APE-502401a-1
AP Specification
Standards Compliance
SDRAM
Flash
Radio Frequency Type
Modulation
Frequency Band
Transmission Power
Transmission Rate
Access Point Interfaces
Sensitivity
Antenna Type
Security Systems
22F-6, No.180, Jingping Rd, Jhonghe City, Taipei County 23581, Taiwan, R.O.C.
www.apm.com.tw apm.sales@msa.hinet.net
IEEE 802.11a
IEEE 802.3
IEEE 802.3u
IEEE 802.3af
32 M Byte
8 M Byte
DSSS/ OFDM
IEEE 802.11a : OFDM with BPSK, QPSK, 16QAM, 64QAM
IEEE 802.11a:
5.15 ~ 5.25 GHz (lower band)
5.25 ~ 5.35 GHz (middle band)
5.725 ~ 5.825 GHz (hi-band)
Frequency can be adjusted from software
IEEE 802.11a: 20 dBm
IEEE 802.11a: 6/ 9/ 12/ 18/ 24/ 36/ 48/ 54 and 108Mbps
Auto sensing MDI/MDI-X Ethernet 10/100Base-TX: RJ-45
IEEE 802.11a: -70dBm @ 54Mbps, PER<10%
Integrated 15dBi 5.0GHz flat panel antenna
64-bit/ 128-bit/ 152-bit WEP encryption; Wi-Fi Protected Access
(WPA) and WPA2
Tel: +886 2 89431966
APM CO., LTD
Fax: +886 2 89434944
1 of 2
Advertisement
Related Manuals for APM APE-502401a-1
Summary of Contents for APM APE-502401a-1
- Page 1 Security Systems 64-bit/ 128-bit/ 152-bit WEP encryption; Wi-Fi Protected Access (WPA) and WPA2 22F-6, No.180, Jingping Rd, Jhonghe City, Taipei County 23581, Taiwan, R.O.C. www.apm.com.tw apm.sales@msa.hinet.net APM CO., LTD Tel: +886 2 89431966 Fax: +886 2 89434944 1 of 2...
-
Page 2: Standard Accessories
Standard Accessories 25M Cable Bracket Kit (U Bolt) 22F-6, No.180, Jingping Rd, Jhonghe City, Taipei County 23581, Taiwan, R.O.C. www.apm.com.tw apm.sales@msa.hinet.net APM CO., LTD 2M Cable Power over Ethernet Tel: +886 2 89431966 Fax: +886 2 89434944 2 of 2...
