Page 1: Installation Guide
Video surveillance camera Installation Guide TV7000 TV7004 TV7001 TV7005 TV7002 TV7006 TV7003 TV7007... -
Page 2: Scope Of Delivery
1. Preface Dear Customer, Thank you for purchasing this ECOLINE digital video surveillance camera. You made the right decision in choosing this state-of-the-art technology. This product complies with the current standards of national and European regulations. The CE has been proven and all related certifications are available from the manufacturer upon request. -
Page 3: Installation Instructions
Do not expose the camera to rain or moisture, or try to operate in wet areas. The camera is designed to be operated indoors only. If the camera becomes wet, turn the power off immediately and ask a qualified service technical to check it before turning the power on again. -
Page 4: Operating Controls And Functions
The ECOLINE colour cameras are equipped with an IR cut and cannot be used in combination with IR illumination. Perfect colour video pictures depend a great deal on the lighting. Please take this into account when installing artificial light sources. Light sources with a colour temperature different from daylight may effect colour drifts in colour cameras. -
Page 5: Auto-Iris Lens Connector
Depending on the camera model, you will find the 230V~ power cord (TV7001, TV7003, TV7005, TV7006) or an input terminal for 12V DC (TV7000, TV7002, TV7004, TV7008). Connect class 2 power supply only and observe the right polarity. (6) Lens drive signal selector for auto-... -
Page 6: Installation
(8) Power status LED This red LED is lit whenever the camera is supplied with power. Only when the LED is lit can a video signal be received from the VIDEO OUT of the camera. A red lit LED does not indicate that the camera is working without malfunction. -
Page 7: Pin Connector
Power on the camera with the correct power supply and make sure that the red Power LED is lit. If there is a video picture visible on the monitor, you may adjust focus and zoom. If there is no video picture on the monitor, please check the following. - Page 8 9. Technical data...
