MSS APE 50 (2012) MANUALE STAZIONE DI SERVIZIO Questo manuale per stazioni di servizio è stato realizzato da PIAGGIO & C. Spa per essere utilizzato dalle officine dei concessionari e sub-agenzie Piaggio. Si presuppone che chi utilizza questa pubblicazione per la manutenzione e la riparazione dei veicoli Piaggio, abbia una conoscenza base dei principi della meccanica e dei procedimenti inerenti la tecnica della riparazione dei veicoli.
Page 4
Safeguarding the environment Sections marked with this symbol indicate the correct use of the vehicle to prevent damaging the environment. Vehicle intactness The incomplete or non-observance of these regulations leads to the risk of serious damage to the vehicle and sometimes even the invalidity of the guarantee. Tracking ID-422/tukxi/04/2013...
Page 5
INDEX OF TOPICS ENERAL GUIDELINES HARACTERISTICS PECIAL TOOLS AINTENANCE CO EM MISSION ONTROLO YSTEM TROUBL ROUBLESHOOTING LECTRICAL SYSTEM NGINE FROM VEHICLE NGINE IFFERENTIAL RAKING SYSTEM TEERING COLUMN USPENSIONS HASSIS DELIVERY TEMP SHEET Tracking ID-422/tukxi/04/2013...
Page 6
INDEX OF TOPICS ENERAL GUIDELINES Tracking ID-422/tukxi/04/2013...
Maintenance guidelines Use original PIAGGIO spare parts and lubricants recommended by the Manufacturer. Non-original or non-conforming spares may damage the vehicle. Use only the appropriate tools designed for this vehicle. Always use new gaskets, sealing rings and split pins upon refitting.
Page 8
INDEX OF TOPICS HARACTERISTICS Tracking ID-422/tukxi/04/2013...
Page 9
MSS APE 50 (2012) Characteristics Identification The identification registration numbers are made up of a prefix that identifies the vehicle type and a progressive number punched on the chassis and engine. These numbers must always be quoted in the spare parts requests. It is advisable to check that the identification reg- istration numbers on the vehicle and on the engine correspond with those indicated in the vehicle reg-...
Page 10
MSS APE 50 (2012) Characteristics 7. Country of production. COLOUR LABEL: This colour label indicates: 1. Original paintwork manufacturer 2. Paintwork colour 3. Paintwork code Characteristics SIZES millimetres (mm) CROSS LONG Deck SHORT deck Length 2660 2700 2660 2490 2500 Width 1260 1260...
MSS APE 50 (2012) Characteristics SIZES - LOAD COMPARTMENT - APE 50 EUROPE 2 - APE 50 Sizes (mm) Long deck Short deck Cross Top long deck base base (8) Length 1427 1257 1257 1427 1422 (9) Width 1211 1211 1211 1211 1262...
MSS APE 50 (2012) Characteristics Specification Desc./Quantity N.B.: THERE ARE 3 SPEEDS IN THE VERSION WITH SPEED LIMITED TO 25 km/h. Differential Connected to the gearbox shaft by cylinder gears, planetary and satellite gears are bevel. The differential box is connected to the two axle shafts that transmit the motion to the wheels.
Page 14
MSS APE 50 (2012) Characteristics Name Torque in Nm Clutch assembly locking nut 40 ÷ 45 Nm Fan flywheel locking nut 45 to 50 Nm Filler joint fixing nuts 5 to 7 Nm Nuts fixing the exhaust pipe to the cylinder 5 to 7 Nm Clutch cover fixing bolts 6 to 8 Nm...
Page 15
MSS APE 50 (2012) Characteristics 060824Y Probe Cylinder-piston oversizes CYLINDER - PISTON Specification Desc./Quantity Normal cylinder nominal sizes Ø=38.40 +0.025 - 0.005 Normal piston nominal sizes Ø=38.265 ±0.015 CYLINDER COUPLING - PISTON Name Initials Cylinder Piston Play on fitting Coupling 1st Oversize 38.600 to 38.620 38.455 to 38.475...
Page 17
INDEX OF TOPICS PECIAL TOOLS Tracking ID-422/tukxi/04/2013...
Page 18
MSS APE 50 (2012) Special tools Tooling PECIAL TOOLS Stores code Description 014499Y Bearing extractor 016029Y Lower Steering Bearing Fitting Tool on the steering tube 017104Y Pliers for circlips 018119Y Axle Fitting Tool 020004Y Steering seats extraction punch 020042Y Steering tube bearing extractor ST - 18 Tracking ID-422/tukxi/04/2013...
Page 19
MSS APE 50 (2012) Special tools Stores code Description 020043Y Rear Wheel Hub Roller Bearing Fitting Punch 020044Y Front Wheel Hub Roller Bearing Fitting Punch 020055Y Steering Ring Nut Key 020057Y Tool for Starter Motor Bushing Calking 020074Y Crankshaft Alignment Check Tool 020119Y Flywheel extractor 020120Y...
Page 20
MSS APE 50 (2012) Special tools Stores code Description 020121Y Punch for Flywheel Side Secondary Shaft Roller Bearing 020123Y Valves Sealing Rings Punch 020125Y Punch to Fit Sealing Rings 020126Y Clutch Stop Key 020127Y Transmission Spider Calking Punch 020128Y Tool to Fit Sealing Rings 020129Y Engine Clearance Gear Check Tool ST - 20...
Page 21
MSS APE 50 (2012) Special tools Stores code Description 020130Y Punch to Fit Roller Casing of Main Shaft, Flywheel Side Crankcase Half 020131Y Flywheel lock tool 020132Y Gearbox Shaft Shimming Gauge 020133Y Tappet plates replacement tool 020144Y Primary Sprocket Lock 020147Y Flywheel Cone Extractor 020150Y...
Page 22
MSS APE 50 (2012) Special tools Stores code Description 020151Y Heat gun 020161Y Differential Box Extractor 020322Y Clutch Removal 020781Y Bearings Fitting Punch 020842Y Upper Steering Bearing Removal Punch 021071Y punch to fit bearings and sealing rings 021330Y Steering seats fitting tool ST - 22 Tracking ID-422/tukxi/04/2013...
Page 23
MSS APE 50 (2012) Special tools Stores code Description 021467Y Bearing extractor 022465Y Pliers for circlips 023638Y Pliers for circlips 009551Y Clutch puller 029569Y Gear Engagement Fitting Tool 030250Y Clutch Stop Key 032975Y Punches for Roller Casings ST - 23 Tracking ID-422/tukxi/04/2013...
Page 24
MSS APE 50 (2012) Special tools Stores code Description 033970Y Punches for Roller Casings 038077Y Engine support 038137Y Rear Hub Extractor 038138Y Roller Casings Punch 048564Y Flywheel extractor 060824Y Probe 020095Y Flywheel Lock 020332Y Digital rev counter 494929 Exhaust fumes analyser 021330Y003 Steering seats fitting 021330Y004...
Page 25
MSS APE 50 (2012) Special tools Stores code Description 018119Y015 Axle fitting 021467Y009 extractor 021467Y013 extractor ST - 25 Tracking ID-422/tukxi/04/2013...
Page 26
INDEX OF TOPICS AINTENANCE Tracking ID-422/tukxi/04/2013...
Page 27
MSS APE 50 (2012) Maintenance WINDSCREEN WASHER FLUID TOP-UP - APE Inside the passenger compartment in the front left part, there is a container for windscreen washer fluid. If the fluid does not escape when pressing the button, remove the pipe that goes from the container to the and blow inside with compressed air.
MSS APE 50 (2012) Maintenance Manutenzione Batterie CHARGE CHECK Connect the terminals of the specific equipment to the respective poles of the battery. Check the charge of the battery. If necessary replace the battery. Scheduled maintenance chart The following table must be regarded as a general guide for periodic inspections and lubrication inter- ventions.
MSS APE 50 (2012) Maintenance km x 1,000 Electrical system and battery Hinges - Door locking - Transmissions Tyre pressure and wear Headlights Safety clamps Test drive OPERATION TIME N.B. THE TIMES LISTED ON THE SCHEDULED MAINTENANCE TABLE INCLUDE THE TIME DEVOTED TO MANAGEMENT ACTIVITIES.
Page 31
MSS APE 50 (2012) Maintenance 19. Admission joint 20. Admission joint gasket 21. Washer 22. M6 nut 23. Gaskets series ADJUSTMENT Perform the idle adjustment. Perform the mixing adjustment. REMOVAL Remove the air filter from the carburettor. WARNING THE CARBURETTOR IS VERY EXPLOSIVE; BE VERY CAREFUL NOT TO SPILL FUEL DURING THE REMOVAL OF THE CARBURETTOR.
Page 32
MSS APE 50 (2012) Maintenance Remove the tank with its gasket. Remove the jet. Remove the needle and the float. Remove the transmissions with their adjustment nuts. MA - 32 Tracking ID-422/tukxi/04/2013...
MSS APE 50 (2012) Maintenance Disassemble the carburettor removing the mini- mum jet, the needle, the gaskets, the petrol filter. REVISION The carburettor is completely decomposed, check all calibrated parts (main jets, idle jets, emulsifiers tubes, etc.). The value of these calibrated parts must corre- spond to the adjustment data prescribed for the type of carburettor.
Page 34
MSS APE 50 (2012) Maintenance Remove the filter and check its state of wear. Replace if damaged. Clean with high flammability solvent and dry with compressed air. CAUTION NEVER RUN THE ENGINE WITHOUT THE AIR FILTER. THIS WOULD RESULT IN AN EXCESSIVE WEAR OF THE PISTON AND CYLINDER.
Page 35
MSS APE 50 (2012) Maintenance Differential oil replacement LEVEL CHECK Start the engine and stop it after having been run- ning for about 1 minute at least. Remove the control rod and check the oil level. The oil level should be between the two notches of the maximum and minimum.
MSS APE 50 (2012) Maintenance Check the oil level and top up if necessary. Verify that there are no leaks. Use specific oils. Tighten the filler plug. Spark plug REMOVAL Remove the rubber cap. Undo the spark plug and remove it from the cylin- der head.
Page 37
MSS APE 50 (2012) Maintenance Piaggio P82M; Champion L82C; Bosch W54C; Lodge 2HN; Ac 430Z. FITTING Fit the spark plug, tighten it manually and then lock it to the prescribed torque with the spark plug spanner. Locking torques (N*m) Spark plug...
Page 38
MSS APE 50 (2012) Maintenance Secondary air system REMOVAL Undo the fixing screws from the aluminium cover of the air box. FILTER CLEANING AND INTEGRITY CHECK Clean the polyurethane sponge by washing with soap and water then dry fully with compressed air and reposition everything in its seat.
Page 39
MSS APE 50 (2012) Maintenance the headlight centre height from ground mul- tiplied by 0.9; 3. Start the engine and lock the throttle twist grip at approximately 1/3 of its travel. Switch the dipped beam headlight on. Direct the beam so that the horizontal line between the light and the shade falls above the horizontal "b-b"...
Page 40
MSS APE 50 (2012) Maintenance Insert the rubber cap. Air Adjustment Position yourself near the carburettor. Remove the rubber cap from the base. Adjust by turning the nut. Insert the rubber cap. MA - 40 Tracking ID-422/tukxi/04/2013...
Page 41
MSS APE 50 (2012) Maintenance Clutch ADJUSTMENT Adjust the clutch transmission by acting on the threaded ring nut near the clutch lever. CAMBIO ADJUSTMENT The adjustment of the gearbox transmission con- trol is performed within the driver's cab. Adjust the gearbox transmission control by turning the nuts.
Page 42
INDEX OF TOPICS CO EM MISSION ONTROLO YSTEM Tracking ID-422/tukxi/04/2013...
Page 43
MSS APE 50 (2012) Emission Controlo System CO check The test must be done after a thorough cleaning of all parts of the carburettor, with the air filter clean and spark plug in good condition Heat the vehicle for the time necessary to activate the catalytic converter.
Page 44
INDEX OF TOPICS TROUBL ROUBLESHOOTING Tracking ID-422/tukxi/04/2013...
