Broadband Wireless Outdoor Solutions
(AP/ Wireless Client /Repeater/Wireless Bridge)
Model No:
●
Wireless LAN IEEE802.11b/g compliant
●
Solid housing provides protection against rigorous weather conditions IP68 compliant
●
Four operating modes support: AP ,Wireless Client ,Repeater and Wireless Bridge
●
Strong network security with 64/128/152-bit WEP encryption and WPA
One detachable N-type male connectors can connect to external high gain antenna for expanding
●
connection distance
●
Provides "RSSI" indication for AP, Repeater and Wireless Bridge
●
Power over Ethernet design IEEE802.3af compliant
Spectifications
Standards Compliance
SDRAM
Flash
Radio Frequency Type
Frequency Band
Transmission Power
ABR-2410gM
IEEE802.11b/g; IEEE802.3af; IEEE802.3; IEEE802.3u
8 M Byte
2 M Byte
DSSS / OFDM
America/FCC:2.412~2.462GHz(11 channels)
Europe CE/ETSI:2.41~2.472 GHz(13 channels)
IEEE802.11b/g:30dBm
Advertisement
Related Manuals for APM ABR-2410gM
Summary of Contents for APM ABR-2410gM
- Page 1 Broadband Wireless Outdoor Solutions (AP/ Wireless Client /Repeater/Wireless Bridge) Model No: ABR-2410gM ● Wireless LAN IEEE802.11b/g compliant ● Solid housing provides protection against rigorous weather conditions IP68 compliant ● Four operating modes support: AP ,Wireless Client ,Repeater and Wireless Bridge ●...
- Page 2 Transmission Rate IEEE802.11b:1/2/5.5/11 Mbps IEEE802.11b/g:6/9/12/18/24/36/48/54 Mbps Super g: up to 108 Mbps Access Point Interfaces Auto MDI/MMDI-X Ethernet 10/100Base-TX: RJ-45 Radio Wave:Antenna N-Male Sensitivity -86dBm @ 11Mbps,PER< 8%;-64dBm @ 54Mbps,PER< 10% Connector Type N-type male Security Systems 64-bit/128-bit/152-bit/ WEP encryption and Wi-Fi Protected Access(WPA) Wireless Setting Operation Mode-AP/Wireless Client/Repeater/Bridge(WDS)PtP...
- Page 3 Standard Accessories...
