Nobles Viper 608669 Operator And Parts Manual

Upright vacuum cleaner

Hide thumbs Also See for Viper 608669:

Operator and parts manual (32 pages)

Table Of Contents

Table of Contents

Advertisement

Quick Links

Model No.:

608669

NOBLES

12875 RANSOM STREET

HOLLAND MI 49424 U.S.A.

CUSTOMER SERVICE: 1-800-365-6625

FAX: 1–800–678–4240

Find... Go To..

Home

Viper

Upright Vacuum Cleaner

Operator and Parts Manual

Rev. 01 (01-00)

R

608680

Table of Contents

Advertisement

Table of Contents

Need help?

Need help?

Do you have a question about the Viper 608669 and is the answer not in the manual?

Questions and answers

Summary of Contents for Nobles Viper 608669

Page 1: Upright Vacuum Cleaner
Viper Upright Vacuum Cleaner Model No.: Operator and Parts Manual 608669 NOBLES 12875 RANSOM STREET HOLLAND MI 49424 U.S.A. 608680 CUSTOMER SERVICE: 1-800-365-6625 FAX: 1–800–678–4240 Rev. 01 (01-00) Find... Go To.. Home...
Page 2: Parts List
PARTS LIST BAG HOUSING GROUP ViperR Upright Vacuum Cleaner (06–99) Find... Go To.. Home...
Page 3 PARTS LIST BAG HOUSING GROUP PART # DESCRIPTION QTY. PART # DESCRIPTION QTY. 605011 DASM., VAC HOSE WAND (see pg. 12) 130166 DCORD GRIP, NYLON/BLK W/NUT 608678 LID, BAG HOUSING, GREEN 604847 DCLIP, WAND 605998 DECAL, INDICATOR LIGHT 607006 SCREW, M4X.7X12 609417 HANDLE, GREEN 604844...
Page 4: Vacuum Motor Housing Group
PARTS LIST VACUUM MOTOR HOUSING GROUP ViperR Upright Vacuum Cleaner (03–99) Find... Go To.. Home...
Page 5 PARTS LIST VACUUM MOTOR HOUSING GROUP PART # DESCRIPTION QTY. PART # DESCRIPTION QTY. 605011 DASM., VAC HOSE WAND 606730 CLAMP PLATE, VAC MOTOR 604840 HOSE, VAC WAND 1-1/4 ID 606731 GASKET, LOWER CLAMP PLATE 604841 WAND, 35MM ID X 19 LG SWIVEL 606982 DFILTER, EXHAUST (3 PACK) 604929...
Page 6: Brush Base Group
PARTS LIST BRUSH BASE GROUP ViperR Upright Vacuum Cleaner (03–99) Find... Go To.. Home...
Page 7: Optional Attachment Kit
PULLEY, MOTOR (DOUBLE "V") 604811 KNOB, HT. ADJUSTMENT 130398 DMOTOR, BRUSH DRIVE 120 VOLT 608670 BASE, GREEN 130399 DMOTOR, BRUSH DRIVE 240 VOLT 608189 DECAL, NOBLES" 604803 DBRUSH ASM. 039708037 DSWITCH, ON/OFF ROCKER 230348 PULLEY, BRUSH (DOUBLE "V") 605010 DASM., VAC HOSE 230349...
Page 8: Wire Diagram
WIRE DIAGRAM 120V 240V TERMINAL STRIP BLUE MAIN SWITCH MAIN SWITCH BAG LOADED SWITCH BAG LOADED SWITCH SENSOR CONTROL SYSTEM BOARD LIGHT CONTROL BOARD MOUNTING PLATE CONTROL SENSOR BOARD SYSTEM LIGHT CONTROL BOARD MOUNTING BRACKET BRUSH MOTOR INTERRUPT SWITCH BRUSH MOTOR BRUSH BASE...