Page 45
MSS APE 50 (2012) Troubleshooting Probable cause and troubleshooting DETONATIONS TO THE EXHAUST Possible Cause Operation Detonations in the silencer to the gas release Check the ducts and the membrane of the choke device on the carburettor. NOISE - KNOCKS Possible Cause Operation Worn or leaking shock absorbers...
Page 46
MSS APE 50 (2012) Troubleshooting Poor performance LOW POWER Possible Cause Operation Timing incorrect Perform the foreseen checks. Cylinder head or spark plug not fitted correctly Correct the locking and the fitting. Leakage of current of the ignition system Locate the dispersion and act accordingly. Excessive incrustation on the lights of the cylinder Descale.
Page 47
MSS APE 50 (2012) Troubleshooting Clutch slipping CLUTCH SLIPPAGE Possible Cause Operation Insufficient idle stroke Adjust the stroke. Weak return spring Replace. Worn or burned driven disc gasket Replace the disc. Insufficient oil in the differential transmission or unsuitable oil Restore the oil level or replace.
Page 48
MSS APE 50 (2012) Troubleshooting Possible Cause Operation Hydraulic absorber inefficient or discharged Replace. Roller casings of swinging arm worn Replace. Difficult riding GUIDE IRREGULARITIES Possible Cause Operation The vehicle "pulls" to one side due to deformation of the steer- Check the steering unit and replace if necessary.
Page 49
INDEX OF TOPICS LECTRICAL SYSTEM Tracking ID-422/tukxi/04/2013...
Page 50
MSS APE 50 (2012) Electrical system Dispositivi e accessori Base electric wiring OMPONENTS DESCRIPTION Component Description D01_01 Starter battery D02_13 Voltage regulator D04_10 Starter motor D04_11 Ignition switch D04_34 External lights switch D04_37 Windscreen control switch D04_53 Ignition device D04_59 Starter button D04_60 Stop button on front brake...
Page 51
MSS APE 50 (2012) Electrical system Component Description D08_44 Cigarette lighter supply fuse D08_45 Ancillary supply fuse D08_46 Headlight supply fuse D08_47 External lighting supply fuse D10_02 Engine ground D10_03 Rear right hand chassis ground D10_06 Battery ground D10_07 Chassis/engine ground D10_10 Ground point services cable harness D11_15...
Page 52
MSS APE 50 (2012) Electrical system OMPONENTS DESCRIPTION Component Description D01_01 Starter battery D02_13 Voltage regulator D04_10 Starter motor D04_11 Ignition switch D04_34 External lights switch D04_37 Windscreen control switch D04_53 Ignition device D04_59 Starter button D04_60 Stop button on front brake D04_61 Stop button on rear brake D04_62...
MSS APE 50 (2012) Electrical system Position 1: contacts 7-8 (ground ignition) and 3-5 (c.c. to the daylight running light). Parking extract- able key. Turn signal switch Position 0: no contact. Position 1: contact between the Blue and White - Blue cables.
Page 55
MSS APE 50 (2012) Electrical system Wiper switch In working position, contact between the White and White Black cables. POSITIONS OF THE WINDSCREEN WIPER SWITCH - APE 50 MIX - APE 50 EUROPE 0 = Windscreen wiper turned off 1 = Windscreen wiper turned on 2 = Windscreen washer enabling Pulsante avviamento In working position, contact between the White...
Page 56
MSS APE 50 (2012) Electrical system Interventions The failure of the alternate current section of the voltage regulator can cause, depending on the type of fault, the following problems: 1) Burning of the bulbs (regulator stopped). 2) Operation failure of the lighting (short circuit in the regulator).
Page 57
MSS APE 50 (2012) Electrical system b) If replacing the regulator does not restore proper operation, check the voltage output from the alter- nator, as in point 2a. Checking the output voltage at 3000 rpm on the c.c. section is greater than or equal to 25V.
MSS APE 50 (2012) Electrical system KEY: 1 = Starter button 2 = Remote control Starter motor removal Safety cap removal Coupling pin removal Remove the retainer ring and remove the pinion. CAUTION ALWAYS REPLACE THE INDICATED GASKET GIVEN TO- GETHER WITH THE SPECIFIC RECOMMENDED PROD- UCT.
Page 59
MSS APE 50 (2012) Electrical system Safety cap calkin - Position the hood. - Chamfer, as shown, the hood with the appropri- ate tool. CAUTION REPLACING THE BRUSHES, AND REMOVE THE REAR LID AND REPLACE. Specific tooling 020057Y Tool for Starter Motor Bushing Calk- Controllo impianto di accensione All system check operations involving disconnec- tion of the cables (inspections of connections and...
Page 60
MSS APE 50 (2012) Electrical system Connect the instrument between the green cable and the white one, there must be continuity and an ohmic value of 500± 20 ohm. KEY: 1 = Red 2 = White 3 = Green 4 = Black 5 = Blue Connect the instrument between the red and white cables, there must be continuity and an ohmic val-...
Page 61
MSS APE 50 (2012) Electrical system Functional Diagram F01_02 - D ESCRIPTION OF COMPONENTS Component Description D01_01 Starter battery D02_13 Voltage regulator D04_10 Starter motor D04_11 Ignition switch D04_53 Ignition device D04_59 Starter button D07_23 Magneto flywheel D08_42 Start-up relay D08_43 Main fuse D08_45...
Page 62
MSS APE 50 (2012) Electrical system Colour Description Green-Black Grey-Blue Blue-Black Red-Black Red-Blue Red-Grey Red-White Yellow-Black Yellow-Green White-Black White-Green White-Blue White-Purple LECTRICAL SIGNALS IDENTIFICATION IN THE DIAGRAM Colour Description Supply BLACK Ground lead BLUE Controls to sensors/electrical devices GREEN Signals from sensors/electrical devices D02_13 - V OLTAGE REGULATOR CONNECTOR ROSS...
Page 63
MSS APE 50 (2012) Electrical system D04_11 - I GNITION SWITCH CONNECTOR Colour Description Ground D10_10 External lighting enable Battery positive from main fuse D08_43 (20A) To fuse D08_45 (7.5A) for ancillary supply External lights and cigarette lighter lighting power supply enable Ground signal for ignition device D04_59 - S TART...
Page 64
MSS APE 50 (2012) Electrical system Colour Description Signal to the voltage regulator Signal to the voltage regulator D08_42 - S TART UP RELAY CONNECTOR Colour Description Direct battery positive Ground D10_10 Positive from start-up button Starter motor command D08_43 - M AIN FUSE CONNECTOR Colour Description...
Page 65
MSS APE 50 (2012) Electrical system USES TERMINAL BLOCK CONNECTOR Colour Description To the external lights switch for activation of daylight running light Headlight power supply from fuse D08_46 (4A) Ancillary power supply from fuse D08_45 (7.5A) Cigarette lighter power supply from fuse D08_44 (10A) External lights power supply from fuse D08_47 (4A) Headlights control of external lights switch Positive after ignition switch from main fuse D08_43 (20A)
Page 66
MSS APE 50 (2012) Electrical system ABLES COLOUR DESCRIPTION Colour Description Black Brown Green Grey Blue Orange Rosa Purple Yellow White Green-Black Grey-Blue Blue-Black Red-Black Red-Blue Red-Grey Red-White Yellow-Black Yellow-Green White-Black White-Green White-Blue White-Purple LECTRICAL SIGNALS IDENTIFICATION IN THE DIAGRAM Colour Description Supply...
Page 67
MSS APE 50 (2012) Electrical system D04_10 - S TARTER MOTOR CONNECTOR Colour Description Starter motor command D04_11 - I GNITION SWITCH CONNECTOR Colour Description Ground D10_10 External lighting enable Battery positive from main fuse D08_43 (20A) To fuse D08_45 (7.5A) for ancillary supply External lights and cigarette lighter lighting power supply enable Ground signal for ignition device D04_53 - I...
Page 68
MSS APE 50 (2012) Electrical system D04_59 - S TART UP BUTTON CONNECTOR Colour Description Starter relay command Positive from fuse D08_45 (7.5A) D07_23 - M AGNETO FLYWHEEL CONNECTOR Colour Description Ground lead Signal to the ignition device Signal to the voltage regulator Signal to the voltage regulator Signal to the voltage regulator D08_42 - S...
Page 69
MSS APE 50 (2012) Electrical system Colour Description Ground D10_10 Positive from start-up button Starter motor command D08_43 - M AIN FUSE CONNECTOR Colour Description Direct battery positive Ignition switch and voltage regulator power supply USES TERMINAL BLOCK CONNECTOR Colour Description To the external lights switch for activation of daylight running light Headlight power supply from fuse D08_46 (4A)
Page 70
MSS APE 50 (2012) Electrical system F02_01 - D ESCRIPTION OF COMPONENTS Component Description D01_01 Starter battery D04_11 Ignition switch D08_10 Turn signal flasher relay D08_43 Main fuse D08_45 Ancillary supply fuse D10_06 Battery ground D10_10 Ground point services cable harness D11_15 Fuel level sensor D11_30...
Page 71
MSS APE 50 (2012) Electrical system Colour Description Yellow-Black Yellow-Green White-Black White-Green White-Blue White-Purple LECTRICAL SIGNALS IDENTIFICATION IN THE DIAGRAM Colour Description Supply BLACK Ground lead BLUE Controls to sensors/electrical devices GREEN Signals from sensors/electrical devices D04_11 - I GNITION SWITCH CONNECTOR Colour Description Ground D10_10...
Page 72
MSS APE 50 (2012) Electrical system D08_43 - M AIN FUSE CONNECTOR Colour Description Direct battery positive Ignition switch and voltage regulator power supply USES TERMINAL BLOCK CONNECTOR Colour Description To the external lights switch for activation of daylight running light Headlight power supply from fuse D08_46 (4A) Ancillary power supply from fuse D08_45 (7.5A) Cigarette lighter power supply from fuse D08_44 (10A)
Page 73
MSS APE 50 (2012) Electrical system Colour Description D11_30 - O IL LEVEL SENSOR CONNECTOR Colour Description Oil level warning light control Signal of intermittent relay D08_10 Positive from fuse D08_45 (7.5A) Positive from fuse D08_45 (7.5A) D12_01 - I NSTRUMENT PANEL CONNECTOR Colour Description...
Page 74
MSS APE 50 (2012) Electrical system F04_01 - D ESCRIPTION OF COMPONENTS Component Description D01_01 Starter battery D04_11 Ignition switch D04_37 Windscreen control switch D07_03 Windshield wiper motor D07_05 Electric screen washer pump D08_43 Main fuse D08_45 Ancillary supply fuse D10_06 Battery ground D10_10...
Page 75
MSS APE 50 (2012) Electrical system Colour Description Yellow-Green White-Black White-Green White-Blue White-Purple LECTRICAL SIGNALS IDENTIFICATION IN THE DIAGRAM Colour Description Supply BLACK Ground lead BLUE Controls to sensors/electrical devices GREEN Signals from sensors/electrical devices D04_11 - I GNITION SWITCH CONNECTOR Colour Description Ground D10_10...
Page 76
MSS APE 50 (2012) Electrical system D07_03 - W INDSCREEN WIPER MOTOR CONNECTOR Colour Description Power supply from fuse D08_45 (7.5A) Ground D10_10 Windscreen switch control D07_05 - E LECTRIC WINDSCREEN WASHER PUMP CONNECTOR Colour Description Ground D10_10 Control of windscreen wiper washer switch D08_43 - M AIN FUSE CONNECTOR Colour...
Page 77
MSS APE 50 (2012) Electrical system USES TERMINAL BLOCK CONNECTOR Colour Description To the external lights switch for activation of daylight running light Headlight power supply from fuse D08_46 (4A) Ancillary power supply from fuse D08_45 (7.5A) Cigarette lighter power supply from fuse D08_44 (10A) External lights power supply from fuse D08_47 (4A) Headlights control of external lights switch Positive after ignition switch from main fuse D08_43 (20A)
Page 78
MSS APE 50 (2012) Electrical system F04_03 - D ESCRIPTION OF COMPONENTS Component Description D01_01 Starter battery D04_11 Ignition switch D04_62 Audible warning device control button D08_43 Main fuse D08_44 Cigarette lighter supply fuse D08_45 Ancillary supply fuse D10_06 Battery ground D10_10 Ground point services cable harness D13_01...
