Webee ADSL Wireless N Router Installation Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
1
FRONT PANEL AND SIDE PANEL WIFI BUTTON
To enable or disable your wireless network, press the WiFi button on the side panel. The wireless
function is set by default.
2
BACK PANEL AND ON/OFF BUTTON
ADSL Wireless N Router
PWR
Green
LAN
Green
1,2,3
LAN 4
Green
WLAN
Green
DSL
Green
Solid green
INET
Flickering
Power on
On: LAN link connected
Blinking: Data transmitting/receiving via LAN port
Off: No LAN link
WAN link connected and active via LAN port
On: Wireless ready and idle
Blinking: Data transmitting/receiving over WLAN
Off: Wireless function is off
On: DSL link connected
Quick blinking: DSL is trying to connect
Slow blinking: No DSL link
IP connected
Data transmitting/receiving via the Internet
Installation Guide
v.1.5

Advertisement

loading
Need help?

Need help?

Do you have a question about the ADSL Wireless N Router and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Webee ADSL Wireless N Router

Summary of Contents for Webee ADSL Wireless N Router

  • Page 1 Installation Guide v.1.5 ADSL Wireless N Router FRONT PANEL AND SIDE PANEL WIFI BUTTON Green Power on On: LAN link connected Green Blinking: Data transmitting/receiving via LAN port 1,2,3 Off: No LAN link LAN 4 Green WAN link connected and active via LAN port...
  • Page 2 CONNECT ROUTER TO THE INTERNET Connect the Router to your broadband internet connection. To connect via ADSL, see 3.1 To connect via Ethernet, see 3.2 iii. To connect 3G USB Modem, see 7. Connect power adapter to the Router’s power connector, then plug it into the power wall outlet.

  • Page 3: Wireless Network (Wifi)

    CONNECT PC TO THE ROUTER Plug network cable to the Ethernet port of your PC (RJ-45), and then to the LAN port of the Router. Start the computer. Check LED is green and indicating PC connected. WIRELESS NETWORK (WiFi) The wireless LAN and wireless security are preconfigured in the Router. Check LED is green to indicate that wireless function is on, and the network is ready for use.
  • Page 4 OPERATORS’ ADSL SETTINGS If INET is not on after DSL connected, check the VPI/VCI identifiers from your operator. If needed, configure new VPI/VCI identifiers in the Router as shown below. Log on to the user interface (5). Open Advanced Setup menu, and select Layer2 Interface. Click ATM Interface. Click Add.
  • Page 5 Select WAN Service, and then click Add. Select the configuration. (Example is showing VPI as 0 and VCI as 35.) Click Next. Select IP over Ethernet , and then click Next. Check Enable NAT, Enable Firewall, Enable IGMP Multicast , and click Next.
  • Page 6 Click on the right side menu information, and then move the information to the left side menu by clicking the arrow button pointing to the left. Click Next. A new window will open. In the same way, move the information in DNS Server Configuration to the left side menu.
  • Page 7 CONNECT 3G USB-MODEM TO THE ROUTER If Router’s DSL Port or WAN Port is connected, unplug the cable. Note! Undo request for PIN on your SIM Card. Connect USB Modem to the Router’s USB Port. Log on to the user interface (5). Open Advanced Setup menu and select Layer2 Interface and 3G Interface.

  • Page 8: Printer Server Installations

    PRINTER SERVER INSTALLATIONS Connect printer cable to the Router’s USB Port. Log on to the user interface (5). Click Advanced Setup Print Server and then check Enable. Type the printer name (and Make and model). Click Apply/Save. In the Windows menu, click Control Panel Printers and Faxes Add a printer.

  • Page 9: Storage Service

    STORAGE SERVICE Connect USB storage device to the Router’s USB port. Log on to the user interface (5). Open Advanced Setup menu and select Storage Service. In table you can see the storage device information. Select User Accounts. Click Add. Enter your user name and password.
  • Page 10 In Samba server check Enable Samba server. Click Apply. In the Windows menu click Start Run. In Open use \\192.168.1.1. Click OK. Type your user name and password in the login interface. You will now access the USB storage device. The folder name is user name. RESET BUTTON AND FACTORY DEFAULTS On the side panel, you will find a small hole (Reset), which is actually the reset switch.
