• 96% residential gas furnace CSA certified
• 4 way multi-poise design
• Two stages of operation to save energy and maintain optimal
comfort level.
• Variable speed blower motor technology provides ultimate
humidity control, quieter sound levels, and year round energy
savings.
• EcoNet
™
enabled HVAC Product
• PlusOne
™
Diagnostics 7-Segment LED all units
• PlusOne
™
Ignition System – DSI for reliability and longevity
• PlusOne
™
Water Management System with patented Blocked
Drain Sensor
• Heat exchanger is removable for improved serviceability.
Aluminized steel primary and stainless steel secondary con-
struction provide maximum corrosion resistance and thermal
fatigue reliability.
Rheem Prestige Series
Two Stage Variable Speed Multi position
Gas Furnaces
R96V- Series
96% A.F.U.E.†
Input Rates from 40 to 115 kBTU
[11.72 to 33.71 kW]
All Models
R96VA085
✝ A.F.U.E. (Annual Fuel Utilization Efficiency) calculated in accordance with
Department of Energy test procedures.
• Low profile "34 inch" cabinet ideal for space constrained
installations.
• Blower Shelf design – serviceable in all furnace orientations
• Pre marked hoses – insures proper system drainage
• Vent with 2" or 3" PVC
• Replaceable Collector box
• Hemmed edges on cabinet and doors
• Quarter turn fasteners for tool less access
• Integrated control boards feature dip switches for easy
system set up
• Self priming condensate trap
• Solid bottom included
• Compatible with single or two stage thermostats. For optimal
performance a two stage thermostat is recommended.
™
Communicating
except
Gas Furnaces
Air
R96V Series
FORM NO. G11-540 REV. 4
Advertisement
Related Manuals for Rheem Prestige R96V series
Summary of Contents for Rheem Prestige R96V series
- Page 1 Gas Furnaces R96V Series Rheem Prestige Series ™ Communicating Two Stage Variable Speed Multi position Gas Furnaces R96V- Series 96% A.F.U.E.† Input Rates from 40 to 115 kBTU [11.72 to 33.71 kW] All Models except R96VA085 ✝ A.F.U.E. (Annual Fuel Utilization Efficiency) calculated in accordance with Department of Energy test procedures.
-
Page 2: Table Of Contents
Table of Contents R96V Series TABLE OF CONTENTS Standard & Optional Equipment ..............3 Physical Data & Specifications ................4 Model Number Identification ................5 Dimensional Data....................6 Blower Performance Data ................7 Accessories....................8 Limited Warranty ....................9... -
Page 3: Standard & Optional Equipment
Standard & Optional Equipment R96V Series REMOTE SENSOR DIRECT SPARK IGNITION & REMOTE SENSOR PRIMARY AND SECONDARY HEAT EXCHANGER GAS VALVE AND MANIFOLD IN-SHOT BURNERS DRAFT INDUCER PRESSURE SWITCHES BLOCKED DRAIN SENSOR ECM MOTOR CONTROL BOARD STANDARD EQUIPMENT OPTIONAL EQUIPMENT Completely assembled and wired;... -
Page 4: Physical Data & Specifications
Physical Data & Specifications R96V Series Physical Data and Specifications—Upflow Models U.S. and Canadian Models MODEL NUMBERS R96VA0402317MSA R96VA0602317MSA R96VA0702317MSA R96VA0852521MSB R96VA1002521MSA R96VA1152524MSA HIGH FIRE INPUT BTU/HR [kW] ➀ 42,000 [12.31] 56,000 [16.41] 70,000 [20.50] 84,000 [24.61] 98,000 [28.72] 112,000 [32.82] LOW FIRE INPUT 29,400 [8.61] 39,200 [11.49]... -
Page 5: Model Number Identification
Model Number Identification R96V Series Model Number Identification — Rheem Motor - Design Series Input Stage - Two Airflow Cabinet Width Configuration - S = Standard Revision - Efficient A = 1st Design BTU/HR 3 - Up to 3 Tons 17 = 17.5"... -
Page 6: Dimensional Data
Dimensional Data R96V Series UNIT DIMENSIONS UNIT DIMENSIONS (CLEARANCE TO COMBUSTIBLES) (CLEARANCE TO COMBUSTIBLES) MINIMUM CLEARANCE (IN.) [mm] FLANGE DIMENSIONS MODEL LEFT SHIP RIGHT R96V SIDE WGTS. BACK FRONT VENT SIDE 1 [25] 2 [51] 123.5 [56] [445] [413] [412] 1 [25] 2 [51] 128 [58]... -
Page 7: Blower Performance Data
Blower Performance Data R96V Series MODEL NUMBER R96VA0402317MSA R96VA0602317MSA R96VA0702317MSA R96VA0852521MSB R96VA1002521MSA R96VA115524MSA 1050 1025 1015 1470 1710 1450 SW 15 = SW 16 = [496] [484] [479] [694] [807] [684] 1235 1490 1300 SW ON = SW 16 = HIGH [378] [415]... -
Page 8: Accessories
Accessories R96V Series FOR HIGH ALTITUDES: VENT TERMINATION KITS: = NOTE: For Canadian installations only, an optional derate (manifold RXGY-E02: Vertical/Horizontal Concentric Vent Termination Kit gas pressure reduction) method may be used to adjust the 2" Pipe (US Only) furnace for altitude. See Installation Instructions for more RXGY-E02A: Vertical/Horizontal Concentric Vent Termination Kit information. -
Page 9: Limited Warranty
Limited Warranty R96V Series GENERAL TERMS OF LIMITED WARRANTY* Rheem will furnish a replacement for any part of this product Parts ............Ten (10) Years which fails in normal use and service within the applicable Heat Exchanger .........Limited Lifetime period stated, in accordance with the terms of the limited Limited Lifetime warranty. - Page 10 Notes R96V Series...
- Page 11 Notes R96V Series...
- Page 12 The new degree of comfort. ™ In keeping with its policy of continuous progress and product improvement, Rheem reserves the right to make changes without notice. Rheem Heating, Cooling & Water Heating • P.O. Box 17010 Rheem Canada Ltd./Ltée • 125 Edgeware Road, Unit 1 Fort Smith, Arkansas 72917 •...