Page 79
MSS APE 50 (2012) Electrical system D04_11 - I GNITION SWITCH CONNECTOR Colour Description Ground D10_10 External lighting enable Battery positive from main fuse D08_43 (20A) To fuse D08_45 (7.5A) for ancillary supply External lights and cigarette lighter lighting power supply enable Ground signal for ignition device D04_62 - A UDIBLE WARNING DEVICE CONTROL SWITCH CONNECTOR...
Page 80
MSS APE 50 (2012) Electrical system USES TERMINAL BLOCK CONNECTOR Colour Description To the external lights switch for activation of daylight running light Headlight power supply from fuse D08_46 (4A) Ancillary power supply from fuse D08_45 (7.5A) Cigarette lighter power supply from fuse D08_44 (10A) External lights power supply from fuse D08_47 (4A) Headlights control of external lights switch Positive after ignition switch from main fuse D08_43 (20A)
Page 81
MSS APE 50 (2012) Electrical system F05_01 - D ESCRIPTION OF COMPONENTS Component Description D01_01 Starter battery D04_11 Ignition switch D04_34 External lights switch D05_01 Left headlight D05_02 Right headlight D05_07 License plate lights D05_18 Right rear light D05_19 Left rear light D08_43 Main fuse D08_46...
Page 82
MSS APE 50 (2012) Electrical system Colour Description Grey-Blue Blue-Black Red-Black Red-Blue Red-Grey Red-White Yellow-Black Yellow-Green White-Black White-Green White-Blue White-Purple LECTRICAL SIGNALS IDENTIFICATION IN THE DIAGRAM Colour Description Supply BLACK Ground lead BLUE Controls to sensors/electrical devices GREEN Signals from sensors/electrical devices D04_11 - I GNITION SWITCH CONNECTOR Colour...
Page 83
MSS APE 50 (2012) Electrical system D05_01/02 - H EADLIGHT CONNECTOR Colour Description P/WL Turn signal control Headlight control Daylight running lights control Headlight ground D05_18/19 - T AILLIGHT CONNECTOR Colour Description Stop light control Daylight running lights control Ground D10_03 Turn signal control D08_43 - M AIN FUSE CONNECTOR...
Page 84
MSS APE 50 (2012) Electrical system USES TERMINAL BLOCK CONNECTOR Colour Description To the external lights switch for activation of daylight running light Headlight power supply from fuse D08_46 (4A) Ancillary power supply from fuse D08_45 (7.5A) Cigarette lighter power supply from fuse D08_44 (10A) External lights power supply from fuse D08_47 (4A) Headlights control of external lights switch Positive after ignition switch from main fuse D08_43 (20A)
Page 85
MSS APE 50 (2012) Electrical system D13_01 - C IGARETTE LIGHTER CONNECTOR Colour Description Positive for cigarette lighter lighting Power supply from fuse D08_44 (10A) Ground D10_10 Fog light/Rear fog light/Stop lights/Reverse light F05_03 - Stop lights Functional Diagram F05_03 - D ESCRIPTION OF COMPONENTS Component Description...
Page 86
MSS APE 50 (2012) Electrical system ABLES COLOUR DESCRIPTION Colour Description Black Brown Green Grey Blue Orange Rosa Purple Yellow White Green-Black Grey-Blue Blue-Black Red-Black Red-Blue Red-Grey Red-White Yellow-Black Yellow-Green White-Black White-Green White-Blue White-Purple LECTRICAL SIGNALS IDENTIFICATION IN THE DIAGRAM Colour Description Supply...
Page 87
MSS APE 50 (2012) Electrical system D04_60 - S TOP BUTTON CONNECTOR ON REAR BRAKE Colour Description Power supply from ancillary fuse D08_45 (7.5A) Stop light control D04_61 - S TOP BUTTON CONNECTOR ON REAR BRAKE Colour Description Power supply from ancillary fuse D08_45 (7.5A) Stop light control D05_18/19 - T AILLIGHT CONNECTOR...
Page 88
MSS APE 50 (2012) Electrical system D08_43 - M AIN FUSE CONNECTOR Colour Description Direct battery positive Ignition switch and voltage regulator power supply USES TERMINAL BLOCK CONNECTOR Colour Description To the external lights switch for activation of daylight running light Headlight power supply from fuse D08_46 (4A) Ancillary power supply from fuse D08_45 (7.5A) Cigarette lighter power supply from fuse D08_44 (10A)
Page 89
MSS APE 50 (2012) Electrical system F05_04 - D ESCRIPTION OF COMPONENTS Component Description D01_01 Starter battery D04_11 Ignition switch D04_63 Turn signal control deviator D05_01 Left headlight D05_02 Right headlight D05_18 Right rear light D05_19 Left rear light D08_10 Turn signal flasher relay D08_43 Main fuse...
Page 90
MSS APE 50 (2012) Electrical system Colour Description Red-Black Red-Blue Red-Grey Red-White Yellow-Black Yellow-Green White-Black White-Green White-Blue White-Purple LECTRICAL SIGNALS IDENTIFICATION IN THE DIAGRAM Colour Description Supply BLACK Ground lead BLUE Controls to sensors/electrical devices GREEN Signals from sensors/electrical devices D04_11 - I GNITION SWITCH CONNECTOR Colour...
Page 91
MSS APE 50 (2012) Electrical system D05_01/02 - H EADLIGHT CONNECTOR Colour Description P/WL Turn signal control Headlight control Daylight running lights control Headlight ground D05_18/19 - T AILLIGHT CONNECTOR Colour Description Stop light control Daylight running lights control Ground D10_03 Turn signal control D08_10 - I NTERMITTENT RELAY CONNECTOR...
Page 92
MSS APE 50 (2012) Electrical system Colour Description To the turn signal control deviator Intermittent signal for oil level warning light D08_43 - M AIN FUSE CONNECTOR Colour Description Direct battery positive Ignition switch and voltage regulator power supply USES TERMINAL BLOCK CONNECTOR Colour Description To the external lights switch for activation of daylight running light...
Page 93
MSS APE 50 (2012) Electrical system D12_01 - I NSTRUMENT PANEL CONNECTOR Colour Description Panel lighting and daylight running light warning light power supply activated Ground D10_10 Turn signal lights activation Turn signal lights activation fuel reserve indication Ground D10_10 Oil level indication INTERNAL LIGHTING Passenger compartment light...
Page 94
MSS APE 50 (2012) Electrical system ABLES COLOUR DESCRIPTION Colour Description Black Brown Green Grey Blue Orange Rosa Purple Yellow White Green-Black Grey-Blue Blue-Black Red-Black Red-Blue Red-Grey Red-White Yellow-Black Yellow-Green White-Black White-Green White-Blue White-Purple LECTRICAL SIGNALS IDENTIFICATION IN THE DIAGRAM Colour Description Supply...
Page 95
MSS APE 50 (2012) Electrical system D08_43 - M AIN FUSE CONNECTOR Colour Description Direct battery positive Ignition switch and voltage regulator power supply USES TERMINAL BLOCK CONNECTOR Colour Description To the external lights switch for activation of daylight running light Headlight power supply from fuse D08_46 (4A) Ancillary power supply from fuse D08_45 (7.5A) Cigarette lighter power supply from fuse D08_44 (10A)
Page 96
INDEX OF TOPICS NGINE FROM VEHICLE Tracking ID-422/tukxi/04/2013...
Page 97
MSS APE 50 (2012) Engine from vehicle REMOVAL: Lift the vehicle using the lift. Disconnect the positive (+) and negative (-) poles of the battery. CAUTION MAKE SURE THAT THE SIDE ARMS OF THE LIFT ARE CORRECTLY WELDED AND POSITIONED IN CORRE- SPONDENCE WITH THE LIFTING POINTS.
Page 98
MSS APE 50 (2012) Engine from vehicle Undo the gearbox oil drain plug. Remove the plug and drain the gearbox oil in a suitable container. Retighten the gearbox oil drain plug. Undo the screws fastening the flange hood of the semi axle to the differential crankcase.
Page 99
MSS APE 50 (2012) Engine from vehicle Remove the flange with the hood and using special pliers remove the retainer ring of the semi axle. Undo the fixing bolt of the suspension arm to the frame. CAUTION DURING THIS OPERATION, SUPPORT THE REAR SUS- PENSION ARM.
Page 100
MSS APE 50 (2012) Engine from vehicle Press on the wheel so as to move it toward the outside so as to push the semi axle out of its seat. Also proceed from the other side of the engine. CAUTION DURING THIS OPERATION, ACT WITH CAUTION.
Page 101
MSS APE 50 (2012) Engine from vehicle Remove the odometer from the engine. Undo the fixing screws of the mixer cover. CAUTION IT IS NOT ESSENTIAL TO REMOVE THE SCREW LOCATED BEHIND THE SILENCER BUT JUST LOOSEN IT TO EN- SURE THE REMOVAL OF THE COVER.
Page 102
MSS APE 50 (2012) Engine from vehicle Undo the fixing screw and remove the mixer oil line retaining plate from the engine. Using a suitable tool, close the oil inlet pipe to the mixer. Remove the oil inlet pipe from the mixer. CAUTION PREPARE A SUITABLE CONTAINER TO COLLECT ANY OIL LEAKS.
Page 103
MSS APE 50 (2012) Engine from vehicle Undo the screw fixing the plate and remove the electrical connection from the starter motor. Close the fuel cock under the appropriate tank. Remove the fuel pipe from the carburettor. CAUTION PREPARE A SUITABLE CONTAINER TO COLLECT ANY OIL LEAKS.
Page 104
MSS APE 50 (2012) Engine from vehicle Remove the carburettor with cleaner from the ad- mission joint. CAUTION BE CAREFUL NOT TO OVERTURN THE CARBURETTOR IN ORDER TO PREVENT LEAKAGE. Remove the mixer output pipe from the carburet- tor. Remove the pipe for pressure loss from the car- burettor.
Page 105
MSS APE 50 (2012) Engine from vehicle Remove the retaining plate of the magnet flywheel connection. Disconnect the connection between the magnet flywheel and the voltage regulator. Disconnect the engine ground. Remove the spark plug cap. EV - 105 Tracking ID-422/tukxi/04/2013...
Page 106
MSS APE 50 (2012) Engine from vehicle Disconnect the transmission of the gear inverter. Hold the engine with a workshop jack. Undo the fixing bolt of the engine to the frame. Remove the fixing bolt of the engine to the frame. EV - 106 Tracking ID-422/tukxi/04/2013...
Page 107
MSS APE 50 (2012) Engine from vehicle Undo the fixing screw of the engine support brack- et to the frame. Remove the bracket from the frame. Repeat these operations to also release the other side of the engine support from the frame. Remove the engine by lowering the workshop jack.
Page 108
MSS APE 50 (2012) Engine from vehicle Tighten the fixing screw and lock the bracket to the frame. Also repeat these operations for the other side of the engine support. Locking torques (N*m) Engine support bracket - Chassis 22 ± 2 Nm Insert and tighten the bolt fixing the engine to the frame.
Page 109
MSS APE 50 (2012) Engine from vehicle Refit and tighten the fixing bolt of the suspension arm to the frame. Locking torques (N*m) Rear suspension arm - Frame 44.1 ± 4.9 Nm With suitable pliers, refit the retainer ring of the semi axle and correctly position the flange with the hood.
Page 110
MSS APE 50 (2012) Engine from vehicle Tighten the engine ground. Connect the connection between the magnet fly- wheel and the voltage regulator. Refit the retainer plate of the magnet flywheel con- nection and tighten the fixing screw to the engine support.
Page 111
MSS APE 50 (2012) Engine from vehicle Tighten the nut of the locking ring of the carburettor to the admission joint. Refit on the carburettor the output pipe from the mixer and the vacuum one. Refit the fuel pipe on the carburettor. Connect the transmission of the gear inverter.
