APM -24005G Specification Sheet

APM-24005g
AP Specification
Standards Compliance
SDRAM
Flash
Radio Frequency Type
Modulation
Frequency Band
Transmission Power
Transmission Rate
Access Point Interfaces
Sensitivity
Antenna Type
Security Systems
Wireless Setting
Operating Environment
Power
22F-6, No.180, Jingping Rd, Jhonghe City, Taipei County 23581, Taiwan, R.O.C.
www.apm.com.tw apm.sales@msa.hinet.net
IEEE802.11b/g; IEEE802.3; IEEE802.3u
8 M Byte
2 M Byte
DSSS / OFDM
IEEE 802.11b: CCK,DQPSK,DBPSK
IEEE 802.11g: OFDM with BPSK, QPSK, 16QAM, 64QAM
America/FCC: 2.412~2.462 GHz (11 channels)
Europe CE/ETSI: 2.412~2.472 GHz (13 channels)
IEEE 802.11b: 20dBm
IEEE 802.11g: 20dBm
IEEE802.11b: 1/ 2/ 5.5/ 11 Mbps
IEEE802.11g: 6/ 9/ 12/ 18/ 24/ 36/ 48/ 54 Mbps
Super G: up to 108Mbps
Auto MDI/MMDI-X Ethernet 10/100Base-TX: RJ-45
-86dBm @ 11Mbps,PER< 8%;-64dBm @ 54Mbps,PER< 10%
Integrated 12 dBi flat panel antenna
64-bit/128-bit/152-bit/ WEP encryption and Wi-Fi Protected Access(WPA)
Operation Mode-AP/Wireless Client/Repeater/Bridge(WDS)PtP
and PtMP Mode
Operating Temperature: -10 ~ +70°C
DC 12 Volt + 5%; 1.5A (Max.); AC adapter AC 100V ~ 240V
Tel: +886 2 89431966
APM CO., LTD
Fax: +886 2 89434944
1 of 2
