NETGEAR LG2200-1USNAS Installation Manual

Installation Guide

™
4G LTE Router
(LG2200-1USNAS)

Package Contents

Router
Ethernet cable
Note: This guide explains how to install the router with a mobile Internet
connection. You can also use the Internet WAN port on the router to connect to
a broadband cable or DSL modem.
Seat the SIM Card
Your router comes with a 3FF SIM (micro SIM) card already installed. If the SIM
card is loose, you must seat it so that the router can detect it.
1. Unplug the router.
2. Open the SIM card compartment on the bottom of the router.
Antennas 3. Press the edge of the SIM card holder to seat it in the router.
Power adapter
4. Close the SIM card compartment door.
Attach the Antennas
You must install both antennas for a 4G connection.
1. Align the antennas with the antenna posts on the router.
2. Attach the antennas on the threaded antenna posts, ensuring that the
connection is secure.
3. Adjust the antenna positions. You can swivel the antennas in any direction.

Place the Router

Place the router in a location that
receives a strong mobile signal (for
example, near a window).
Do not put the router close to reflective or
metal surfaces, such as mirrors, metal file
cabinets, or stainless steel counter tops.
Do not put the router near electrical
equipment or appliances such as
microwave ovens that can generate WiFi
signal interference.
