Summary of Contents for ProGin T-368
- Page 1 USER’S GUIDE T-368 Data Logger Bluetooth GPS Receiver V1.0 ProGin Technology Inc. 10F-1,No.77,Sec.2,Chung-Hwa E.Rd.,East District, Tainan City701, Taiwan Tel:+886-6-2694857 Fax:+886-6-2690442 E-mail: info@progin.com.tw http://www.progin.com.tw...
-
Page 2: Table Of Contents
1.3 Electrical Characteristics................3 2. Hardware ………………………………………………………………………………...4 2.1 Dimension…………………………………………………………………………..4 2.2 Accessories…………………………………………………………………………..4 2.3 Description………………………………………………………………………….5 3. Operation ………………………………………………………………………………...10 3.1 Getting Start…………………………………………………………………………..10 3.2 GPS Viewer for Testing....................11 3.3 Function…………………………………………………………………………………12 3.4 Navigation……………………………………………………………………………..12 4. Warranty ………………………………………………………………………………..12 Appendix: Software Specification………………………………………….. Appendix: Time Zone Table ………………………………………………………..22 T-368 User’s Guide v1.0... -
Page 3: Introduction
1 second (average) and updates position data every second. 1.2 Features The T-368 provides a host of features that make it easy for integration and use. 1. With SiRF StarⅢ high sensitivity chipset. 2. High sensitivity and high performance receiver tracks up to 20 satellites. -
Page 4: Electrical Characteristics
Class 2 (4 dBm max) Receiver sensitivity -80 dBm with BER<0.1% Communication distance 10 meter typically Communication profile Serial Port Profile (SPP) Power Consumption Main power input 5.0 ± 5% VDC input Operation Current 75 mA average in normal mode T-368 User’s Guide v1.0... -
Page 5: Hardware
A 1200 mAh Lithium-ion rechargeable battery. A vehicle lighter adapter assembly for battery recharge. A household power adaptor assembly for battery recharge. A USB cable assembly with “A” plug to mini USB plug. User manual and CD. T-368 User’s Guide v1.0... -
Page 6: Description
There is a SD/MMC card slot located on the other broadside of the body. The mini USB port for charging the battery is on the down side of the body. LED status T-368 User’s Guide v1.0... - Page 7 Remark: Battery charging suspended (protection when charging overtime or battery overheat) Unplug the power plug and wait for a moment to resume charging. LCD Indication The LCD display panel shows the following message: T-368 User’s Guide v1.0...
- Page 8 3. Press “Next” for 1 second to select different parameters. 4. After finishing setup, press “Exit” for 1 second to back to operation status. Whenever setting up, the power of the device must be turned off then on again to reactivate the signal. T-368 User’s Guide v1.0...
- Page 9 Record once per 8 seconds Under 100 Km/h Record once per 10 seconds Over 100 Km/h Record once per 20 seconds Whenever setting up, the power of the device must be turned off then on again to reactivate the signal. T-368 User’s Guide v1.0...
- Page 10 T-368 User’s Guide v1.0...
-
Page 11: Operation
Red LED flashing Battery in charging -------------------------------------------------------- Green LED steady on Battery charging suspended (protection when Green LED charge timer over or battery overheat) ----------------- flashing Charge completes or battery in normal capacity ---------------------- both LEDs off T-368 User’s Guide v1.0... -
Page 12: Gps Viewer For Testing
(b) Click “Start” to receive data. Usually a window shows the NMEA format data stream while another window shows tracked satellites signal quality. (c) Once the link is successful, click “Stop” button to stop the program. However, you may click, for example, the “Cold Start” button to perform “cold start” testing. T-368 User’s Guide v1.0... -
Page 13: Function
3.3 Function As soon as the power on, the T-368 Bluetooth GPS receiver begins the process of satellite acquisition, tracking, and Bluetooth radio connection. Under normal circumstances, it takes around 42 seconds (average) to achieve a position fix at the first time. After a position fix has been calculated, information about valid position, velocity, and time is transmitted over the output channel. -
Page 14: Appendix: Software Specification
NMEA Protocol The T-368 interface protocol is based on the National Marine Electronics Association (NMEA) interface specification, namely, the NMEA 0183 standard. The T-368 is capable of supporting the following NMEA message formats specifically developed and defined by SiRF. NMEA Message Prefix... - Page 15 DGPS is not used. Diff Ref. Station ID 0000 Checksum <CR> <LF> Message terminator. Only apply to NMEA version 2.3 (and later) in this NMEA message description. SiRF does not support geoid corrections. Values are WGS84 ellipsoid heights. T-368 User’s Guide v1.0...
