- Page 1 INSTRUCTION MANUAL DA2208 2 in 8 out audio distributor P O W E R C H 1 a m pe r e s www.ampereselectronics.com Precision Design, Absolute Confidence...
-
Page 2: Parts Identifications
By using every Amperes product, you can be assured of money well worth invested in, as we do not end here. After sales services, parts availability and prompt turn around downtime are our key matters in our after sales objectives. - Page 3 To switch on / off the DC power connected to the unit. 5. DC POWER CONNECTOR The unit operates using 24V DC power supply, either via AC/DC adaptor or Amperes PS9400 power supply unit. We strongly recommend regulated power supply for powering the unit. Direct powering via 24V battery charger or battery connected to battery charger should be avoided.
- Page 4 Note : Use DA2208 when the output from a mixer ( or any other source ) is to be linked to many amplifiers ( typicall exceeding 6 units ). Otherwise it shall not be required and can be fed to amplifier inputs directly from mixer.
- Page 5 S IG IN S IG IN S IG IN S IG IN audio output - line balanced P O W E R AMPERES DA2208 C H 1 a m pe re s balanced line outputs output 1 location A ( soft music )
-
Page 6: Block Diagram
Pin 2 ( Hot ) Pin 3 ( Cold or -ve ) All inputs and outputs available in DA2208 are in balanced mode. In the event that unbalanced signal is to be used, pin 1 and pin 3 shall be shorted. -
Page 7: Technical Specifications
Amperes Electronics Sdn Bhd has the policy of improving or reviewing its products in design, performance as well as quality from time to time. It is therefore, Amperes Electronics has the right to change the above specifications without prior notice. The specification change shall cover the physical appearance, features as well as components used. -
Page 8: Warranty Conditions
It is recommended that all services and repairs on this product be carried out by AMPERES ELECTRONICS SDN BHD or its authorized service agents. AMPERES series must only be used for the purpose they were intended by the manufacturer and in conjunction with this operating manual.
