HDMI®/ HDMI® Micro to VGA Video Converter - Active
MCHD2VGA
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
NOTE: If no video is passed through the video converter,
than it may not be getting enough power from the
HDMI connection. Connect the included power adapter
from an AC electrical outlet to the USB mini-B connector
on the side of the video converter. Restart the video
source device as necessary.
VGA connector (Output)
Packaging Contents
• 1 x HDMI to VGA Video Converter
*actual product may vary from photos
• 1 x HDMI to Micro HDMI Cable
• 1 x Power Adapter
• 1 x Instruction Manual
System Requirements
• HDMI enabled video source (Smartphone, PVR/ DVR, etc.)
• HDMI cable (if connecting non Micro HDMI device)
• VGA enabled display device (i.e. monitor, projector, etc.)
• VGA cable (male to male)
• OPTIONAL: Available AC electrical outlet
Installation
1. Make sure the video source and display device are both powered
off before attempting installation.
2. Connect an HDMI cable from the video source device to the video converter.
3. Connect a VGA cable from the display device to the video converter.
USB mini-B connector
HDMI type A
4. Power on the VGA display device first, followed by the HDMI video source.
connector (Input)
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 03/21/2012
