- Page 1 PCE122IR HDMI Over Single Coaxial Splitter/Extender w/ IR Pass-Thru User Guide WWW.AAVARA.COM AAVARA INNOVATION CORP. ALL RIGHTS RESERVED Rev 1.0...
- Page 2 TABLE OF CONTENTS Chapter 1 Introduction ........3 1.1 Features ............3 1.2 Content of Package ........3 1.3 Technical Specifications ....... 4 1.4 Panel Layout: ..........5 1.5 IR Cable Installation ........5 Chapter 2 Installation ......... 6...
-
Page 3: Chapter 1 Introduction
PCE122IR ultra long distance ultra high video quality transmission makes PCE122IR the perfect solution for both signage and residential AV applications. The PCE122IR also boasts built-in 1 to 2 Coaxial Splitter in Sender and One Coaxial Cascade output in Receiver which brings greater flexibility as it supports up to 5 layers cascade across 600M more HD video and audio transmission, for 10 connected TVs, displays or projectors or more. - Page 4 1.3 Technical Specifications Sender Receiver Item Name PCE122IR-S PCE122IR-R Input Connector HDMI Type A x 1 Coaxial BNC x 1 IR Receiver Jack x 1 Output Connector Coaxial BNC x 2 (1 to 2 Splitter) HDMI Type A x 1...
- Page 5 1.4 Panel Layout: Receiver Front Panel Receiver Rear Panel Sender Front Panel Sender Rear Panel 1.5 IR Cable Installation...
- Page 6 One Sender to One Receiver/HDTV configuration: Connect HDMI cable between video source’s HDMI output port and HDMI input of PCE122IR-S Sender. Connect one 75 Ohm RG6U Coax cable between Coax 1 output port of PCE122IR-S Sender and Coax in input port of PCE122IR-R Receiver.
