- Page 1 Aspect L RD Installation guide 30cm...
- Page 2 1 < < < <...
- Page 3 2 < < < <...
- Page 4 3 < < < <...
- Page 5 4 < < < <...
- Page 6 5 < < < <...
-
Page 7: Table Of Contents
Table of contents Introduction ..................8 Safety instructions.................. 8 Installation requirements ................. 9 The fire ..................9 False Chimney breast ................ 9 Requirements flue system and outlets............ 9 terminals ..................10 Preparation and Installation instructions ............10 Gas connection ................10 Electric connection ................. - Page 8 Table ..................... 19 12.1 Please note : only a vertical flue installation, ......... 19 Technical Data.................. 20 Dimensions of the appliance ..............21 Dimensions ventilation grills ..............22 Dimensions service Hatch ..............23 7 < < < <...
-
Page 9: Introduction
1 Introduction The appliance can only be installed by a competent person in accordance with the Gas Safety. We urgently advise you to read this installation manual properly. This appliance complies with the guidelines for European gas appliances (Gas Appliances Directive) and bears the CE mark. -
Page 10: Installation Requirements
The false chimney breast and its construction may not rest on the appliance Requirements flue system and outlets You should always make use of the materials prescribed by Faber International Ltd. Only by using these materials can Faber International Ltd. guarantee a proper functioning. -
Page 11: Terminals
terminals The flue outlet can end on an external wall or a roof . Check whether the outlet desired by you complies with local requirements concerning good function and ventilation systems . For a proper functioning the terminal should be at least 0.5 m. away from: ... -
Page 12: Placing The Appliance
4.4.2 Suspended from the wall If desired, the appliance can be mounted suspended from the wall. Faber does not supply any extra materials for this. Make sure you have a sufficiently strong construction and take the bearing power of the wall into account. -
Page 13: Building A False Chimney Breast
Chapter 5). Check whether all the corners are aligned in a straight line (see dotted line 1 fig 1.3) If this is not the case then the top part A should be realigned in relation to the bottom part Do this in the following way: ... -
Page 14: Removing The Side Glass
removing the side glass Place the suction discs onto the glass. Remove the sealing cord from the groove. Slide the glass upwards so that the bottom edge is released from the groove. Now gradually move the bottom edge of the glass forwards and lower the glass into the opening between the build-in frame and the appliance. -
Page 15: Checking The Installation
burner (see fig. 3.2/3.3) Place the glass and check the fire image. 7 Checking the installation. Checking the ignition of the pilot burner, main burner. Start the pilot and main burner according to the instructions in the user’s manual. ... -
Page 16: Checking The Flame Picture
Checking the flame picture. Allow the applaince to burn for at least 20 minutes at full and then check the flame picture for: 1. Distribution of the flames 2. Colour of the flames If either one or both points are unacceptable, then check: ... -
Page 17: Annual Maintenance
9 Annual maintenance Service and cleaning: Check and clean if necessary after checking: o The pilot light o The burner o The combustion chamber o The glass o The logs for possible fractures o The outlet Replace: o If necessary the chips/embers. o in an LPG flat burner replace the burner sheet Cleaning the glass Most of the deposits can be removed with a dry cloth. -
Page 18: Calculation Of Flue System
11 Calculation of flue system The possibilities for the lengths of flue pipes and the possible restrictors have been recorded in a table (see chapter 12 ) This table works with a vertical and a horizontal length. To define the vertical length all lengths of flue pipes in a vertical direction should be added up. -
Page 19: Sample Computations
11.2 Sample computations Sample calculation 1 Count the horizontal lengths Flue pipe lengths C+E = 1 + 1 Bend D = 1 x 2 m Total Count the vertical lengths Flue pipe length A Roof terminal G Total Sample calculation 2 Count the horizontal lengths Flue pipe lengths J + L = 0,5 + 0,5 1 m Bends... -
Page 20: Table
12 Table Find the correct vertical and horizontal lengths in the table. In case of an “x”, or if the values are outside the table, the combination is not permitted. The value found indicates the width of the restrictor to be placed ("0" means no restrictor should be placed). -
Page 21: Technical Data
13 Technical Data 2H3+ 2H3+ 2H3+ Gascat. Type appliance C11 C31 C11 C31 C11 C31 Reference gas Input Nett Efficiency class NOx class mbar inlet-pressure 1050 Gas rate at 15ºC and 1013 mbar gr/h Gas rate at 15ºC and 1013 mbar mbar 23.5 24.5... -
Page 22: Dimensions Of The Appliance
Dimensions of the appliance 21 < < < <... -
Page 23: Dimensions Ventilation Grills
15 Dimensions ventilation grills 22 < < < <... -
Page 24: Dimensions Service Hatch
16 Dimensions service Hatch 23 < < < <...
