SYNC-SWITCH - MANUAL
The front panel appears as in the following figure.
At the bottom right there are two rows of status LEDs.
The figure below shows the back of SYNC-SWITCH with the positions of the connectors and their electrical wiring.
TNC
GPS Antenna
95 – 240 V
AC
PSU
SYNC-SWITCH does not provide any supply switch.
-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
SYNC-SWITCH – Manual – Rev 1.1
Front View
Rear View
10/100/1000
RJ45
Connectors
BNC
Gigabit SFP
10 MHz
Connectors
OUT
BNC
OUT
7
PPS
- 7 -
