Summary of Contents for Janus V2

  • Page 2: Table Of Contents

    Contents 1. Features and Function 2. Warnings and cautions 3. Product contents 4. Product specification 5. Installation guide 6. Exclusive viewer 7. Firmware upgrade 8. Setup 9. User directions 2page...

  • Page 3: Features And Function

    1. Features and function Thanks for using JANUS V2 1.0.0 It integrates the vehicle DVR system with leading-edge technology, GPS to create the new generation vehicle surveillance system. This state of art system not only records H.264 video and CD quality audio, but also manage events happening on vehicle.

  • Page 4: Warnings And Cautions

    2. Warnings and Cautions Don’t try to insert or Do not clean the unit put unknown with water or volatile substance into unit. solvent.(can be damaged (Might cause a fire the product or might Or electric shock.) cause of fire or electric shock Do not segregate or open the unit and remodel it.

  • Page 5: Product Contents

    3. Product contents JANUS V2 Power cable/Cigar jack Emergency Bracket Extension Button User Manual and Install CD If any of these items is missing or damaged, notify your dealer or installer immediately. Keep the packing utilities for moving or storage purposes afterwards.
  • Page 6 IR LED SDHC memory card insert CDS sensor Monitor connection Recording LED GPS connection GPS LED Channel switch button POWER LED Power cable connection Emergency Button 6page...

  • Page 7: Product Specification

    4. Product Specification Contents Specification Camera 0.3 Mega Pixel CMOS Lens 175° Wide Lens Audio Inner MIC Emergency Internal / External button Button G-Sensor (Outer GPS) Sensor Vibration Sensor installed (Impact detection) Memory SDHC Power DC 7 ~ 26V 7 page...
  • Page 8 Specifications 2EA CMOS Built-in Camera Digital 2ch built-in Video Input C- MIC built-in Audio Input /Output H.264 Video Compression ADPCM Audio Compression VGA 640X480, CIF 320 x 240 Recording Resolution Recording Speed Max.50fps (CH/25fps) Emergency Event Switch Urgent, event detect and recording Vibration Sensor Impact, event detect and recording Over speed, sudden accelerate, detect and recording...

  • Page 9: Installation Guide

    2. Connect with JANUS V2 ‘Video OUT’ component to display monitor’s (or Navigation LCD) ‘Video INPUT’ component. (Yellow is video, red is audio) 3. Connect with cigar power cable to JANUS V2 power Component (DC 7~26V) for operation the unit.
  • Page 10 5. Please check the images from the monitor and try to find the right place to stick JANUS V2 on. (Sticker on the back of the bracket is very adhesively.) 6. Connect GPS module to the JANUS V2 and locate the right place in. GPS Module...
  • Page 11 7. Connect external emergency button to JANUS V2 and locate external emergency button to near the driver’s seat 11 page...
  • Page 12 JANUS V2 Viewer installation guide (Korean and English are provided) 1. Run JANUS V2 EXE file from the Installation CD. 2. Click next for next step.. 12page...
  • Page 13 3. After finish the installation click JANUS V2 Icon on desktop. 4. Put ID and PASSWORD before using. 13 page...

  • Page 14: Exclusive Viewer

    6. Exclusive Viewer (JANUS V2 Player) Configuration Open file Close Save Steal shot File list See E-map Play button Volume control Auto-meter Channel play mode button Speed control bar 14page...
  • Page 15 6-1. Button Operation 6-1-1. Main buttons (1~5) 1. Open configuration 2. Close 3. Open recorded file 4. Saving steal cut image 5. Open map (Location coordinates will be shown when you play the file) 6-1-2. Play buttons (6) Move to first data Play Backward Pause Play...
  • Page 16 6-1-3. Play Channel Play 640 x 480 modes each channel Play 320 x 240 modes with 2 channels Screen Double Click!! Channel No. 1 and No. 2 can be showing at the same time 16page...
  • Page 17 Screen Double Click!! Screen Double Click!! When you double click on the image you can see full screen. 17 page...
  • Page 18 6-2. Play list List will be shown event by each categories such as ‘Normal’ ‘ Emergency’ ‘Impact’ ‘Over speed’ Recorded files are marked as year/month/day/hour/minute/second. 18page...
  • Page 19 6-3. Map Link See E-map : E-map and location will be provided when click map button. Whenever network is connected you can see an e-map (google map is provided) 19 page...
  • Page 20 6-4. Configuration Open Configuration System.cfg JANUS V2 Version 1.0.0 must to choose the ‘system cfg’. file in order to open and change configuration 20page...
  • Page 21 6-4-1. Setup 1. Frame : Setup recording frames (Available setup for each channel) 2. Event frame : Setup frames of event occurs. (Pre-Alarm and Post Alarm) Pre-Alarm – 2 ~ 5 seconds to adjustable before event. Post-Alarm – 10 ~ 30 seconds to adjustable after event. 3.

  • Page 22: Firmware Upgrade

    6-4-2. User configuration 1. Car Info : Vehicle’s information 2. Driver Info: Driver’s information 3. User ID : JANUS V2 user ID 4. Password: JANUS V2 user password. 5. Version : JANUS V2 Version information 7. Firmware upgrade 22page...
  • Page 23 All the JANUS V2 upgrades and configuration are automatically upgrade by SD memory card. Firmware upgrade Please visit (www.JANUS V2page.com) and download the firmware. (www.JANUS V2page.com -> Support -> JANUS V2 support -> Download) 1. Take out SD memory card 2.

  • Page 24: Setup

    8. Setup Changed setup will be applied when the JANUS V2 is boot up. 1. Take out SD memory card 2. Insert SD memory card into PC from the JANUS V2 3. Run JANUS V2 Viewer 4. Changing the setting on configuration 6.

  • Page 25: User Directions

    JANUS V2. (It might be a cause of damage if SD memory card get out in sudden when power on) Be sure backup the data before over written data. JANUS V2 will be overwritten when the memory is full. 25 page...
  • Page 26 Caution and Warning Caution: Any changes or modification in construction of this device which are not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class a digital device, purchase to part 15 of the FCC Rules.
