Frequency Reference
Signal
Spectral Purity
Phase noise
Output level
Output impedance
Output connector
Stability
Time Reference
Signal
Output level
Output impedance
Output connector
PTP Section
Network connection
Protocol
Role
Time stamping
Precision
Options
Signalling
Signalling
Serial Connection
Supply
Input
Network
Sizes
Width
Depth
Weight
Accessories
Certifications
-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
SYNC-SWITCH – Manual – Rev 1.1

Technical Data

10 MHz sine wave
-70 dBc (harmonic)
-75 dBc (non-harmonic)
-125 dBc at 1kHz
13 dBm
50
BNC
1e-12 daily average (OCXO locked to GPS on SA)
1e-10 daily average (OCXO free run)
1 PPS, 100µs Duty, Rising Edge
TTL 5 Vpp, Square wave
50
BNC
N° 8x Ethernet 10/100/1000 interfaces, 2x 1/2.5 Gigabit SFP interfaces
IEEE 1588-2008 (PTPv2)
End-to-End Transparent Clock or Grandmaster Clock
Hardware
8 ns
Multicast, Unicast, E2E, P2P, UDP/IPv4, Layer 2, 802.1Q, SyncE
Leds on front panel
RS-232 connector IDC-10
N° 1 supply
95 Vac < > 240 Vac Plug IEC320 integrated, filter EMI/RFI
1 Unit 19''
300 mm without connectors
1.5 Kg
Handbook in English
CE
