CONCENTRIC TERMINATIONS

CONCENTRIC VENT KIT
NO. RXGY-E03A (SEE FIGURE 18)
This kit is for vertical and horizontal
intake air/vent runs. One
5-in. diameter hole is required for
installation. See Figure 18 for the gen-
eral layout. Complete installation
instructions are included with the kit.
FIGURE 18
CONCENTRIC VENT KIT NO. RXGY-E03A
(DIRECT VENT INSTALLATIONS)
ITEM No. DESCRIPTION
"
1 2.5 PVC PIPE SCHEDULE 40 -- 37.125
"
2 4 PVC PIPE SCHEDULE 40 -- 24
" "
3 3 x 3 x 4
"
4 3 x 45° STREET ELBOW (FIELD SUPPLIED)
5 PVC RAINCAP
HORIZONTAL INSTALLATION
FIELD-SUPPLIED
STRAP
NOTE: AIR INTAKE NOT
ORIENTATION SENSITIVE.
26
NOTE: The following IPEX brand con-
centric terminations (System 636) may
be purchased in the field and used in
place of factory supplied kits:
3" Concentric Kit – Item # 196006
"
LONG
"
LONG
"
SPECIAL CONCENTRIC FITTING
A
1" MAXIMUM
VERTICAL INSTALLATION
A NOTE: Drain tee is not needed for the inlet pipe.
MAINTAIN 12 IN.
MINIMUM CLEARANCE
ABOVE HIGHEST
ANTICIPATED SNOW
LEVEL. MAXIMUM OF
24 IN. ABOVE ROOF.
A
