Specification - ViewSonic A90f+-1 VCDTS23307-2R Service Manual

Size and deflection angle
Screen type
CDT
Horizontal pitch / Dot pitch
Surface treatment
Transmission rate
Horizontal Frequency
Scanning
Freq.
Vertical Frequency
Video amplifier Applicable pixel rate
Resolution
Maximum
Modes
Factory preset/User modes
AC input range
Max. power consumption
Power
Power Management
Power Switch
Up/Down adjustment Key
User controls
"1" " 2" Key
"UltraBrite Mode "Key
Rear
Signal
connection
connections
Power input
Agency
Approvals
European
USA
Plug and Play DDC 1/2 B
Operating Temperature
Storage Temperature
Environmental
Conditions Operating Humidity
Storage Humidity
Dimensions W x H x D
Weight Kg
ViewSonic Corporation
2. Specifications
Normal
Off
Standard Model
Safety
Emissions
Immunity
Ergonomic
VLMF
EPA
Safety
Emissions
X-ray
Regulatory Filing
3
19 inch 90 degree
Pure, Flat, High Brightness
0.22mm / 0.25mm
Anti-static AR coating
52.6%
30kHz to 86kHz
50Hz to 150Hz
175MHz
1600 x 1200
13 / 10
100 to 240 Vac
110W
<110 W
<3 W
On/off with Led indicator
2 key pads for adjust
Up / down keys are direct access for Contrast
And Brightness adjustment
As a select key/ go to next sub menu
As a select key/ go to High Bright Display mode
1.8 m signal cable with 15Pin D shell miniature
male connector.
AC socket with 1.8 meter cable
CB,
EN50081-1
EN50082-1
ISO9241Paart3 &ISO9241Part8
MPRII
Energy Star
UL1950, Cul950 or CSA 22.2
FCC class B
DHHS
VCDTS23307-XYZ
Version 2
0 C to 40 C
–40 C to +60 C
10% to 90%
10% to 95 %
575 mm x 600mm x 630mm
25.5Kg (Gross)
Confidential – Do Not Copy
A90f+-1
