TS-ABX11
TS-AZX11
'
USER
S MANUAL
®
®
TM
Intel
Pentium
II / III
Series

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TS-ABX11 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Transcend TS-ABX11

Summary of Contents for Transcend TS-ABX11

  • Page 1 TS-ABX11 TS-AZX11 ’ USER S MANUAL ® ® Intel Pentium II / III Series...
  • Page 2 This is even if Transcend has been advised of the possibility of such damages arising from any defect or error in this manual or product.

  • Page 3: Table Of Contents

    1.2 Specifications and Features ................. 1 CHAPTER 2 HARDWARE INSTALLATION 2.1 Transcend’s TS-ABX11/TS-AZX11 Motherboard ..........3 2.2 Layout of Transcend’s TS-ABX11/TS-AZX11 Motherboard........4 2.3 CPU Installation ....................5 2.4 66/100MHz System Configuration..............8 2.5 CPU Internal Frequency Ratio Settings............8 2.6 Memory Configuration ...................
  • Page 4 CHAPTER 3 BIOS SETUP 3.1 BIOS Setup ......................18 3.2 The Main Menu ....................18 3.3 Standard CMOS Setup ..................20 3.4 BIOS Features Setup ..................23 3.5 Chipset Features Setup ..................26 3.6 Power Management Setup ................29 3.7 PnP/PCI Configuration Setup................33 3.8 Integrated Peripherals ..................

  • Page 5: Chapter 1 Introduction

    8~256MB memory capacity for TS-AZX11 - 8/16/32/64/128/256MB SDRAM DIMM for TS-ABX11 8/16/32/64/128MB SDRAM DIMM for TS-AZX11 - 64 data bits or 72 data bits (ECC) structure for TS-ABX11 64 data bits structure for TS-AZX11 • • • • • I/O BUS Slot - 1 AGP slot - 5 Master / Slave PCI-BUS slots (PCI 2.1 compliant) for TS-ABX11...

  • Page 6: Award Bios

    INTRODUCTION • • • • • I/O Functions - Supports PIO Mode 3, 4 ATAPI devices and Ultra DMA/33 - Supports 2 high speed UART 16550 COM Ports - Supports EPP/ECP LPT Port - Support s1.44/2.88 MB floppy drive - Supports PS/2 mouse and PS/2 keyboard - Supports IrDA port - Supports 2 Universal Serial Bus Ports - Supports Creative...

  • Page 7: Chapter 2 Hardware Installation

    ****5 PCI Slots Wake-on-LAN BIOS Intel PIIX4 Chipset Li Battery 2 ISA Slots Panel Connector * T:Top ** B:Bottom *** 3 DIMM Sockets for TS-ABX11, 2 DIMM Sockets for TS-AZX11 **** 5 PCI slots for TS-ABX11, 4 PCI slots for TS-AZX11...

  • Page 8: Layout Of Transcend's Ts-Abx11/Ts-Azx11 Motherboard

    Li Battery ***PCI Slot 5 (PCI5) Hardware Monitor ISA Slot 1 (ISA1) Panel Connector ISA Slot 2 (ISA2) *72 bits ECC structure is valid for TS-ABX11 only. **PCI slot 5 is present in TS-ABX11 only. ***DIMM3 is present in TS-ABX11 only.

  • Page 9: Cpu Installation

    HARDWARE INSTALLATION 2.3 CPU Installation •UNIVERSAL RETENTION MODULE (URM) INSTALLATION ON MODULE UNIVERSAL RETENTIO L O C K 1. Before installing the UNIVERSAL RETENTION MODULE, pull the supporting EARs 90 outward until you hear a “Click” and both EARs sit upright in the notches of the main body.
  • Page 10 HARDWARE INSTALLATION •The Intel Processor Type Intel Celeron Intel Pentium II Intel Pentium III Processor Processor Processor (S.E.P.P) (S.E.C.C) (S.E.C.C.2) A-(the Retention Mechanism) B-(the Processor Latches) NOTE:The retention mechanism must support your specific processor. Some retention mechanism may not support all processors. Contact your motherboard retailers or refer to your motherboard documentation if you have any questions.
  • Page 11 HARDWARE INSTALLATION •The Intel Processor Installation Step1: Install the Processor in Slot 1 Slide the processor into the URM assembly and insert it in Slot 1, while making sure that the heat sink assembly is facing towards the chipset, as shown in the figure. Press down firmly on the CPU until it is fully seated in the Slot 1 connector.

