The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly
damaged.
Caution
There are no user serviceable parts inside the fixture. Do not open the housing or attempt
any repairs yourself. In the unlikely situation, your unit may require service, please contact
your nearest dealer.

2. Technical Specifications

3, 5, 7channels selectable Flat LED PAR 64 light
4 push button with 4 Digital LED Display
Auto, Sound Activated, DMX512, Master/Slave, IR Remote Control
Light source:181PCS 10mm Ultra Bright LEDs (49 red,72 green,60 blue)
Please ensure there is nothing in between the remote and the fixture. Maximum distance for
the remote to work is 2 meters.
Bulb angle:15-20 degree
Power consumption: 20W
Power input: AC90-250V/ 50-60Hz
Dimensions:L430xW250xH155mm
Weight:2.35kg

3. Installation

The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is
firmly fixed to avoid vibration and slipping while operating. Always ensure that the structure
to which you are attaching the unit is secure and is able to support a weight of 10 times of
the unit's weight. Also always use a safety cable that can hold 12 times of the weight of the
unit when installing the fixture.
The equipment must be installed by professionals.

4. How To Set The Unit

4.1 Control Panel
3A
