Page 1: Operating Instructions
Automatic Pool Cleaner Installation and Operating Instructions Please pass these instructions on to the operator of this equipment. E-mail: sales@davey.com.au Website: davey.com.au... -
Page 2: Table Of Contents
Automatic Pool Cleaner Congratulations on the purchase of your Davey Frill-NeckWIZARD ® automatic pool cleaner. Your new Frill-NeckWIZARD has been designed ® for hassle-free surface maintenance of all popular above and below ground pools, so you can simply relax and enjoy swimming in a clean pool! INDEX: Packing List .................... -
Page 3: Packing List
8. Alternative ‘Slippery Surface’ Footpad 9. Automatic Weir Valve 10. 2 x 45º Angle Joints 11. Universal Weir Adaptor 12. Flow Meter Flow Rate Requirement For optimum cleaning performance, your Frill-NeckWIZARD automatic pool ® cleaner requires 60-70 litres per minute (lpm) of flow from the pool pump. Your Frill-NeckWIZARD Pool Cleaner ®... - Page 4 2. Surface Cleaning Frill and Footpad: Captures debris from the pool floor in the vacuum field whilst scrubbing the pool floor clean. Cleaning Frill Foot Pad 3. Deflector Ring: Assists the Frill-NeckWIZARD in negotiating steps, ® tight corners and ladders. Can be set at different heights on the bumper. 4. Bumper: Protects the extension pipe from damage whilst providing provision for the attachment of the deflector wheel.
-
Page 5: Step1: Pre-Installation Of Your Frill-Neckwizard
Step 1: Pre-installation of your Frill-NeckWIZARD Pool Cleaner ® Before you begin to install the Frill-NeckWIZARD it is important you have ® a basic understanding of how the pool water flows from the skimmer, through the pool pump and filter returning to the pool. Below is a diagram of a typical pool with standard equipment showing how the water usually flows. If you are still unsure, simply refer to your local pool professional for assistance. Step 2: Preparing your Pool for the Frill-NeckWIZARD ®... -
Page 6: Step 3: Assembling The Cleaning Head
If the furthest point from the skimmer box is the steps, use the lowest step as the furthest point. NOTE: If you require extra lengths, please contact your Frill-NeckWIZARD ® dealer and refer to spare parts code on page 15. -
Page 7: Step 5: Setting Up The Skimmer Box Connection
C. Connect 2 x 45 elbows to the weir adaptor and insert the weir valve into it. Ensure the “Water Flow” arrow on the side of the valve is pointing towards the skimmer plate and the valve bypass flap is pointing downwards. Step 6: Checking the Flow Use the flow meter supplied to measure the flow going through your Frill-NeckWIZARD before you attach the cleaning head. ® A. Attach the flow meter to the first length of hose (that connects to the cleaning head). B. Feed the cleaner hose vertically in to the pool so that it fills with water. -
Page 8: Step 7: Connecting The Frill-Neckwizard
® to allow any air to escape (bubbles will be released) C. Push the male cuff end of the hose firmly onto the outer extension pipe of the cleaner head of the Frill-NeckWIZARD ® D. Connect female cuff (fitted with hose protector) to the weir valve. E. Lower the cleaner head gently and gradually into the pool F. Switch the pump on and watch the WIZARD clean like magic! - Page 9 PERFORMANCE CAUSE CORRECTION The WIZARD is moving too fast Adjust springs on and / or is climbing above Too much suction automatic weir water level valve to Low setting The WIZARD is moving too Adjust springs on slowly and / or not climbing Not enough suction automatic weir the low walls...
-
Page 10: Caring For Your Frill-Neckwizard
® around the pool. Maintenance & Service Tips Operating Time: It is good practice to operate your Frill-NeckWIZARD ® the amount of time required to clean your pool only, to maximise the life of the product. Ladder (Above Ground Pools): To prevent Frill-NeckWIZARD being ®... - Page 11 Protect the Frill-NeckWIZARD : When not in use, store in a safe, shaded ® area with the hoses laid straight. Removing trapped debris from the Engine Unit: Removing trapped debris is simple. A. Recover the cleaner head and rotate it while still submerged in the water to show the underside and throat.
- Page 12 C. Remove the end cap. D. Use your finger to angle the engine unit slightly down and then remove it. RUBBER BALL REPLACEMENT A. Pull the clear Fastening / Wear Ring down, away from the ball. Be careful not to damage the ring. B. Peel the ball off the engine unit by lifting it from the seal lip. C.
-
Page 13: Troubleshooting
Troubleshooting Problem 1: Frill-NeckWIZARD is not working/moving too slowly: ® Cause Solution / Action Pump not Check if the pump is ON and / or primed. If not, turn ON switched on and wait for it to prime Remove obstruction from engine unit. See maintenance... -
Page 14: Accessories
Ensure the hoses are not damaged. Accessories Part Description Davey Code Is installed on to the hose and is designed to assist the Frill-NeckWIZARD Large Deflector Ring 32605 in avoiding stairs, difficult corners or ladders in above ground Pools. Is installed on the hose line and catches large leaves and debris... -
Page 15: Spare Parts
Spare Parts Part Davey Code Surface Cleaning Frill 401819 Standard Footpad (Silver) 401820 Footpad for slippery surfaces (Dark Silver) 401821 Bumper 401822 Deflector Ring 401827 Engine Unit M5958 Engine Rubber Ball M5959 Ball Ring M5970 Grey Cleaner Hose x 12 M5910ST... -
Page 16: Davey Water Products Guarantee
DAVEY WATER PRODUCTS GUARANTEE FOR AUSTRALIA & NEW ZEALAND This Davey product is guaranteed to be free of material or manufacturing defects at the time of original purchase. Should the cleaner head fail as a result of such defects within 3 years from the original purchase, the product will be repaired free of charge.
