PART VI HOW TO REPLACE THE PARTS
SDJP0809
Copyright
2008 RespirAide Tech Inc.
C
SERVICE MANUAL
R200 Ver.2.1
R200T
ELECTRONIC
AIR PURIFIER
This manual provides reference
information for servicing the
Respiraide 200T.
WARNING:
RISK OF ELECTRIC SHOCK
This servicing manual is for use by
qualified personnel only. To reduce
the risk of electric shock, do not
perform any servicing other than
that contained in the operating
manual unless you are qualified to
do so.
228256
R
C
US
ERI JU07655-7001