Page 112
MSS APE 50 (2012) Engine from vehicle Refit the electrical connection from the starter mo- tor, tightening the screw fixing the plate. Connect the gearbox transmissions. CAUTION FOR THE CORRECT REFITTING, REFER TO THE POSI- TION OF BOTH TRANSMISSIONS, PREVIOUSLY NOTED. Refit the oil inlet pipe on the mixer.
Page 113
MSS APE 50 (2012) Engine from vehicle Connect to the mixer the transmission of the ac- celerator coming from the splitter. Refit the mixer cover. Tighten the fixing screws of the mixer cover. CAUTION THE SCREW LOCATED BEHIND THE SILENCER HAS NOT BEEN REMOVED;...
Page 114
MSS APE 50 (2012) Engine from vehicle Position the clutch cable on the engine. Refit the cylinder on the clutch cable Tighten the retaining cylinder of the clutch trans- mission. Open the fuel cock under the appropriate tank. EV - 114 Tracking ID-422/tukxi/04/2013...
Page 115
MSS APE 50 (2012) Engine from vehicle Remove the tool and reopen the oil inlet pipe to the mixer. Reconnect the positive (+) and negative (-) pole of the battery. Restore the oil in the gearbox. Check the proper adjustment of all transmissions (clutch, gearbox, accelerator, gear inverter).
Page 116
INDEX OF TOPICS NGINE Tracking ID-422/tukxi/04/2013...
Page 117
MSS APE 50 (2012) Engine Engine type 1 Air deflector - cooling fan 1. Screw 2. Plate 3. Washer 4. Cooling hood 5. Cap 6. Spark plug 7. Screw 8. Scroll cover 9. Washer 10. Screw EN - 117 Tracking ID-422/tukxi/04/2013...
Page 118
MSS APE 50 (2012) Engine REMOVAL Undo the spark plug. Remove the spark plug from its seat. Undo the screws fastening the cooling hood. Remove the cooling hood. EN - 118 Tracking ID-422/tukxi/04/2013...
Page 119
MSS APE 50 (2012) Engine Undo the lock screw of the scroll cover and remove FITTING Position the scroll cover on its seat and tighten the lock screws of the scroll cover. Position the cooling hood in its seat, on the cylin- der head.
Page 120
MSS APE 50 (2012) Engine Install the spark plug on the cylinder head. Tighten the spark plug. Flywheel 1. Magneto flywheel 2. Nut EN - 120 Tracking ID-422/tukxi/04/2013...
Page 121
MSS APE 50 (2012) Engine 3. Washer REMOVAL Remove the scroll cover. Using the specific equipment lock the flywheel fan. Specific tooling 020095Y Flywheel Lock Using the specific equipment remove the fixing nut of the flywheel fan and the washer. Specific tooling 048564Y Flywheel extractor Remove the flywheel fan.
Page 122
MSS APE 50 (2012) Engine Using the specific equipment tighten the fixing nut of the flywheel. Locking torques (N*m) Flywheel fan - Crankshaft 47.5 ± 2.5 Nm Stator 1. Complete stator. 2. Washer. 3. Screw. REMOVAL Remove the flywheel fan. EN - 122 Tracking ID-422/tukxi/04/2013...
Page 123
MSS APE 50 (2012) Engine Check correspondence of the reference mark of the stator with respect to the crankcase. Remove the fixing screws and washers. Remove the complete stator. When removing the stator, remove the sheath from inside. FITTING Insert the cable in the appropriate passage hole. EN - 123 Tracking ID-422/tukxi/04/2013...
MSS APE 50 (2012) Engine Install the complete stator taking care to match the reference marks as shown at disassembly. Tighten the fixing screws of the complete stator. Locking torques (N*m) Coils support - Crankcase half 4 ± 1 Nm Starter motor 1.
Page 125
MSS APE 50 (2012) Engine 3.Elastic washer. 4.Nut. Removal Undo the fixing nuts of the starter motor. Remove the starter motor from its seat. Assembly Install the motor. EN - 125 Tracking ID-422/tukxi/04/2013...
MSS APE 50 (2012) Engine Tighten the fixing nuts of the starter motor Locking torques (N*m) Starter motor - Crankcase half 8 ± 1 Nm Crankcase splitting 1. Complete crankcase. 2. Stud bolt. 3. Stud bolt. 4.Screw. 5.Stud bolt. 6.Stud bolt. 7.
Page 127
MSS APE 50 (2012) Engine 11. Ring. 12. Seeger ring. 13.Bearing. 14. Nut. 15. Washer. 16.Bolt. 17. Gasket. 18. Oil plug. Half-crankcase splitting REMOVAL Remove the flywheel fan. Remove the stator. Remove the head and the cylinder. Remove the differential unit. Remove the clutch assembly and the engine gear.
Page 128
MSS APE 50 (2012) Engine FITTING Thoroughly clean the coupling surfaces and posi- tion a new gasket on the flywheel side crankcase half. Couple the crankcase halves. Install the clutch assembly and the engine gear. Install the head and the cylinder. Install the differential unit.
MSS APE 50 (2012) Engine Crankcase bearings 1. Complete crankcase 2. Flywheel-side crankcase half 3. Clutch-side crankcase half 4. Ring 5. Bearing 6.Ring 7. Seeger ring 8.Bearing REMOVAL Separate the crankcase. Remove the crankshaft from the flywheel side crankcase half. EN - 129 Tracking ID-422/tukxi/04/2013...
Page 130
MSS APE 50 (2012) Engine Heat the crankcase bearing coupling to a temper- ature of about 80°C to facilitate removal. Specific tooling 020151Y Heat gun Remove the sealing ring and by means of a punch of suitable diameter eject the bearing. Remove the bearing from the flywheel side crank- case half.
Page 131
MSS APE 50 (2012) Engine Remove the bench bearing sealing ring from the flywheel side crankcase half. Using the appropriate pliers, remove the snap ring. Specific tooling 022465Y Pliers for circlips Heat the crankcase to about 80°C to facilitate the expulsion of the bearing.
Page 132
MSS APE 50 (2012) Engine FITTING Heat the coupling seat to about 80°C to facilitate installation. Place the bearing on its seat on the flywheel side crankcase half and insert it using a punch of an adequate size. Specific tooling 020150Y Support 020151Y Heat gun Heat the coupling seat on the clutch side crank-...
Page 134
MSS APE 50 (2012) Engine Roller cage 1. Flywheel-side crankcase half 2. Roller bearing REMOVAL Carry out the separation of the crankcase. Heat the crankcase to about 80°C to facilitate the removal of the roller bearing. Remove the roller bearing using the specific equip- ment.
Page 135
MSS APE 50 (2012) Engine FITTING Let the crankcase cool down. Fit the roller bearing using the specific equipment. Specific tooling 032975Y Punches for Roller Casings Perform the coupling of the crankcase. Primary gear-shaft 1. Flywheel-side crankcase half 2.Bearing 3.Gear REMOVAL Carry out the separation of the crankcase.
Page 136
MSS APE 50 (2012) Engine Remove the gear box primary shaft from the crank- case. Heat the flywheel side crankcase half to about 80° C to facilitate the removal of the bearing. Remove the gear box primary shaft bearing using a punch of suitable diameter and a rubber ham- mer.
Page 137
MSS APE 50 (2012) Engine Gear-box coupling replacement KEY: 1. Ring 2. Ring 3. 4th speed gear 4. Gear 5. Gear 6. Gear 7. Change gear shaft 8. Ball 9, Spring 10. Fitting Overhaul REMOVAL Carry out the separation of the crankcase and remove the gearbox secondary shaft. Remove the speed gears from the gearbox secondary shaft.
Page 138
MSS APE 50 (2012) Engine Remove the snap ring and disassemble the gear- box engagement. Specific tooling 023638Y Pliers for circlips Check the condition of wear and replace damaged components. FITTING Using the special tool reassemble the gearbox en- gagement. Specific tooling 029569Y Gear Engagement Fitting Tool Install the speed gears.
Page 139
MSS APE 50 (2012) Engine Bearings on half-crankcase clutch-side 1. Gasket 2. Stop 3. Bushing 4. Tie rod 5. Pin 6. Fork 7. Slider 8. Snap ring 9. Ring 10. Bearing 11. Seeger ring 12. Clutch-side crankcase half 13. Gasket 14.
Page 140
MSS APE 50 (2012) Engine Remove the snap ring. Specific tooling 023638Y Pliers for circlips Remove the helical gear. Heat the crankcase to about 80°C to facilitate re- moval. Eject the bearing using a punch of appropriate di- ameter. Specific tooling 020150Y Support 020151Y Heat gun Remove the bearing from the clutch side crank-...
Page 141
MSS APE 50 (2012) Engine Refitting Heat the crankcase to about 80°C to facilitate re- moval. Position the bearing in its housing on the clutch side crankcase half using a punch of appropriate diameter. Specific tooling 020150Y Support 020151Y Heat gun Fit the snap ring by means of special pliers.
Page 142
MSS APE 50 (2012) Engine 1. Crankcase 2.Gear. 3.Key. 4.Bearing. 5.Seeger ring. 6. Helical gear. 7.Ring. REMOVAL Remove the clutch assembly. Carry out the separation of the crankcase. Heat the crankcase to about 80°C to facilitate re- moval. Remove the helical gear using a rubber hammer if necessary.
Page 143
MSS APE 50 (2012) Engine Differential assembly 1. Differential crankcase 2. Ring 3.Roller cage 4.Bushing 5.Whole gear 6. Spring 7. Sliding gear 8.Slider 9.Fork 10. Axle shaft 11.Helical ring 12. Washer 13.Pin 14.Differential case 15. Ring 16.Washer 17. Planetary gear 18.Helical ring 19.Pin EN - 143...
Page 144
MSS APE 50 (2012) Engine 20.Pin 21.Gear 22. Spacer 23. Differential crankcase 24.Sealing ring 25. Bushing 26.Ring 27. Washer 28.Plug 29.Ring 30. Lever 31. Lever 32. Gasket 33. Spring 34.Pin 35.Ring 36.Screw 37.Washer 38. Nut 39.M6 nut 40. Flat washer 41.
Page 145
MSS APE 50 (2012) Engine Cover removal 1. Spring 2.Plug 3.Ring 4. Lever 5.Lever 6.Gasket 7.Pin 8.Ring 9.Spring 10.Sealing ring 11.Bushing 12. Differential crankcase 13.Nut 14.Flat washer 15. Elastic washer 16.Screw EN - 145 Tracking ID-422/tukxi/04/2013...
Page 146
MSS APE 50 (2012) Engine REMOVAL Remove the fixing screws. Remove the cover of the gear. Remove the spring. Remove the nuts and the fixing screws. EN - 146 Tracking ID-422/tukxi/04/2013...
Page 147
MSS APE 50 (2012) Engine Remove the cover of the differential crankcase. FITTING Thoroughly clean the contact surface and apply new paste. Install the cover of the differential crankcase. Tighten the nuts and the screws. Locking torques (N*m) Crankcase half - Differential crankcase cover ±...
Page 148
MSS APE 50 (2012) Engine Position the spring. Differential box and transmission gears REMOVAL Remove the cover of the differential crankcase. Remove the whole gear. Remove the sliding gear. EN - 148 Tracking ID-422/tukxi/04/2013...
Page 149
MSS APE 50 (2012) Engine Remove the differential box. FITTING Install the differential box. Install the sliding gear Install the whole gear Install the cover of the differential crankcase. EN - 149 Tracking ID-422/tukxi/04/2013...
Page 150
MSS APE 50 (2012) Engine Differential case 1. Differential crankcase 2.Ring 3.Roller cage 4. Bushing 5.Whole gear REMOVAL Remove the cover of the differential crankcase. Remove differential box. Remove the fixing nuts. EN - 150 Tracking ID-422/tukxi/04/2013...
Page 151
MSS APE 50 (2012) Engine Remove the differential crankcase. FITTING Thoroughly clean the contact surface of paste res- idues. Apply the new paste on the contact surface of the differential crankcase. Install the differential crankcase. EN - 151 Tracking ID-422/tukxi/04/2013...
