  • Page 1 Gas Cooktops Installation Guide...
  • Page 2 WARNING most up-to-date information. death if precautions are not followed. Throughout this guide, dimensions in IMPORTANT NOTE: parentheses are millimeters unless otherwise specified. Save these instructions for the local IMPORTANT NOTE: electrical inspector. Wolf Customer Care 800.222.7820...
  • Page 3: Product Information

    " is required between to the illustration below. units. If service is necessary, contact Wolf factory certified service with the model and serial number. For the name of the Electrical nearest Wolf factory certified service or for questions regarding the installation, visit the contact & support section Installation must comply with all applicable electrical codes.
  • Page 4: Gas Supply

    (34.9 mb) (3.5 kPa) pressures equal to or less than .5 psi (3.5 kPa) LP GAS Wolf natural gas cooktops will function up to 10,250' Supply Pressure 10" (25 mb) in altitude without adjustment and LP gas cooktops (3124 m) Min Line Pressure 11"...
  • Page 5 SPECIFICATIONS 15" Gas Cooktop STANDARD INSTALLATION " (64) 14" " (356) (495) " (64) COUNTERTOP CUT-OUT 13" 18" 30" (330) (457) (762) 7" (178) ELECTRICAL AND GAS FLOOR 5" LOCATION (127) SIDE VIEW FRONT VIEW NOTE: Shaded area above countertop indicates minimum clearance to combustible surfaces, combustible materials cannot be located within this area.
  • Page 6 NOTE: Shaded area above countertop indicates minimum clearance to combustible surfaces, combustible materials cannot be located within this area. Electrical and gas supply location only applies to installations with built-in oven. CUT-OUT WIDTH GAS COOKTOP 30" Model 29" (737) 36" Model 35" (889) Wolf Customer Care 800.222.7820...
  • Page 7: Cooktop Installation

    Cooktop installation. Wolf, Wolf & Design, Wolf Gourmet, W & Design and the color red as applied to knobs are registered trademarks and service marks of Wolf Appliance, Inc. Sub-Zero, Sub-Zero & Design, Dual Refrigeration, The Living Kitchen, Great American Kitchens The Fine Art of Kitchen Design, and Ingredients are registered trademarks and service marks of Sub-Zero,...
  • Page 8 AVISO IMPORTANTE: entre paréntesis son milímetros, a menos que se especi- fique lo contrario. guarde estas instrucciones para el AVISO IMPORTANTE: inspector eléctrico local. Atención al cliente de Wolf 800.222.7820...
  • Page 9 " entre las unidades. Si necesita servicio, póngase en contacto con el centro de servicio autorizado de Wolf y tenga a la mano el modelo y Instalación eléctrica número de serie de la unidad. Para obtener los datos del centro de servicio autorizado de Wolf más cercano o si La instalación debe tener una conexión a tierra de conformidad...
  • Page 10 WC, .5 psi estas elevaciones, póngase en contacto con su distribuidor (34.9 mb) (3.5 kPa) regulador autorizado de Wolf para conseguir un kit de conversión para regiones altas. LLAVE DE PASO EN POSICIÓN ABIERTA PLACA DE DATOS A LA UNIDAD...
  • Page 11 ESPECIFICACIONES Estufa de gas de 15" INSTALACIÓN ESTÁNDAR " (64) 14" " (356) (495) " (64) RECORTE DEL MOSTRADOR 13" 18" 30" (330) (457) (762) 7" (178) UBICACIÓN DE LA CONEXIÓN ELÉCTRICA Y DE GAS 5" EN EL PISO (127) VISTA LATERAL VISTA FRONTAL NOTA: la zona sombreada sobre el mostrador indica la distancia mínima a las superficies combustibles,...
  • Page 12 área. La ubicación del suministro eléctrico y de gas solamente aplica para las instalaciones con horno empotrado. ANCHURA DEL RECORTE MODELO Ancho Estufa de 30" 29" (737) Estufa de 36" 35" (889) Atención al cliente de Wolf 800.222.7820...
  • Page 13 Instalación de la estufa. Wolf, Wolf & Design, Wolf Gourmet, W & Design y el color rojo aplicado a las perillas son marcas comerciales registradas y marcas de servicio de Wolf Appliance, Inc. Sub-Zero, Sub-Zero & Design, Dual Refrigeration, The Living Kitchen, Great American Kitchens The Fine Art of Kitchen Design, e Ingredients son marcas comerciales registradas y marcas de servicios de Sub-Zero, Inc.
  • Page 14 REMARQUE IMPORTANTE : tout au long de ce guide, les dimensions entre parenthèses sont en millimètres à moins d’indication contraire. conservez ces directives pour REMARQUE IMPORTANTE : l’inspecteur en électricité local. Service à la clientèle de Wolf 800.222.7820...
  • Page 15 Pour obtenir le nom du centre de service L’installation doit être mise à la terre électriquement confor- Wolf certifié par l’usine le près de chez vous ou si vous mément aux codes locaux ou, en l’absence de codes avez des questions concernant l’installation, consultez la...
  • Page 16: Alimentation En Gaz

    à 0,5 lb/po² (3,5 kPa) Pression max. jusqu’au 14 po CE, 0,5 lb/po² (34,9 mb) (3,5 kPa) Les cuisinières au gaz naturel de Wolf fonctionneront régulateur jusqu’à une altitude de 10 250 pi sans ajustment (3 124 m) GAZ PL et les cuisinières au gaz PL fonctionneront jusqu’à...
  • Page 17 SPÉCIFICATIONS Surface de cuisson au gaz de 15 po INSTALLATION STANDARD (64) 14 po (356) (495) (64) DÉCOUPE DU COMPTOIR 13 po 18 po 30 po (330) (457) (762) 7 po (178) EMPLACEMENT SUR LE PLANCHER DE L’ÉLECTRICITÉ 5 po ET DU GAZ (127) VUE DE PROFIL...
  • Page 18 L’emplacement de l’alimentation électrique et en gaz ne s’applique qu’aux installations avec un four encastré. LARGEUR DE LA DÉCOUPE MODÈLE Surface de cuisson de 30 po 29 po (737) Surface de cuisson de 36 po 35 po (889) Service à la clientèle de Wolf 800.222.7820...
  • Page 19 Wolf, Wolf & Design, Wolf Gourmet, W & Design et la couleur rouge qui est appliquée aux boutons sont des marques déposées et des marques de service de Wolf Appliance, Inc. Sub-Zero, Sub-Zero & Design, Dual Refrigeration, The Living Kitchen, Great American Kitchens The Fine Art of Kitchen Design et Ingredients sont des marques déposées et des marques de service de Sub-Zero, Inc.
  • Page 20 WOLF APPLIANCE, INC. P.O. BOX 44848 MADISON, WI 53744 WOLFAPPLIANCE.COM 800.222.7820 823108 REV-D 7 / 2014...
