- Page 1 9100SXT Meter Initiated Water Softener OPERATION MANUAL WQA Tested and Certified against CSA B483.1 This manual contains important maintenance procedures for the continued proper operation of your unit. These MUST be performed regularly for your guarantee to remain valid. #54746WQA 3/11...
- Page 3 308 (139) 320 (145) *Items include brine tank grid • Capacities are based on two tanks of resin. Ex: DT30TM, 9100SXT set at 6lb/cf selt setting would provide 23,000 grains of Working Temperature = 34-110°F (1-43°C) hardness removal for one tank.
- Page 4 Control Operation During Programming The control will only enter the Program Mode with the valve in Service. While in the Program Mode, the control will continue to operate normally, monitoring water usage and keeping all displays up to date. Control programming is stored in memory permanently, eliminating the need for battery back-up power.
-
Page 5: Installation Instructions
Installation Instructions All government codes and regulations governing the installation of these devices must be observed. CAUTION: If the ground from the electrical panel or breaker box to the water meter or underground copper pipe is tied to the copper water lines and these lines are cut during installation of the Noryl bypass valve and/or poly pipe, an approved grounding strap must be used between the two lines that have been cut in order to maintain continuity. - Page 6 Figure 3 4. Attach the bypass valve to the control valve. Connect the inlet and outlet of the water softener to the plumbing in the house. The control valve must not be submitted to temperatures above 43°C (110°F). When sweat fittings are used, to avoid damaging the control valve, solder the threaded copper adapters to the copper pipe and then, using Teflon tape, screw the assembly into the bypass valve.
-
Page 7: Drain Line Connection
Drain Line Connection NOTE: Waste connections or drain outlet shall be designed and constructed to provide for connection to the sanitary waste system through an air-gap of 2 pipe diameters or 1 inch (22 mm) whichever is larger. WARNING: Never insert drain line directly into a drain, sewer line, or trap. Always allow an air gap between the drain line and the wastewater to prevent the possibility of sewage being back-siphoned into the conditioner. -
Page 8: Set Time Of Day
Operating Instructions Figure 4 The valve has been pre-programmed with factory settings as follows: Regeneration Cycle Step Programming 1. Backwash ........10 minutes 2. Brine Rinse ........60 minutes 3. Rapid Rinse ........10 minutes 4. Brine Refill ........06 minutes – DT20TM 08 minutes – DT30TM 10 minutes –... - Page 9 User Programming Mode Options Abbreviation Parameter Description Day Override The timer’s day override setting THIS IS AN OPTION ONLY. PLEASE DO NOT ADjUST BEFORE CONSULTING AN AUTHORIzED DEALER. Feed Water Hardness The hardness of the inlet water - used to calculate system capacity for metered systems Reserve Capacity The fixed reserve capacity...
-
Page 10: Error Codes
Error Codes Note: Error codes appear on the In Service display Error Code Probable Cause Recover and Resetting [Err 0] Drive motor is stalled Unplug the unit from the power source [Err 1] Drive motor is running continuously When power is restored to the unit, the Err _ display code clears. - Page 11 Manual Regeneration Cycle If you run out of softened water because of inadequate regeneration frequency, inadequate reserve capacity, power failure or unusually high water usage, you can initiate a manual regeneration simply by pressing the extra cycle button. The softener will now automatically complete a regeneration cycle and return to service. If possible, avoid water use during the regeneration cycle.
-
Page 12: Maintenance Instructions
Maintenance Instructions Checking the Salt Level Check the salt level monthly. Remove the lid from the cabinet or brine tank, make sure salt level is always above the brine level (you should not be able to see water). Adding Salt Use only clean salt labeled for water conditioner use, such as crystal, pellet, nugget, button or solar. -
Page 13: Parts Breakdown
ToP VIEW - BrInE TAnk BrInE TAnk Resin Brine Tank Valve Tank Distributor Brine Grid Resin Model # #21501 DT20TM, 9100SXT 100283 91001-08 100008-2 (2) 19478 (2) 1.5 CF DT30TM, 9100SXT 100283 91001-08 100016-2 (2) 19478 (2) 2.0 CF DT40TM, 9100SXT... -
Page 14: Troubleshooting Guide
Trouble Shooting Guide Problem Possible Solutions 1. CONDITIONER DELIVERS HARD WATER A. Bypass valve is open A. Close bypass valve B. No salt in brine tank B. Add salt to brine tank and maintain salt level above water level C. Injector or screen plugged C. -
Page 16: General Provisions
Novatek assumes no responsibility for consequential damage, labor or expense incurred as a result of a defect or for failure to meet the terms of these guarantees because of circumstances beyond its control. Contact your local distributor: WATERGROUP INC. WATERGROUP COMPANIES INC. FRIDLEY, MN REGINA, SK • CAMBRIDGE, ON 1-800-354-7867 1-877-288-9888 www.watergroup.com...