Page 152
MSS APE 50 (2012) Engine Tighten the fixing nuts Locking torques (N*m) Differential crankcase - Crankcase half 33.5 ± 1.5 Install the differential box. Install the cover of the differential crankcase. Differential box overhaul 1. Differential box 2. Washer 3. Pin 4.
Page 153
MSS APE 50 (2012) Engine Remove the pin. Remove the pivot. Remove the gears, the washers and the spacer. REVISION Check the condition of the components. EN - 153 Tracking ID-422/tukxi/04/2013...
Page 154
MSS APE 50 (2012) Engine FITTING Install the washers in position inside the differential box. Position the gears and the spacer. Partially insert the pin. Completely insert the pin. Position the pin. Install the differential box. EN - 154 Tracking ID-422/tukxi/04/2013...
Page 155
MSS APE 50 (2012) Engine Clutch assembly 1. Gasket 2.Clutch actuating pad 3.286406 Ring 4.Clutch cap 5. Reference dowel 6.Flanged TE screw 7. Spring 8. Lever 9.Clutch cover 10. Bearing 11. Bearing 12. Gasket 13. Complete clutch Clutch cover and thrust plate CLUTCH COVER REMOVAL Remove the oil pump.
Page 156
MSS APE 50 (2012) Engine Remove the fixing screws of the cover. Remove the clutch cover. Remove the ring. Remove the clutch cap. EN - 156 Tracking ID-422/tukxi/04/2013...
Page 157
MSS APE 50 (2012) Engine CLUTCH LEVER REMOVAL Release the end of the spring from the lever. Remove the bearing from the clutch cover. Remove the lever from its seat on the clutch cover and remove the second bearing and the clutch ac- tuating pad.
Page 158
MSS APE 50 (2012) Engine Insert the lever. Attach the end of spring into the hole of the lever. Position the clutch actuating pad in its housing be- ing careful to lubricate. In order to properly position thrust plate actuating pad, keep the clutch lever at the end of its travel, insert the pad in its housing and holding the pad pressed, slowly release the clutch lever;...
Page 159
MSS APE 50 (2012) Engine Install the ring Position the gasket and the clutch cover. Tighten the fixing screws of the clutch cover. Locking torques (N*m) Clutch cover - Crankcase half 7 ± 1 Nm EN - 159 Tracking ID-422/tukxi/04/2013...
Page 160
MSS APE 50 (2012) Engine Clutch and engine gear 1. Key 2. Complete clutch 3.Nut 4.Washer 5.Seeger ring 6.Nut 7.Washer 8.Engine gear REMOVAL Remove the clutch cover. Straighten the safety tabs of the washer. EN - 160 Tracking ID-422/tukxi/04/2013...
Page 161
MSS APE 50 (2012) Engine Lock the clutch assembly using the specific equip- ment and remove the fixing nut. Specific tooling 030250Y Clutch Stop Key Remove the washer. Install the clutch extractor tool. Specific tooling 009551Y Clutch puller Remove the complete clutch and the key posi- tioned on the shaft.
Page 162
MSS APE 50 (2012) Engine Straighten the safety tabs of the washer. Loosen the lock nut of the engine gear. Remove the nut and the washer. Remove the engine gear and the key. Remove the clutch housing. FITTING Fit the clutch housing. CAUTION REFIT THE PARTICULAR COMPONENTS OF THE ASSEMBLY IN THE CORRECT ORDER.
Page 163
MSS APE 50 (2012) Engine Position the key. Insert the key of the engine gear on the shaft. CAUTION CORRECTLY POSITION THE KEY ON THE SHAFT Position the engine gear. Install the washer and the nut. Tighten the nut. Locking torques (N*m) Engine gear - Crankshaft 52.5 ±...
Page 164
MSS APE 50 (2012) Engine Fold the safety tab. Position the complete clutch. Position the washer. Tighten the nut. Specific tooling 030250Y Clutch Stop Key Locking torques (N*m) Clutch assembly - Gear 42.5 ± 2.5 Nm EN - 164 Tracking ID-422/tukxi/04/2013...
Page 165
MSS APE 50 (2012) Engine Fold the safety tab on the washer. Clutch overhaul 1. Complete clutch 2.Bell 3. Spring 4.Retaining plate 5.Drive disc 6.Pressure plate 7. Helical ring 8.Tray 9.External cap REMOVAL EN - 165 Tracking ID-422/tukxi/04/2013...
Page 166
MSS APE 50 (2012) Engine Remove the complete clutch and position it on the bench. Remove the snap ring and the tray. Remove the external cap, the driving and driven discs and the retainer cap. Remove the springs and the housing. REVISION Check the wear status of the components and re- place damaged components.
Page 167
MSS APE 50 (2012) Engine FITTING Place in order: housing, springs, retaining plate, driving and driven discs alternately, outer plate, tray. CAUTION REFIT THE PARTICULAR COMPONENTS OF THE ASSEM- BLY IN THE CORRECT ORDER. Using the specific equipment assemble the com- ponents and position the snap ring by completing the installation of complete clutch.
MSS APE 50 (2012) Engine 2. Piston 3. Cylinder head 4. Washer 5. Washer 6. Bolt Cylinder head 1. Cap 2. Spark plug 3. Cylinder head 4. Washer 5. Washer 6. Bolt REMOVAL Remove the cooling hood. EN - 168 Tracking ID-422/tukxi/04/2013...
Page 169
MSS APE 50 (2012) Engine Remove the fixing pins of the head. Remove the head from the cylinder. Undo the fixing nuts of the cylinder. Remove the cylinder removing it from the stud bolts. EN - 169 Tracking ID-422/tukxi/04/2013...
Page 170
MSS APE 50 (2012) Engine FITTING Position the gasket on the crankcase. Insert the piston, paying attention to lubricate dur- ing installation. Put the cylinder in position. Tighten the fixing nuts. Locking torques (N*m) Cylinder - Crankcase 14 ± 1 Nm EN - 170 Tracking ID-422/tukxi/04/2013...
Page 171
MSS APE 50 (2012) Engine Position the head on the cylinder. Tighten the fixing screws of the head. Locking torques (N*m) Head - Cylinder 15.5 ± 2.5 Nm Piston LEGENDA 1. Albero motore 2. Gabbia spinotto EN - 171 Tracking ID-422/tukxi/04/2013...
Page 172
MSS APE 50 (2012) Engine 3. Anello elastico 4. Spinotto 5. Pistone 6. Anello di tenuta SMONTAGGIO Rimuovere il cilindro. Rimuovere l'anello elastico dalle estremità dello spinotto. Rimuovere lo spinotto per mezzo dell'apposito punzone. Rimuovere il pistone. EN - 172 Tracking ID-422/tukxi/04/2013...
Page 173
MSS APE 50 (2012) Engine Rimuovere gli anelli di tenuta. Rimuovere la gabbia spinotto. MONTAGGIO Inserire la gabbia spinotto avendo cura di lubrifi- care al montaggio. Lubrificare il vano dell'albero motore. EN - 173 Tracking ID-422/tukxi/04/2013...
Page 174
MSS APE 50 (2012) Engine Installare gli anelli di tenuta sul pistone. Posizionare il pistone. CAUTION POSIZIONARE IL PISTONE CON LA FRECCIA STAMPI- GLIATA SUL CIELO DELLO STESSO IN DIREZIONE DEL- LO SCARICO. Posizionare l'anello elastico. Inserire lo spinotto e posizionare l'anello elastico sul cilindro.
Page 175
MSS APE 50 (2012) Engine Crankshaft 1. Crankcase halves 2. Nut 3.Washer 4.COMPL. CRANKSHAFT 5.Pin cage 6. Key REMOVAL Remove the piston. Carry out the separation of the crankcase. Heat the housing of the crankshaft bearing to fa- cilitate its removal. EN - 175 Tracking ID-422/tukxi/04/2013...
Page 176
MSS APE 50 (2012) Engine Make light blows with a rubber hammer. CAUTION SUPPORT THE CRANKSHAFT TO PREVENT DAMAGE BY FALLING. Remove the complete crankshaft. FITTING If necessary heat the coupling seat between the crankshaft and bearing to facilitate its positioning. Position the shaft in its seat.
Page 177
MSS APE 50 (2012) Engine Check the correct positioning of the complete crankshaft respect to the crankcase half. Perform the coupling of the crankcase. Crankshaft gear 1. Crankcase 2. Key 3. Engine gear 4. Washer 5. Nut EN - 177 Tracking ID-422/tukxi/04/2013...
Page 178
MSS APE 50 (2012) Engine REMOVAL Straighten the safety tabs of the washer. Loosen the lock nut of the engine gear. Remove the nut and the washer. Remove the engine gear and the key. EN - 178 Tracking ID-422/tukxi/04/2013...
Page 179
MSS APE 50 (2012) Engine FITTING Insert the key in its seat on the shaft. Position the engine gear. Install the washer and the nut. Tighten the nut. Locking torques (N*m) Engine gear - Crankshaft 52.5 ± 2.5 Nm Fold the safety tab. EN - 179 Tracking ID-422/tukxi/04/2013...
Page 181
MSS APE 50 (2012) Engine Remove the snap ring. Remove the oil input and output pipes. Remove the fixing screws. Remove the oil pump. EN - 181 Tracking ID-422/tukxi/04/2013...
Page 182
MSS APE 50 (2012) Engine Fitting Position the oil pump. Tighten the fixing screws. Position the oil input and output pipes and the ca- ble grommet. Fit the oil pump cover. Engine timing Check correspondence of the reference mark of the stator with respect to the crankcase EN - 182 Tracking ID-422/tukxi/04/2013...
Page 183
MSS APE 50 (2012) Engine Check to be carried with the Tecno- test 130/P strobe gun (or a similar one that is able to function properly up to at least 11,000 times per minute). CAUTION BEFORE PERFORMING THE TESTS ABOVE, CHECK THE CORRECT JOINING OF THE FLYWHEEL ON THE CRANK- SHAFT.
Page 184
MSS APE 50 (2012) Engine AIR FILTER REMOVAL Remove the fixing nuts. Remove the air filter. AIR FILTER OPENING Remove the fixing screw. Remove the gasket from its seat. EN - 184 Tracking ID-422/tukxi/04/2013...
Page 185
MSS APE 50 (2012) Engine AIR FILTER FITTING Remove the air filter. Tighten the fixing nuts of the air filter EN - 185 Tracking ID-422/tukxi/04/2013...
Page 186
INDEX OF TOPICS IFFERENTIAL Tracking ID-422/tukxi/04/2013...
Page 187
MSS APE 50 (2012) Differential Half-axle KEY: 1. Differential crankcase 2. Axle shaft 3. Helical ring 4. Washer 5. Pin 6. Differential crankcase 7. Bushing 8. Ring 9. Hood 10.Cover 11.Screw TE M6x20 DI - 187 Tracking ID-422/tukxi/04/2013...
Page 188
MSS APE 50 (2012) Differential REMOVAL: Lift the vehicle using the lift. Remove the wheel hub. Undo the oil drain plug. CAUTION PREPARE A CONTAINER SUITABLE FOR COLLECTING BRAKE FLUID. CAUTION PAY THE UTMOST ATTENTION NOT TO COME IN CON- TACT WITH THE OIL.
Page 189
MSS APE 50 (2012) Differential Using suitable pliers, remove the retainer ring of the semi-axle. Remove the semi axle. Remove semi pins and sprocket. REFITTING: Position the semi axle in the appropriate housing on the differential crankcase. Using suitable pliers, lock the retainer ring of the semi-axle.
Page 190
MSS APE 50 (2012) Differential Tighten the screws fastening the hood to the dif- ferential crankcase. Refit the wheel hub. Top up the oil in the differential, by removing the appropriate oil filler cap. CAUTION CHECK THAT THE DIFFERENTIAL BOX DOES NOT LEAK OIL.
Page 191
INDEX OF TOPICS RAKING SYSTEM Tracking ID-422/tukxi/04/2013...
Page 192
MSS APE 50 (2012) Braking system Brake RULES TO CHECK THE HYDRAULIC BRAKE: If the braking system is malfunctioning and this requires a general inspection, make sure that: 1. The metal pipes are in perfect working conditions and are adequately fitted so that they do not interfere with the chassis and may get damaged or flattened.