  • Page 12: 66/100Mhz System Configuration

    1 0 0 M H z 6 6 M H z A U T O TS-ABX11/TS-AZX11 66/100MHz FSB Configuration Jumper 2.5 CPU Internal Frequency Ratio Setting Switch 1 (SW1) is for adjusting the CPU internal frequency ratio. The frequency ratio is shown in the table overleaf.
  • Page 13 1 2 3 4 x 6.0 1 2 3 4 x 6.5 1 2 3 4 x 7.0 1 2 3 4 x 7.5 1 2 3 4 x 8.0 1 2 3 4 TS-ABX11/TS-AZX11 CPU Freq.-Ratio DIP Switch Setting...

  • Page 14: Memory Configuration

    768MBytes (max.) **Total Memory *DIMM3 is for TS-ABX11only. **768 MB is maximum for the TS-ABX11, while 256MB is maximum for the TS-AZX11. 3.3V Position Unbuffered Position 1 6 8 P i n S D R A M M o d u l e ( D I M M 1 )

  • Page 15: Keyboard Wake Up

    K B - A W K Disable Enable TS-ABX11/TS-AZX11 Keyboard Wake Up 2.8 Primary / Secondary IDE Connectors (Two 40-pin IDE) This motherboard supports two 40-pin IDE connectors marked as IDE1 (primary IDE channel) and IDE2 (secondary IDE channel). Each channel supports two IDE devices which makes a total of four devices.

  • Page 16: Floppy Disk Drive Connector

    Floppy Drive Connector F D C PIN1 TS-ABX11/TS-AZX11 Floppy Disk Drive Connector 2.10 Fan Power Connectors There are three fan power connectors on the motherboard: CPU-FAN, POWER-FAN, and CASE-FAN. Each connector provides +12V power. Make sure it is in the right orientation, or it may cause damage.

  • Page 17: Wake-On-Lan Connector

    +5 Volt Standby G r o u n d P M E TS-ABX11/TS-AZX11 Wake-on-LAN Connector 2.12 IrDA-Compliant Infrared Module Connector (5-pin IrDA) The IrDA connector can be configured to support a wireless infrared module. With this module and application software such as Laplink or Win95 Direct Cable Connection, users can transfer files to or from laptops, notebooks, PDA and printers.

  • Page 18: Panel Connectors

    R E S E T S P E A K E R S O F T _ O F F TS-ABX11/TS-AZX11 Panel Connectors Power LED Lead (3-pin KEYLOCK) This 3-pin connector attaches to the power LED. Pin1 : Pin2 :...

  • Page 19: Power Connector

    Make sure to plug the ATX power supply connector in the right direction. The pin definition is shown below. Make sure that your ATX power supply can support at least 720mA on the standby lead. P W R - C O N N PSON# : Power Supply on TS-ABX11/TS-AZX11 Power Connectors...

  • Page 20: External Connectors

    The serial port 1 is marked as “COMA”, and the serial port 2 is marked as “COMB”. 1. PS/2 Mouse 4. Parallel Port (Printer) 3. USB1 3. USB2 2. PS/2 Keyboard 5 . C O M B 5 . C O M A TS-ABX11/TS-AZX11 External Connectors...

  • Page 21: Clear Cmos Jumper

    To clear the CMOS data, you should turn off your computer’s power and short pin1 and pin2 of JP4. J P 4 C M O S _ C L R Default TS-ABX11/TS-AZX11 Clear CMOS Jumper 2.17 SB-Link Connector The SB-Link connector is used only for Creative ® PCI sound cards. If your sound card sup- ports this function, attach the SB-Link cable to this connector.

