SYNC-SWITCH - MANUAL
Sono presenti sul dispositivo e nella documentazione simboli utilizzati per la segnalazione di segnalazione
conformi alle specifiche IEC61010-1 II.
Safety-related symbols used on equipment and documentation comply with IEC 61010-1 II.
• SIMBOLO DIRECT CURRENT IEC 417, N° 5031
Vdc may be used on rating labels
• SIMBOLO ALTERNATING CURRENT IEC 417, N° 5032
For rating labels, the symbol is typically replaced by V and Hz as in 230V, 50Hz.
• SIMBOLO PROTECTIVE CONDUCTOR TERMINAL IEC 417, N° 5019
This symbol is specifically reserved for the
placed at the equipment earthing point and is mandatory for all grounded equipment
• SIMBOLO CAUTION ISO 3864, N°B.3.1
used to direct the user to the instruction manual where it is necessary to follow certain
specified instructions where safety is involved.
Rev. Note
1.0 First review
1.1 Added PTP master support
-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
SYNC-SWITCH – Manual – Rev 1.1
Simboli di sicurezza
Safety Symbols
PROTECTIVE CONDUCTOR TERMINAL
Changelog
4
and no other. It is
Data
28/10/2012
31/01/2014