Page 194
MSS APE 50 (2012) Braking system Removal Remove the rear brake pump. Remove the cotter pin fixing the pedal. Release the spring from the pedal. Remove the bolt locking the pedal to the pump. BS - 194 Tracking ID-422/tukxi/04/2013...
MSS APE 50 (2012) Braking system Remove the pivot. Separate the brake pedal from the pump. Remove the spring. Inspection and repair Check all parts for distortion or irregularities. Make sure of the proper functioning of the spring; otherwise proceed with the replacement. BS - 195 Tracking ID-422/tukxi/04/2013...
Page 196
MSS APE 50 (2012) Braking system Installation Position the spring on the pedal pin as shown in the figure. Insert the pedal on the pump by attaching the spring appropriately. Insert the bolt locking the pedal to the pump. Insert the pin that secures the pedal to the lug of the pump.
Page 197
MSS APE 50 (2012) Braking system Lock the pin by inserting the cotter pin. Refit the rear brake pump. CAUTION WHEN REFITTING USE A NEW COTTER PIN. CAUTION PERFORM THE BRAKE PEDAL ADJUSTMENT. Adjustment REAR BRAKE PEDAL During use you may notice a slight lengthening of the rear brake pedal stroke due to normal wear of the brake shoe.
MSS APE 50 (2012) Braking system Brake fluid reservoir KEY: 1. Clamp 2. Screw d3.5x9.5 3. Brake fluid tank 4. Plug Removal Remove the plug from the tank. CAUTION CHECK THAT THE VEHICLE DOES NOT HAVE THE EN- GINE RUNNING. BS - 198 Tracking ID-422/tukxi/04/2013...
Page 199
MSS APE 50 (2012) Braking system Using a suitable pump, suck the brake fluid inside the tank. Reposition the plug on the tank. CAUTION BRAKING SYSTEM LIQUID IS HAZARDOUS: WASH WITH WATER IN THE EVENT OF ACCIDENTAL CONTACT. CAUTION BRAKING CIRCUIT FLUID IS VERY CORROSIVE;. AVOID CONTACT WITH PAINTED PARTS.
Page 200
MSS APE 50 (2012) Braking system Pull the tank upwards. CAUTION PAY ATTENTION TO ANY DROPS OF OIL RELEASED. Installation Insert, pressing it down, the tank into place on the pump. CAUTION CHECK THAT THE VEHICLE DOES NOT HAVE THE EN- GINE RUNNING.
Page 201
MSS APE 50 (2012) Braking system Attach the electrical connection of the rear brake switch. Fill the tank with the right amount of brake fluid: the level must be between 1 cm below the surface of the cap (MAX level) and 1 cm above the bottom of the tank (MIN level).
MSS APE 50 (2012) Braking system Brake system Fill the brake liquid tank. Press the brake pedal up to the end of the stroke and release it quickly several times until the pedal feels a back pressure. CAUTION THIS PROCEDURE SHOULD BE CARRIED OUT WITH TWO PEOPLE.
MSS APE 50 (2012) Braking system CAUTION BRAKING SYSTEM LIQUID IS HAZARDOUS: WASH WITH WATER IN THE EVENT OF ACCIDENTAL CONTACT. Parking brake lever KEY: 1. Rod 2. Spring 3. Clutch control lever 4. Detent 5. Pin 6. Sector 7. Ring 8.
Page 204
MSS APE 50 (2012) Braking system Removal Using a screwdriver remove the retainer ring. Remove the washer. Remove the tie rod fixing screw cotter pin. Release the tie rod from the parking brake com- mand lever. BS - 204 Tracking ID-422/tukxi/04/2013...
Page 205
MSS APE 50 (2012) Braking system Remove the parking brake command lever from the pin on the chassis. Check Remove the rod with the spring from the lever. Remove the sector. Check all parts for distortion or irregularities. Make sure of the proper functioning of the spring; otherwise proceed with the replacement.
Page 206
MSS APE 50 (2012) Braking system Reposition the rod with the spring inside the lever. Make sure that the final part of the rod, inside the lever, positions itself at the end of the detent as shown in the figure. Position the sector so that the teeth engage with the detent.
Page 207
MSS APE 50 (2012) Braking system Insert the tie rod on the parking brake command lever. Lock the tie rod by inserting the cotter pin. CAUTION WHEN REFITTING USE A NEW COTTER PIN. Insert the washer on the pin on the chassis. Position the retaining ring so as to lock the lever.
Page 208
MSS APE 50 (2012) Braking system Parking brake cable KEY: 1. Tie rod BS - 208 Tracking ID-422/tukxi/04/2013...
Page 209
MSS APE 50 (2012) Braking system 2. Cotter pin 3. Cable grommet 4. Spacer 5. M6 nut 6. Transmission 7. Screw d3.5x9.5 8. Plate Removal Remove the tie rod fixing screw cotter pin. Release the tie rod from the parking brake com- mand lever.
Page 210
MSS APE 50 (2012) Braking system Remove the tie rod and the spacer. Remove the transmission support. At the rear of the cab, undo the fixing screw of the transmission retaining plate. Remove the plate. BS - 210 Tracking ID-422/tukxi/04/2013...
Page 211
MSS APE 50 (2012) Braking system Remove the two ends of the parking brake cable from the backing plates on both wheels. Release the parking brake cables from both sus- pension arms. From inside the cab, remove the parking brake ca- ble.
Page 212
MSS APE 50 (2012) Braking system Attach the cable to the back cab by applying the relative plate. Tighten the fixing screw of the plate to the chassis. From inside the cab, apply the relative support on the cable. Insert the tie rod with its spacer on the support. BS - 212 Tracking ID-422/tukxi/04/2013...
Page 213
MSS APE 50 (2012) Braking system Tighten the nut securing the tie rod to the trans- mission support. Insert the tie rod on the parking brake command lever. Lock the tie rod by inserting the cotter pin. CAUTION WHEN REFITTING USE A NEW COTTER PIN. BS - 213 Tracking ID-422/tukxi/04/2013...
Page 214
MSS APE 50 (2012) Braking system Brake pump KEY: 1. Brake pump 2. Screw 3. Screw 4. m12x1.5 h=7 Hexagonal nut 5. Bracket 6. Switch 7. M6 nut 8. Washer 9. M8 nut REMOVAL: Remove the brake liquid tank. Unscrew the rear brake pipe from the pump. CAUTION IF YOU DECIDE TO REMOVE THE PUMP WITHOUT RE- MOVING THE TANK, PLACE A CONTAINER FOR THE COL-...
Page 215
MSS APE 50 (2012) Braking system Remove the rear brakes pipe from the pump. From under the vehicle, in the front wheel, loosen the bolts securing the pump. Remove the brake pump. Remove the rear brake switch. Remove the brake pedal. BS - 215 Tracking ID-422/tukxi/04/2013...
Page 216
MSS APE 50 (2012) Braking system Remove the lug from the pump. Undo the screw fixing switch support bracket. Remove the bracket. CHECK: Check all parts for distortion or irregularities. Check the proper operation; otherwise proceed with the replacement. BS - 216 Tracking ID-422/tukxi/04/2013...
Page 217
MSS APE 50 (2012) Braking system REFITTING: Refit the brake pedal. Insert the lug in the pump. Refit the switch support bracket by tightening the fixing screw. Tighten the rear brake switch. CAUTION PERFORM THE BRAKE COMMAND PEDAL ADJUSTMENT. Position the brake pump in its seat inside the cab. BS - 217 Tracking ID-422/tukxi/04/2013...
Page 218
MSS APE 50 (2012) Braking system Tighten the bolts securing the pump to the chassis. Locking torques (N*m) Brake pump - Chassis 15.7 ± 4 Nm Insert and tighten the rear brake pipe in the pump. Remove the brake liquid tank. CAUTION BLEED THE AIR FROM THE BRAKING SYSTEM.
Page 219
MSS APE 50 (2012) Braking system Shoes and drums KEY: 1. Shoe holder disc 2. Shoe 3. Spring 4. Buffer 5. Drum 6. Strut 7. Spring 8. Shoe 9. Spring Lift the vehicle using the lift. Remove the rear brake drum. Using appropriate pliers, loosen a shoe so as to release it from the spring.
Page 220
MSS APE 50 (2012) Braking system Remove the strut. Remove the spring. Remove the side spring from a shoe. Remove the parking brake cable from its seat. BS - 220 Tracking ID-422/tukxi/04/2013...
Page 221
MSS APE 50 (2012) Braking system Remove the first shoe after releasing it from the upper spring. Remove the other shoe after detaching it from the side spring. Remove the side spring. CHECK: Check that there are no irregularities on the sur- face of the shoes and that the springs are not deteriorated or stretched.
Page 222
MSS APE 50 (2012) Braking system REAR SHOES REFITTING: Attach the shoe to the plate using the special side clamp. CAUTION BEFORE PROCEEDING WITH THE REPLACEMENT OF THE SHOES, THE REGISTERS MUST BE CLEARED. Position the parking brake cable in its seat. Also insert the side spring in the other shoe.
Page 223
MSS APE 50 (2012) Braking system Insert the strut in its seats on the shoes. Attach the lower spring to the two shoes. Fit the upper spring. N.B. TO FACILITATE THE OPERATION, SLIGHTLY OFFSET THE UPPER PART OF THE SHOE FROM ITS SEAT. With the help of a screwdriver, if necessary bring the shoe back into place.
MSS APE 50 (2012) Braking system Shoe and drum clearance adjustment Before performing the adjustment between the shoe and the drums, it is necessary to set the brakes in motion, in a way that ensures the cen- tring of said shoe. Then act as follows for each wheel: Lift the wheel from the ground, fully lower the brake pedal until bringing the shoes against the drum.
MSS APE 50 (2012) Braking system 1. Rod 2. Spring 3. Clutch control lever 4. Detent 5. Pin 6. Sector 7. Ring 8. Washer 9. Tie rod 10.Cotter pin Parking brake adjustment HAND BRAKE During the use of the vehicle, you may notice a slight lengthening of the hand brake stroke due to normal wear.
Page 226
MSS APE 50 (2012) Braking system Front drum brake KEY: 1. Brake drum 2. Spring 3. Shoe 4. Plate FRONT SHOES REMOVAL: Lift the vehicle using the lift. Remove the front brake drum. CAUTION MAKE SURE THAT THE SIDE ARMS OF THE LIFT ARE CORRECTLY WELDED AND POSITIONED IN CORRE- SPONDENCE WITH THE LIFTING POINTS.
Page 227
MSS APE 50 (2012) Braking system Using a screwdriver remove the retaining ring of the shoe. Remove the shoe from the upper pin. In the lower part of the shoe, remove the plate. Remove the first shoe after releasing it from the spring.
Page 228
MSS APE 50 (2012) Braking system Remove the other shoe. Release the spring. Remove the spacer. CHECK: Check that there are no irregularities on the sur- face of the shoes and that the spring is not deter- iorated or stretched. BS - 228 Tracking ID-422/tukxi/04/2013...
Page 229
MSS APE 50 (2012) Braking system FRONT SHOES REFITTING: Position the spacer into its seat on the steering arm pin. Attach the spring to the shoe and insert the latter on the upper pin. Also attach the other shoe of the spring and insert the plate in the lower part.
Page 230
MSS APE 50 (2012) Braking system Lock the shoe by applying the retaining ring on the pin. Refit the front brake drum. CAUTION ADJUST THE FRONT BRAKE. FRONT DRUM BRAKE Turn the adjuster screw on the front wheel clock- wise to recover any excessive clearance of the front brake lever due to wear.
Page 231
INDEX OF TOPICS TEERING COLUMN Tracking ID-422/tukxi/04/2013...
Page 233
MSS APE 50 (2012) Steering column 19.Sleeve 20. Washer 21. Clutch control lever 22. Sector 23.Hand grip Lift the vehicle using the lift. Remove the handle- bar cover. CAUTION MAKE SURE THAT THE SIDE ARMS OF THE LIFT ARE CORRECTLY WELDED AND POSITIONED IN CORRE- SPONDENCE WITH THE LIFTING POINTS.