- Page 16 N=north or S=south. Longitude 12158.3416 dddmm.mmmm E/W indicator E=east or W=west. UTC Time 161229.487 hhmmss.sss Status A: Data valid or V: Data invalid. Mode A=Autonomous, D=DGPS, E=DR (Only present in NMEA version 3.00). Checksum <CR><LF> Message terminator. T-368 User’s Guide v1.0...
- Page 17 2D position fix. 3D position fix. Satellites Used SV on channel 1. Satellites Used SV on channel 2. … Satellites Used SV on channel 12. PDOP HDOP VDOP Checksum <CR> <LF> Message terminator. Satellites used in solution. T-368 User’s Guide v1.0...
- Page 18 Azimuth of satellite, range 0 to 359. SNR (C/N dBHz Range 0 to 99, null when not tracking. Checksum <CR> <LF> Message terminator. (1) Depending on the number of satellites tracked multiple messages of GSV data may be required. T-368 User’s Guide v1.0...
- Page 19 The channel of the beacon being used if a multi-channel beacon receiver is used. Checksum <CR> <LF> Message terminator. Fields marked in italic red apply only to NMEA version 2.3 (and later) in this NMEA message description. T-368 User’s Guide v1.0...
- Page 20 <CR> <LF> Message terminator. SiRF does not support magnetic declination. All “course over ground” data are geodetic WGS84 directions. Fields marked in italic red apply only to NMEA version 2.3 (and later) in this NMEA message description. T-368 User’s Guide v1.0...
- Page 21 <CR> <LF> Message terminator. SiRF does not support magnetic declination. All “course over ground” data are geodetic WGS84 directions. Fields marked in italic red apply only to NMEA version 2.3 (and later) in this NMEA message description. T-368 User’s Guide v1.0...
- Page 22 01 to 31, day of month. UTC Month 01 to 12. UTC Year 2003 1980 to 2079. Local zone hours Offset from UTC (set to 00). Local zone minutes Offset from UTC (set to 00). Checksum <CR> <LF> Message terminator. T-368 User’s Guide v1.0...
-
Page 23: Appendix: Time Zone Table
Copenhagen, Madrid, Paris, Berlin, Bern, Rome, Stockholm, Vienna, West Central Africa Athens, Istanbul, Minsk Bucharest, Cairo, Pretoria, Jerusalem, Harare, Pretoria Helsinki, Riga, Israel, Kyiv, Sofia, Tallinn, Vilnius Baghdad, Kuwait, Riyadh, Nairobi Moscow, St. Petersburg, Volgograd Tehran +3.5 +4.5 T-368 User’s Guide v1.0... - Page 24 SAR, Kuala Lumpur, Irkutsk, Ulaan Bataa Osaka, Sapporo, Tokyo Seoul, Yakutks Adelaide, Darwin +9.5 Brisbane, Guam, Port Moresby Canberra, Melbourne, Sydney Hobart, Vladivostok Magadan, Solomon Islands, New Caledonia Auckland, Wellington Fiji Islands, Kamchatka, Marshall Islands *Unit: hour All Rights Reserved T-368 User’s Guide v1.0...
