Wireless Network (Wifi) - Webee ADSL Wireless N Router Installation Manual

3.3 CONNECT PC TO THE ROUTER
a. Plug network cable to the Ethernet port of your PC (RJ-45), and then to the LAN port of
the Router.
b. Start the computer. Check LED is green and indicating PC connected.
4

WIRELESS NETWORK (WiFi)

The wireless LAN and wireless security are preconfigured in the Router. Check LED is green to
indicate that wireless function is on, and the network is ready for use. If needed, press the WiFi
button.
WPA2-PSK encryption is set by default.
Wireless network name (SSID) and password are printed at the bottom of the Router. If you wish
to change the network name and password first log on to the user interface (5), and then
configure new security settings as shown below.
a. Open Wireless menu, and select Basic.
b. Set your SSID.
c. Click Apply/Save.
d. Open Security menu. Use WPA2-PSK if supported by your PC adapter. Set your network
key in WPA Pre-Shared Key. Otherwise use WEP (Shared). Then set your network key
in Network Key 1.
e. Click Apply/Save.
f. Change wireless network Channel (optional) in the Advanced menu.
g. Click Apply/Save.
5 LOGON USER INTERFACE
a. Launch your web browser, and then use http://192.168.1.1.to log on to the user interface.
b. Enter user name admin and password adslroot. Click OK.
If you wish to change the Router's password, set new password in Management
Control Passwords.
Access