Page 234
MSS APE 50 (2012) Steering column Remove the fixing screw of the sleeve to the han- dlebar. Release the clutch cable from the engine side. Remove the retainer knob of the clutch cable on the handlebar. Remove the clutch cable from the handlebar and its bushing.
Page 235
MSS APE 50 (2012) Steering column Undo the fixing screw of the clutch control lever to the sleeve. Remove the clutch control lever. Remove the sleeve. Remove the fixing screw of the sector cover. SC - 235 Tracking ID-422/tukxi/04/2013...
Page 236
MSS APE 50 (2012) Steering column Remove the cover of the sector. N.B. FOR THE CORRECT REFITTING, NOTE DOWN THE POSI- TION OF THE GEAR CONTROL TRANSMISSIONS ON THE SECTOR. Remove the gear transmissions. Remove the sector from the handlebar. SC - 236 Tracking ID-422/tukxi/04/2013...
Page 237
MSS APE 50 (2012) Steering column Remove the pipe from the handlebar. Remove the knob on the right side of the handle- bar, after having been placed common lubricant underneath to facilitate the extraction. Unscrew the retaining screw of the accelerator transmission.
Page 238
MSS APE 50 (2012) Steering column On the rear wheel, loosen the adjusting nut of the brake transmission. From the brake lever on the handlebar, remove the transmission of the front brake. CAUTION PAY ATTENTION TO THE RELEASE OF THE BUSHING ON THE BRAKE.
Page 239
MSS APE 50 (2012) Steering column Remove the stop button. Remove the fixing screw of the front brake lever. Remove the front brake lever. Undo the fixing screw of the sleeve to the accel- erator pipe. SC - 239 Tracking ID-422/tukxi/04/2013...
Page 240
MSS APE 50 (2012) Steering column Remove the accelerator pipe from the sleeve, pay- ing attention to the escape of the slider. N.B. FOR THE CORRECT REFITTING, TAKE NOTE OF THE PO- SITION OF THE SLIDER. Remove the fixing bolt of the handlebar. Remove the handlebar.
Page 241
MSS APE 50 (2012) Steering column Undo and remove the cone from the bottom end of the handlebar. Remove the bolt with the washer from inside the handlebar. CHECK: Check that all the components are free of deformities or failures so as not to compromise functioning. Replace in case of irregularities.
Page 242
MSS APE 50 (2012) Steering column Insert the plastic guard on the handlebar. Insert the handlebar in its appropriate seat on the steering. Tighten the fixing bolt of the handlebar. Locking torques (N*m) Handlebar - Steering seat 47.5 ± 12.5 Nm Fit the slider on the accelerator tube, matching the locations indicated above.
Page 243
MSS APE 50 (2012) Steering column Insert the accelerator pipe with the slider on the sleeve. Tighten the fixing screw of the sleeve to the accel- erator pipe. Insert the front brake lever in its seat on the sleeve and tighten the fixing screw. Locking torques (N*m) Front brake lever - Sleeve 4 ±...
Page 244
MSS APE 50 (2012) Steering column Insert the complete sleeve on the handlebar, right side, and lock it by tightening the fixing screw. Locking torques (N*m) Accelerator sleeve - Handlebar 8.3 ± 0.5 Nm Refit the lever of the transmission of the front brake.
Page 245
MSS APE 50 (2012) Steering column Insert the pipe on the left part of the handlebar. Insert the sector in the suitable seat on the pipe. N.B. WE RECOMMEND GREASING THE HOUSING OF THE SECTOR. Fit the gear transmissions. CAUTION PAY ATTENTION TO PROPERLY INSTALLING THE GEAR TRANSMISSIONS.
Page 246
MSS APE 50 (2012) Steering column Tighten the fixing screw of the sector cover. Fit the sleeve. Mount the clutch command lever on the sleeve and lock it by tightening the fixing screw. Locking torques (N*m) Clutch control lever - Sleeve 4 ±...
Page 247
MSS APE 50 (2012) Steering column Tighten the retainer knob of the clutch cable on the lever. Refit the clutch cable from the engine side. CAUTION ADJUST THE CLUTCH CABLE. Tighten the fixing screw of the sleeve to the han- dlebar.
Page 248
MSS APE 50 (2012) Steering column Insert the rubber hand grip. Refit the handlebar cover. Steering wheel from chassis 1. Ring 2. Steering tube 3.Steering tube ring nut 4. Steering washer 5. Ring nut 6. Gasket 7.Sealing ring 8. Bearing 9.
Page 249
MSS APE 50 (2012) Steering column 11. Nut 12. Brake lever axis 13.Screw 14.Washer 15. Cup spring 16. Spacer 17. Plate 18.Sealing ring 19.Cap 20. Flat washer 21. Sealing ring 22.Brake command lever REMOVAL: Remove the handlebar. Remove the front shock absorber. Remove the front wheel, the drum and the brake shoe.
Page 250
MSS APE 50 (2012) Steering column Remove the front brake transmission from its clamp on the steering tube. Undo the adjusting nut of the brake transmission. Remove the adjusting nut of the brake transmis- sion. Pull the front brake transmission from the brake lever axle.
Page 251
MSS APE 50 (2012) Steering column Undo the fixing bolt of the brake lever axle. Remove the brake lever axle from the steering tube. Press on the opposite side to remove the brake command lever. Undo the brake command lever with the sealing ring and the washer.
Page 252
MSS APE 50 (2012) Steering column Undo the fixing screw of the plate to the steering tube. Remove the plate. Remove the o-ring from the plate. With the appropriate tool, undo the second steer- ing tube ring nut. CAUTION DURING THIS OPERATION SUPPORT THE STEERING TUBE FROM THE OUTSIDE.
Page 253
MSS APE 50 (2012) Steering column Remove the second ring nut from the steering tube. CAUTION PAY SPECIAL ATTENTION TO AVOID THE FALL OF THE BALLS UNDERNEATH. Remove the steering tube. CAUTION PAY SPECIAL ATTENTION TO AVOID THE FALL OF THE BALLS ON THE STEERING TUBE.
Page 254
MSS APE 50 (2012) Steering column Position the ring nut on the steering tube. With the appropriate tool, tighten the ring nut. Specific tooling 020055Y Steering Ring Nut Key Locking torques (N*m) Ring nut- Steering tube 34.3 ± 4.9 Nm Insert the steering washer.
Page 255
MSS APE 50 (2012) Steering column With the appropriate tool, tighten the steering tube ring nut. Specific tooling 020055Y Steering Ring Nut Key Locking torques (N*m) Steering tube ring nut- Steering tube 53.9 ± 5 Nm Reinsert the o-ring on the plate. Refit the plate on the steering tube.
Page 256
MSS APE 50 (2012) Steering column Refit the sealing ring and the washer on the brake command lever. Reinsert the brake command lever on the steering tube. Refit the brake lever axle on the brake command lever on the steering tube. The refitting of the brake lever axle on the brake command lever can be done in one way only, lining up the smooth sides with no notches.
Page 257
MSS APE 50 (2012) Steering column Tighten the fixing bolt of the brake lever axle. Locking torques (N*m) Brake lever axle - Brake command lever 12.2 ± 0.5 Nm Insert the front brake transmission on the brake lever axle. Tighten the adjusting nut of the brake transmis- sion.
Page 258
MSS APE 50 (2012) Steering column Steering bearing housing from chassis 1. Steering tube 2.Bearing seat 3.Ball 4.Bearing seat 5.Washer Upper housing REMOVAL: Remove the steering from the chassis. Remove the balls from the upper seat. Using the specific tool and with the aid of a ham- mer, release the upper seat from the chassis.
Page 259
MSS APE 50 (2012) Steering column Remove the upper seat. Disassemble the lower seat. CHECK: Check the good state of all components. REFITTING: Thoroughly clean the housings of the upper and lower seats on the frame. Position the upper seat in its housing on the steer- ing tube.
Page 260
MSS APE 50 (2012) Steering column Also fit the upper spacer on the threaded pin. Insert the upper nut on the threaded pin. Tighten the nut until the simultaneous complete insertion of the upper and lower seat. Refit the balls on the upper seat, after having prop- erly applied grease to the housing.
Page 261
MSS APE 50 (2012) Steering column Lower housing REMOVAL: Remove the steering from the chassis. Remove the upper seat. Using the specific tool and with the aid of a ham- mer, release the lower seat from the chassis. CAUTION SUPPORT THE LOWER SEAT FROM THE OUTSIDE IN OR- DER TO AVOID DANGEROUS LEAKS.
Page 262
MSS APE 50 (2012) Steering column Lower housing from steering column 1. Steering tube 2. Dust gaiter 3.External steering bearing 4.Ball REMOVAL: Remove the steering from the chassis. Remove the balls. SC - 262 Tracking ID-422/tukxi/04/2013...
Page 263
MSS APE 50 (2012) Steering column Using a punch and a hammer, release the lower seat and the dust gaiter from the tube. Remove the lower seat and the dust gaiter from the steering tube. CHECK Check that the lower seat is free of deformities or failures so as not to compromise functioning. Replace in case of irregularities.
Page 264
MSS APE 50 (2012) Steering column Clean any grease leaks with a rag. Reposition the balls in their seat. Smontaggio cilindretto commutatore a chiave 1. Dowel 2. Switch SC - 264 Tracking ID-422/tukxi/04/2013...
Page 265
MSS APE 50 (2012) Steering column 3.Lock block 4.Plate 5.Lock body 6.Cylinder 7.Keys REMOVAL: Disconnect the switch electric connection. Using an Allen wrench undo the fixing dowel of the switch. Remove the switch from its seat on the steering tube. Remove the cylinder.
Page 266
MSS APE 50 (2012) Steering column Press down with a pin on the internal latch to re- move the lock. CAUTION TURN THE KEY TO THE "OFF" POSITION. At the same time remove the lock. CAUTION PAY ATTENTION TO THE RELEASE OF THE PLATE. Remove the plate from the lock.
Page 267
MSS APE 50 (2012) Steering column Remove the cylinder from the lock body. CHECK: Check that the components of the lock are free of deformities or failures so as not to compromise functioning. Replace if necessary. REFITTING: Insert the cylinder in the lock body until it clicks into its locked position.
Page 268
MSS APE 50 (2012) Steering column Position the lock inside its seat on the steering tube and press it until it clicks into its locked posi- tion. CAUTION BE CAREFUL NOT TO DROP THE PLATE. Refit the cylinder in its seat. Refit the switch in its seat on the steering tube.
Page 269
MSS APE 50 (2012) Steering column Connect the switch electric connection. SC - 269 Tracking ID-422/tukxi/04/2013...
Page 270
INDEX OF TOPICS USPENSIONS Tracking ID-422/tukxi/04/2013...
Page 271
MSS APE 50 (2012) Suspensions Front KEY: 1. Front shock absorber 2. Buffer 3. Spring 4. Washer 5. Nut 6. Washer 17.6x11x2.5 Shock-absorbers removal REMOVAL: Lift the vehicle using the lift. Undo the top locking nut of the shock absorber to the steering tube.
Page 272
MSS APE 50 (2012) Suspensions Also remove the washers and the buffer. Undo the lower fixing nut of the shock absorber. Remove the washer underneath. Remove the complete front shock absorber. CAUTION DURING THIS OPERATION, SUPPORT THE FRONT WHEEL. SS - 272 Tracking ID-422/tukxi/04/2013...
Page 273
MSS APE 50 (2012) Suspensions Remove the spring from the shock absorber. CHECK: Check the following parts: 1. Spring buffer = wear 2. Spring = flattened condition 3. Shock absorber = oil loss SHOCK ABSORBER FUNCTIONING CHECK: Position the shock absorber in a vice. Press the shock absorber and check that the com- pression is uniform throughout the stroke, and that there is no abnormal resistance or noise.
Page 274
MSS APE 50 (2012) Suspensions REFITTING: Apply the spring to the shock absorber. Fit the complete shock absorber on the steering tube. Insert the washer on the lower pin of the steering tube. Tighten the lower fixing nut of the shock absorber. Locking torques (N*m) Front shock absorber (upper part) - Steering tube...
