APM -24005G-1 Specification Sheet

APM-24005g-1
AP Specification
Standards Compliance
SDRAM
Flash
Radio Frequency Type
Modulation
Frequency Band
Transmission Power
Transmission Rate
Access Point Interfaces
Sensitivity
Antenna Type
Security Systems
Wireless Setting
Operating Environment
Power
22F-6, No.180, Jingping Rd, Jhonghe City, Taipei County 23581, Taiwan, R.O.C.
www.apm.com.tw apm.sales@msa.hinet.net
IEEE802.11b/g; IEEE802.3; IEEE802.3u
8 M Byte
2 M Byte
DSSS / OFDM
IEEE 802.11b: CCK,DQPSK,DBPSK
IEEE 802.11g: OFDM with BPSK, QPSK, 16QAM, 64QAM
America/FCC: 2.412~2.462 GHz (11 channels)
Europe CE/ETSI: 2.412~2.472 GHz (13 channels)
IEEE 802.11b: 14dBm
IEEE 802.11g: 14dBm
IEEE802.11b: 1/ 2/ 5.5/ 11 Mbps
IEEE802.11g: 6/ 9/ 12/ 18/ 24/ 36/ 48/ 54 Mbps
Super G: up to 108Mbps
Auto MDI/MMDI-X Ethernet 10/100Base-TX: RJ-45
-86dBm @ 11Mbps,PER< 8%;-64dBm @ 54Mbps,PER< 10%
Integrated 6 dBi flat panel antenna
64-bit/128-bit/152-bit/ WEP encryption and Wi-Fi Protected Access(WPA)
Operation Mode-AP/Wireless Client/Repeater/Bridge(WDS)PtP
and PtMP Mode
Operating Temperature: -10 ~ +70°C
DC 12 Volt + 5%; 1.5A (Max.); AC adapter AC 100V ~ 240V
Tel: +886 2 89431966
APM CO., LTD
Fax: +886 2 89434944
1 of 2
