DC INVERTER MULTI VRF
No.
1 Left Decoration Plate
2 Shaft of Louver I
3 Swing Louver Fixer sub-assy
4 Louver Support
5 Louver Fixer
6 Louver
7 Shaft of Louver II
8 Right Decoration Plate
9 Left Swing Motor Fixer
10 Front Panel
11 Display Box
12 Display Board 5T52
13 Front Panel
14 Right Swing Motor Fixer
15 Step Motor MP35CA
16 Motor Clamp
17 Water Tray
18 Auxiliary Water Tray
19 Pipe Clip
20 Drainage hose
21 Handle
22 Right Side Foam sub-assy
23 Right Fixing Palte
24 Support of Motor Bearing
25 Fixer of Motor Support
26 Right Decoration Panel
27 Pipe Clamp
28 Electric Box
29 Wire Base
30 Wire Clamp
31
Terminal Board
32 Fuse 5A 250VAC
33 Main PCB Z6935
34 Ring of Bearing
35 Fan Bearing
36 Transformer 57X25C
37 Cover of Electric Box
38 Centrifugal Fan
39 Rotary Axis
40 Capacitor CBB61 3uF/450
41 Motor FN100A
42 Motor Fixer
43 Motor Clamp
44 Axes Connector
Part Name
MAINTENANCE
GMV(L)-R71Zd/Na-K
Code
261124172
10512025
013324232
24212020
24222016
105124042
10512026
261124212
26152007
01532414
20102138
30545654
01544106
26152008
15212402
26112026
01272412
01272413
70812001
05235433
26232001
12312407
01332404
01792408
01792409
26112033
01072424
01402407
24253001
24253002
42011159
46010013
30226903
76512404
76512210
43110237
01412408
10312401
73012401
33010027
15012406
01722409
01702405
73012403
Qty.
1
2
1
3
2
1
2
1
1
1
1
1
1
1
2
4
1
1
1
1
4
1
1
2
1
1
1
1
1
1
1
1
1
2
2
1
1
4
2
1
1
1
2
2
