Instruction Manual
1000 Mbps Gigabit Single-Mode Fiber Ethernet Media Converter
MCMGBSC15 / MCMGBSC15GB / MCMGBSC15EU
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
Packaging Contents
• 1 x MCMGBSC15 / GB / EU media converter
• 1 x Power Adapter
• 1 x Installation Guide
System Requirements
• Gigabit (1000Mb/s) Ethernet network
• Gigabit (1000Mb/s) Fiber network
LED Indicators
LED
Status
Description
ON
PWR
OFF
ON
FX
LINK
OFF
ON
LINK
OFF
TP
ON
Unit is receiving data from Ethernet port
RX
OFF
No incoming data from Ethernet port
For the most up-to-date information, please visit: www.startech.com
Power On
Power Off
Fiber Link Detected
No Fiber Link Detected
Ethernet Link Detected
No Ethernet Link Detected
Front View
SC Fiber port
Rear View
DC power port
*actual product may vary from photos
RJ45 Ethernet port
LED
indicators
Mode switch
Manual Revision: 02/07/2012
