- Page 1 CoolMatic RPD-175, RPD-215 Refrigerator Instruction manual M_101101_RPD_R1.indd 1 M_101101_RPD_R1.indd 1 10/12/10 2:36 PM 10/12/10 2:36 PM...
- Page 2 RPD-175, RPD-215 RPD-175 M_101101_RPD_R1.indd 2 M_101101_RPD_R1.indd 2 10/12/10 2:36 PM 10/12/10 2:36 PM...
- Page 3 RPD-175, RPD-215 RPD-215 M_101101_RPD_R1.indd 3 M_101101_RPD_R1.indd 3 10/12/10 2:36 PM 10/12/10 2:36 PM...
- Page 4 RPD-175, RPD-215 ∅/mm² 12 V 24 V VIEW A VENTILATION HOLES 50 min VIEW A POWER STATUS COLD COLDEST ON/OFF M_101101_RPD_R1.indd 4 M_101101_RPD_R1.indd 4 10/12/10 2:36 PM 10/12/10 2:36 PM...
-
Page 5: Table Of Contents
RPD-175, RPD-215 Please read this manual carefully before starting the machine. Keep it in a safe place for future reference. If the device is resold, this operating manual must be handed over to the purchaser along with the device. Contents... -
Page 6: Safety Instructions
This device may only be repaired by qualifi ed personnel. Inadequate repairs can lead to considerable hazards. Should your device need to be repaired, please contact WAECO customer services. Do not open the refrigerant circuit under any circumstances. Place the device in a dry location where it is protected against splashing water. -
Page 7: Scope Of Delivery
Scope of delivery RPD-175, RPD-215 Food may only be stored in its original packaging or in suitable containers. If the cable is damaged, it must be replaced to prevent possible electrical hazards. Only replace a damaged power cable with a power cable of the same type and specifi... -
Page 8: Intended Use
RPD-175, RPD-215 Intended use Intended use The refrigerator is suitable for cooling and freezing foodstuffs. The device is also suitable for use on boats. If you wish to cool medicines, please check if the cooling capacity of the device is suitable for the medicine in question. - Page 9 Using the refrigerator RPD-175, RPD-215 – Keep objects clear of openings in the housing or mounting structure (such as ventilation slots). – The refrigerator is designed for installation in a fi tted niche. Once it is installed, only the front of the appliance may be accessible.
-
Page 10: Drain Water Hose
RPD-175, RPD-215 Using the refrigerator 2. Install two screws in the top frame. 3. Install two screws in the rear base. Drain water hose The condensation which forms during normal operation of the refrigerator needs to be drained to the outside. - Page 11 RPD-175, RPD-215 Ventilation The refrigerator must be installed so that the warm air produced can easily fl ow away. Therefore make sure there is adequate ventilation ( fi g , page 4). page 4 Explanation Action No. in fi g...
- Page 12 RPD-175, RPD-215 Caution! Make sure that the polarity is correct. Before starting up the device for the fi rst time, check whether the operating voltage and the battery voltage correspond (see type plate). Connect the refrigerator – As directly as possible to the pole of the battery or –...
-
Page 13: Using The Refrigerator
RPD-175, RPD-215 Using the refrigerator Before starting your new refrigerator for the fi rst time, you should clean it inside and outside with a damp cloth for hygienic reasons (please also refer to 8 “Cleaning and maintenance”. Energy saving tips Choose a well ventilated installation location which is protected against direct sunlight. - Page 14 RPD-175, RPD-215 Power and Status LED’s Power LED The Power LED ( 2, page 4) indicates the following conditions: POWER LED Condition Not lit Refrigerator is turned off, or there is no power supply Green Refrigerator is turned on, and the compressor is running...
- Page 15 RPD-175, RPD-215 Conserving foodstuffs You can conserve foodstuffs in the refrigerator compartment. The time for which the food can be conserved in this way is usually stated on the package. Caution! Do not conserve warm food in the refrigerator compartment.
- Page 16 RPD-175, RPD-215 Removing and replacing the shelves 1. Remove the shelf locks by inserting the tip of a fl at bladed screwdriver into the slot of the locks. Turn the screwdriver counterclockwise and then remove the shelf locks from the wire shelf.
-
Page 17: Heating Cable
RPD-175, RPD-215 Heating cable During the summer months of high temperatures and humidity, the metal frame between the freezer and fresh food compartments may have water droplets forming. This refrigerator comes standard with a 12V DC heating cable that will evaporate the water droplets when they form. - Page 18 RPD-175, RPD-215 Switching off and storing the refrigerator If you do not intend to use the refrigerator for a long time, proceed as follows: Set the ON/OFF button ( 1, page 4) to ‘OFF’, indicated by POWER LED ( page 4) not lit.
-
Page 19: Replacing The Bulb
RPD-175, RPD-215 Replacing the bulb To replace the bulb, follow these steps: 1. Remove the lamp cover. Push the lamp cover backwards. 2. Replace the old bulb with an appliance bulb of the same wattage (12V, max 10W) 3. Replace the cover. -
Page 20: Cleaning And Maintenance
RPD-175, RPD-215 Cleaning and maintenance Caution! Do not use abrasive cleaning agents or hard objects during cleaning as these can damage the refrigerator. Caution! Never use hard or pointed tools to remove ice or to loosen objects which have frozen in place. -
Page 21: Troubleshooting
RPD-175, RPD-215 11 Troubleshooting General Fault Possible cause Suggested remedy Device does not There is no voltage present Check source to ensure power function, Power LED in the 12/24 V supply from battery is switched on does not glow The integrated mains... - Page 22 RPD-175, RPD-215 Interior temperature too cold on control setting “1” Fault Possible cause Remedy Compressor runs Thermostat sensor has no contact to Secure the sensor constantly the evaporator Short circuit in the thermostat line. Change the thermostat Thermostat defective –...
-
Page 23: Technical Data
RPD-175, RPD-215 12 Technical data RPD-175 RPD-215 Capacity (total) 175 litres 213.5 litres Freezer proportion 43 litres 43 litres Connection voltage 12 V DC or 24 V DC Rated Current 7.0A at 12V DC 7.5A at 12V DC 3.5A at 24V DC 3.5A at 24V DC... - Page 24 RPD-175, RPD-215 Dometic International AB Torggatan 8, SE-171 54 Solna. Sweden +46 (0)8 501 02500 · +46 (0)8 501 02599 Mail: info@dometic.se · Internet: www.dometic.com Europe Overseas + Middle East Dometic Austria GmbH Dometic Italy S.p.A. Dometic Australia Neudorferstrasse 108...
