RespirAide 200T Operation Manual

Electronic air purifier
Hide thumbs Also See for 200T:
Table of Contents

Advertisement

Quick Links

Sensor
Manual
Auto
Remote control Button melody
Timer
Filter & UV lamp
Safety switch
replacement alarm
Model No.
228256
Check alarm
RespirAide Tech Inc.
Add:13-100 Hanlan Road
Woodbridge, Ontario Canada
L4L 4V8
Tel: 1-866-874-2532
Fax: 1-905-850-5553
www.respiraide.com
**RespirAide is a trademark of RespirAide Tech Inc.
6
Phase

Operation Manual

RespirAide200T
R
C
US
WARNING
To reduce the risk of electric shock,
this equipment has a grounding
type plug that has a third
(grounding) pin.This plug will only fit
into a grounding type power outlet.If
the plug does not fit into the outlet,
contact a qualified personnel to
install the proper outlet.Do not alter
the plug in any way.
Before operating the system,please read this
manual
thoroughly,and retain it for future
reference.
This product can be used only where the
power supply is 120V/60Hz.You can not use
the unit if the power voltage is different.
R