  • Page 22: Chapter 3 Bios Setup

    BIOS SETUP CHAPTER 3 BIOS SETUP 3.1 BIOS Setup Award BIOS has a built-in Setup program that allows users to modify the basic system configuration. This information is stored in CMOS RAM. It can retain the Setup information when the power is turned off. When the battery of CMOS fails, it will cause the data to be lost. If this happens, you should set up your configuration parameters again after replacing the battery.
  • Page 23 BIOS SETUP [ F1 ] General help, only for Status Page Setup Menu and Option Page Setup Menu [ F2 ] Change color from total 16 colors [ F2 ] to select color forward [ Shift ] + [ F2 ] to select color backward [ F3 ] Calendar, only for Status Page Setup Menu...

  • Page 24: Standard Cmos Setup

    BIOS SETUP • SUPERVISOR / USER PASSWORD Change, set, or disable a password. In some BIOS versions that allow separate user and supervisor passwords, only the supervisor password permits access to Setup. The user password generally allows only power-on access. •...
  • Page 25 BIOS SETUP 1. Match the specifications of your installed IDE hard drive(s) with the preprogrammed values for drive type 1 through 45. 2. Select “USER” and enter values into each drive parameter field. 3. Use the “IDE HDD AUTO DETECTION” function in Main Menu. Here are brief explanations of the drive specifications.
  • Page 26 BIOS SETUP • Drive A / Drive B Select the correct specifications for the diskette drive(s) installed in the computer. - None : No diskette drive installed - 360K, 5.25 in” : 5-1/4 inch PC-type standard drive; 360 kilobyte capacity - 1.2M, 5.25 in”...

  • Page 27: Bios Features Setup

    BIOS SETUP 3.4 BIOS Features Setup This “BIOS FEATURES SETUP” option allows you to improve your system performance and set up system features according to your preference. • Virus Warning When the function is enabled, you will receive a warning message if a program (specifically, a virus) attempts to write to the boot sector or the partition table of the hard disk drive.

  • Page 28: Processor Number Feature

    BIOS SETUP • Processor Number Feature This option is for the Intel Pentium III CPU. End users can choose to open or close it • CPU L2 Cache ECC Checking Select “Enabled” to make sure of data accuracy. • Quick Power On Self Test Select “Enabled”...

  • Page 29: Security Option

    BIOS SETUP • Typematic Rate (Chars / Sec) When the typematic rate setting is enabled, you can select a typematic rate (the rate at which character repeats) when you hold down a key of 6, 8, 10,12, 15, 20, 24 or 30 characters per second.

  • Page 30: Chipset Features Setup

    BIOS SETUP shadowing into each section of memory separately. Many system designers hardwire shadowing of the system BIOS and eliminate a System BIOS Shadow option. Video BIOS shadows into memory area C0000-C7FFF. The remaining areas shown on the “BIOS Features Setup” screen may be occupied by other expansion card firmware. If an expansion peripheral in your system contains ROM-based firmware, you need to know the address range the ROM occupies to shadow it into the correct area of RAM.
  • Page 31 BIOS SETUP • SDRAM RAS-to-CAS Delay This controls the latency between SDRAM active command and the read/write command. Leave on default setting. • SDRAM RAS Precharge Time This controls the idle clocks after issuing a precharge command to SDRAM. Leave on default setting.

  • Page 32: Delayed Transaction

    BIOS SETUP • Memory Hold At 15M-16M Enabling this feature reserves memory address space from 15MB to 16MB to ISA expansion cards that specifically require this setting. This makes the memory from 15MB and up unavailable to the system. Expansion cards can only access memory up to 16MB. The default is “Disabled”.

  • Page 33: Power Management Setup

    BIOS SETUP 3.6 Power Management Setup The Power Management Setup allows you to configure your system to save energy most effectively while operating in a manner consistent with your own style of computer use. • ACPI function This item allows you to enable/disable the Advanced Configuration and Power Management (ACPI).

  • Page 34: Pm Control By Apm

    BIOS SETUP 2. Min. Power Saving : Minimum power management mode. Inactivity peroid is defined as below. Doze Mode = 1 hr. Standby Mode = 1 hr. Suspend Mode = 1 hr. HDD Power Down = 15 min. 3. Max. Power Saving : Maximum power management mode. Inactivity period is defined as below.

