- Page 1 PS128A 1080p HDMI Splitter 1:8 With RS-232 control & HDMI v1.4 3D Video Format Support Installation Guide WWW.AAVARA.COM AAVARA INNOVATION CORP. ALL RIGHTS RESERVED Rev 1.1...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Chapter 1............. 3 1.1 Introduction ............ 3 1.2 Features ............3 1.3 Technical Specifications......... 4 Chapter 2............. 5 2.1 Installation ............5 2.2 RS-232 Command List ........5 Chapter 3............. 6 3.1 Troubleshooting .......... -
Page 3: Chapter 1
Chapter 1 1.1 Introduction Aavara® PS128A is a HDMI 1080p distribution hub that sends the same HDMI video input to eight HDMI HDTV digital screens. It support HDMI v1.4 3D Video Format, RS-232 control, Two Splitter Modes. PS128A is a flexible solution to integrate multiple displays in signage, video wall or demo shelf. -
Page 4: Technical Specifications
1.3 Technical Specifications Model No. PS128A HDMI Source Input HDMI Single Link, TMDS x 1 HDMI Display Output HDMI Single Link, TMDS x 8 Front Panel: - Splitter Mode Dip Switch: - Off M1 Greatest Common Video & Audio Format among all displays connected. -
Page 5: Chapter 2
Which Signage and Demo on retail shelf application, so any other display plug-in or unplug to PS128A HDMI Output 2 ~ 8 won’t affect other display, no black out for re-handshake for whole Splitter System. Also can ensure the output video resolution and audio format as expecting. -
Page 6: Chapter 3
4. Turn off all equipments and restart all equipments. HDMI Splitter ※ If the has HDCP compliant issue, please contact your video source device and display/projector seller for HDCP compliant. 3.2 F/W Upgradable: ALL RIGHTS RESERVED. 2011 AAVARA INNOVATION CORP.