  • Page 35: Standby Mode

    BIOS SETUP • Video Off After Select the power-saving modes during which the monitor goes blank. Doze : Monitor remains “on” during Doze modes. Suspend : Monitor blanked when system enters Suspend mode. N/A : It is default. When system enters power-saving mode, it does not do the video off action.

  • Page 36: Reload Global Timer Events

    BIOS SETUP • LAN Wake Up This allows you to remotely power up your system through your network by sending a wake up frame or signal. NOTE: This feature requires a network interface and an ATX power supply with at least 720mA +5 V standby power.

  • Page 37: Pnp/Pci Configuration Setup

    BIOS SETUP 3.7 PnP/PCI Configuration Setup This section describes configuring the PCI bus system. PCI (Personal Computer Interconnect) is a system which allows I/O devices to operate at speeds nearing the speed that CPU itself uses when communicating with its own special components. This section covers some very technical items and it is strongly recommended that only experienced users make any changes.

  • Page 38: Reset Configuration Data

    BIOS SETUP • Reset Configuration Data Normally, you leave this field “Disabled”. Select “Enabled” to reset Extended System Configuration Data (ESCD) when you exit “Setup”, if you have installed a new add-on and the system reconfiguration has caused such a serious conflict that the operating system cannot boot.

  • Page 39: Integrated Peripherals

    BIOS SETUP 3.8 Integrated Peripherals This option will load the default BIOS values. Choose the option and the following message appears. • • • • • IDE HDD Block Mode The item means HDD access uses over one cycle method for improving HDD performance. If the HDD supports this function, choose”...

  • Page 40: Init Display First

    BIOS SETUP • • • • • On-Chip IDE Primary / Secondary PCI IDE The chipset contains a PCI IDE interface which supports two IDE channels. Select “Enabled” to activate the first and/or second IDE interface. Select “Disabled” to deactivate an interface, if you install a primary and/or secondary add-in IDE interface.
  • Page 41 BIOS SETUP • • • • • Onboard Serial Port The second serial port shares resources (address and IRQ) with IrDA. • • • • • UART Mode Select Normal : Normal operation IrDA : IrDA compliant serial infrared port ASKIR : Amplitude shift keyed infrared port •...

  • Page 42: Supervisor Password

    BIOS SETUP 3.9 Supervisor Password This option will set the password to prevent others from making changes to your system. Password prevents unauthorized use of your computer. If you set a password, the system prompts for the correct password before you boot or access to “Setup” To set a password: 1.

  • Page 43: User Password

    BIOS SETUP 3.10 User Password This option will set the password to prevent others from making changes to your system when accessed by POWER ON. This operation is same as SUPERVISOR PASSWORD. 3.11 IDE HDD Auto Detection Use the BIOS utility to detect the HDD type automatically. Press “Y” to accept, “N” to reject, and “ESC”...

  • Page 44: Save & Exit Setup

    BIOS SETUP 3.12 Save & Exit Setup Save the setting and exit the BIOS utility. 3.13 Exit Without Saving Abort the current change and exit the BIOS utility.

  • Page 45: Load Bios Defaults

    BIOS SETUP 3.14 Load BIOS Defaults NOTE: This option allows you to load the troubleshooting default values permanently stored in the BIOS ROM. These default settings are non-optimal and disable all high performance features. 3.15 Load Setup Defaults This option allows you to load the default values to the system configuration fields. These default values are the optimized configuration settings for the system.

  • Page 46: Chapter 4 Bios Upgrade

    BIOS.) 4.2 Download Correct BIOS File from Web Please enter Transcend is website : http://www.transcendusa.com. Choose BIOS upgrade environment. The BIOS file name consists of 5 characters. Check the exact BIOS to download. Your BIOS file name must exactly match the one shown on our web.

  • Page 47: How To Update Your Motherboard Bios

    BIOS UPGRADE 4.3 How to Update Your Motherboard BIOS Please follow these 5 steps listed below to update your BIOS. Step 1: Make a record of your original or existing BIOS Setup parameters. - Press [Del] during the Power On Self Test to enter BIOS Setup Program when you start your system.