Page 275
MSS APE 50 (2012) Suspensions Insert the washers and the buffer and tighten the upper nut locking the shock absorber to the steer- ing tube. Make the vehicle without load shake up and down, in order to settle the suspension. Check again the locking torque of the fixing nuts to the steering tube.
Page 276
MSS APE 50 (2012) Suspensions REMOVAL: Lift the vehicle using the lift. Undo the fixing nuts of the front wheel. CAUTION MAKE SURE THAT THE SIDE ARMS OF THE LIFT ARE CORRECTLY WELDED AND POSITIONED IN CORRE- SPONDENCE WITH THE LIFTING POINTS. Remove the front wheel.
Page 277
MSS APE 50 (2012) Suspensions Undo the drum fixing nut. Remove the brake drum. BRAKE DRUM CHECK: Check the internal surface of the brake drum. Replace if there are any irregularities or cracks that may damage the brake shoes. REFITTING: Insert the brake drum in its seat on the steering tube.
Page 278
MSS APE 50 (2012) Suspensions Refit the cap by pressing it, if necessary hitting it with light blows with a rubber hammer. Refit the front wheel and attach to the drum by tightening the fixing nuts. Locking torques (N*m) Front wheel - Brake drum 23.6 ±...
Page 279
MSS APE 50 (2012) Suspensions 2. Bearing 3. Brake drum REMOVAL: Remove the front wheel and the brake drum. Position the drum on a flat and stable surface. Using the appropriate equipment, remove the sealing ring. Specific tooling Pliers_snap_rings_suspensions_ape502012 Pliers for circlips Position the drum in a clamp.
Page 280
MSS APE 50 (2012) Suspensions Using a hammer hit a few blows on an appropriate punch to insert the ball bearing. CAUTION APPLY GREASE TO THE BEARING Specific tooling Punch_installation_bearings_suspen- sions_ape502012 Punch for mounting bear- ings Recommended products AGIP GREASE MU3 Yellow lithium based grease, suitable for various purposes.
Page 281
MSS APE 50 (2012) Suspensions Remove the roller bearing from the other side. REFITTING: Reposition the roller bearing in its seat on the drum. Using a hammer hit a few blows on an appropriate punch to insert the roller bearing. Refit the ball bearing.
Page 282
MSS APE 50 (2012) Suspensions Alternately push and pull the top and bottom of the tyre, making sure that does not have an excessive clearance. - If the clearance is excessive, repeat the control with the front brake lever engaged. - If there is excessive clearance then the front wheel bearing is loose.
Page 284
MSS APE 50 (2012) Suspensions 5. 13.75x8.15x4.5 flexible washer 6. Nut REMOVAL: Lift the vehicle using the lift. Undo the fixing nuts of the rear wheel. CAUTION MAKE SURE THAT THE SIDE ARMS OF THE LIFT ARE CORRECTLY WELDED AND POSITIONED IN CORRE- SPONDENCE WITH THE LIFTING POINTS.
Page 285
MSS APE 50 (2012) Suspensions Remove the brake drum. BRAKE DRUM CHECK: Check the internal surface of the brake drum. Replace if there are any irregularities or cracks that may damage the brake shoes. REFITTING: Reposition the brake drum in its seat. Insert the ring and the washer on the pin.
Page 286
MSS APE 50 (2012) Suspensions Chamfer the nut with a punch. Fit the rear wheel. Tighten the fixing nuts of the rear wheel. Locking torques (N*m) Rear wheel - Brake drum 23.6 ± 4 Nm Parking brake control and brake shoes REMOVAL: Lift the vehicle using the lift.
Page 287
MSS APE 50 (2012) Suspensions Remove the ring. Remove the parking brake control transmission from the shoe holder disc. REFITTING: Insert the parking brake cable in its seat on the shoe holder disc. Apply the ring on the parking brake control trans- mission so as to lock it to the shoe holder disc, pulling the cable slightly.
Page 288
MSS APE 50 (2012) Suspensions Brake cylinder and shoe disc REMOVAL: Lift the vehicle using the lift. Remove the rear wheel, the brake drum and the shoe. Undo the bleed screw and drain the oil in the brak- ing system, if necessary applying a rubber tube to facilitate the operations.
Page 289
MSS APE 50 (2012) Suspensions Remove the brake cylinder. Supporting the nuts from the inside part with a wrench, undo the fixing bolts of the shoe holder disc. Remove the shoe holder disc. REFITTING: Insert the shoe holder disc in the semi axle in its seat.
Page 290
MSS APE 50 (2012) Suspensions Tighten the shoe holder disc fixing bolts to the hub. Locking torques (N*m) Shoe holder disc - Wheel hub 23.6 ± 4 Nm Apply the brake cylinder in the appropriate slot on the shoe holder disc. Tighten the screw fixing the brake cylinder on the shoe holder disc.
Page 291
MSS APE 50 (2012) Suspensions Planetary and half-pins KEY: 1. Axle shaft 2. Helical ring 3. Washer 4. Pin REMOVAL: Remove the semi axle. Position the semi axle in an appropriate clamp. SS - 291 Tracking ID-422/tukxi/04/2013...
Page 292
MSS APE 50 (2012) Suspensions Remove the protection hood. Remove the sealing ring with the appropriate equipment. Specific tooling Pliers_snap_rings_suspensions_ape502012 Pliers for circlips Remove the washer. Remove the pivot. CAUTION TAKE NOTE OF THE CORRECT POSITIONING OF THE TWO SEMI PINS INSIDE THE JOINT. SS - 292 Tracking ID-422/tukxi/04/2013...
Page 293
MSS APE 50 (2012) Suspensions Remove the joint from the semi axle. Remove, from the joint, the other pin with the washer and the sealing ring. Remove the washer from the semi axle. Remove the sealing ring of the semi-axle to the differential crankcase.
Page 294
MSS APE 50 (2012) Suspensions Remove the flange with the hood. CHECK: Check that all the components are free of deform- ities or failures so as not to compromise the semi- axle joint. Replace in case of irregularities. REFITTING: Refit the flange with the hood on the semi axle. Refit the sealing ring on the semi-axle to the dif- ferential crankcase.
Page 295
MSS APE 50 (2012) Suspensions Insert the washer on the semi axle. Refit the joint on the semi axle. Insert the pin in the joint. Rotate the joint, and, based on what was previ- ously noted, correctly insert the other pin as well. SS - 295 Tracking ID-422/tukxi/04/2013...
Page 296
MSS APE 50 (2012) Suspensions Refit the washer. Refit the sealing ring using the appropriate equip- ment. Specific tooling Pliers_snap_rings_suspensions_ape502012 Pliers for circlips Refit the washer and the sealing ring also for the other pin in the joint. Ball bearing and split ring on hub REMOVAL: Remove the wheel hub on the semi-axle.
Page 297
MSS APE 50 (2012) Suspensions Remove the spacer. Clean the residual grease from the inside of the hub. Remove the sealing ring with the appropriate equipment. Specific tooling Pliers_snap_rings_suspensions_ape502012 Pliers for circlips Turn over the hub and, using a hammer and suit- able punch, eject the bearing.
Page 298
MSS APE 50 (2012) Suspensions Remove the spacer. CHECK: Check that all the components are free of deform- ities or failures so as not to compromise function- ing. Replace in case of irregularities. REFITTING: Apply grease in the internal chamber of the hub. Recommended products AGIP GREASE MU3 Yellow lithium based grease, suitable for various purposes.
Page 299
MSS APE 50 (2012) Suspensions Insert the spacer inside the hub. Insert the bearing in its seat. Using a hammer hit a few blows on an appropriate punch to insert the bearing at the end. Specific tooling Punch_installation_bearings_suspen- sions_ape502012 Punch for mounting bear- ings Apply grease on the surface of the bearing.
Page 300
MSS APE 50 (2012) Suspensions Insert the sealing ring with the appropriate equip- ment. Specific tooling Pliers_snap_rings_suspensions_ape502012 Pliers for circlips Insert the spacer. CAUTION THE SPACER MUST BE PLACED WITH THE FLARING FACING UP. Fit the oil seal. Refit the roller bearing. Refit the wheel hub on the semi-axle.
Page 301
MSS APE 50 (2012) Suspensions Remove the spacer. Turn over the hub and, using a hammer and suit- able punch, eject the roller bearing. CAUTION PAY ATTENTION TO ESCAPE OF THE ROLLER BEARING FROM THE OTHER SIDE OF THE HUB. Specific tooling Punches for rear suspension roller casings Punches for roller casings...
Page 302
MSS APE 50 (2012) Suspensions REFITTING: Position the roller bearing in its seat. Using a hammer hit a few blows on an appropriate punch to insert the roller bearing. Specific tooling 038138Y Punches for roller casings Insert the roller bearing by aligning the edge to the seat.
Page 303
MSS APE 50 (2012) Suspensions Fit the oil seal. Refit the ball bearing. Refit the wheel hub on the semi-axle. CAUTION WHEN REFITTING ALWAYS USE NEW OIL SEALS. Wheel hub on half-shaft REMOVAL: Remove the shoe holder disc. Remove the rear shock absorber. Undo the bolts that secure the hub to the rear sus- pension arm.
Page 304
MSS APE 50 (2012) Suspensions Use the appropriate extractor to remove the hub. Specific tooling 038137Y Rear hub extractor Remove the wheel hub from the semi-axle. REFITTING: Mount the wheel hub on the semi-axle, also tap- ping it lightly with a rubber mallet so as to lock it permanently on the semi-axle.
Page 305
MSS APE 50 (2012) Suspensions Insert the bolts and their fixing nuts. Tighten the bolts that secure the hub to the rear suspension arm. Refit the rear shock absorber. Refit the shoe holder disc. Locking torques (N*m) Wheel hub - Rear suspension arm 58.8 ±...
Page 306
MSS APE 50 (2012) Suspensions 2. Nut 3. Flexible washer 4. Washer 5. Buffer 6. Rear shock absorber 7. Buffer REMOVAL: Remove the rear wheel. Undo the lower nut fixing the shock absorber to the wheel hub. Remove the washer. Slightly lower the hub and remove the buffers with the washers and the bolt.
Page 307
MSS APE 50 (2012) Suspensions Remove the upper cover. Remove the washer underneath. Remove the buffer. Undo the upper nut fixing the shock absorber to the chassis. CAUTION DURING THIS OPERATION, SUPPORT THE SHOCK AB- SORBER FROM THE LOWER SIDE. SS - 307 Tracking ID-422/tukxi/04/2013...
Page 308
MSS APE 50 (2012) Suspensions Remove the rear shock absorber from below. Remove the spring of the shock absorber. Remove the buffer from the upper seat of the shock absorber. CHECK: Check that the buffers are not worn and that the washers are in good condition.
Page 309
MSS APE 50 (2012) Suspensions SHOCK ABSORBER FUNCTIONING CHECK: Position the shock absorber in a vice. Press the shock absorber and check that the com- pression is uniform throughout the stroke, and that there is no abnormal resistance or noise. Check the same conditions with the shock absorb- er extended.
Page 310
MSS APE 50 (2012) Suspensions Mount the buffer with the washer inside the upper seat on the wheel hub. Mount the buffer with the washer inside the lower seat on the wheel hub. Insert the shock absorber pin and tighten the nut with the washer so as to fix it to the wheel hub.
Page 311
MSS APE 50 (2012) Suspensions Tighten the upper nut fixing the shock absorber to the chassis. Locking torques (N*m) Rear shock absorber (upper part) - Chassis 34.3 ± 4.9 Nm Insert the buffer. Insert the washer. Apply the cover and tighten the screws to fix it to the deck.
Page 312
MSS APE 50 (2012) Suspensions Suspension arm replacement KEY: 1. Screw 2. Washer 3. Screw 4. M10 self-locking nut 5. Arm REMOVAL: Remove the wheel hub from the semi-axle. Release the parking brake transmission from the suspension arm. SS - 312 Tracking ID-422/tukxi/04/2013...
Page 313
MSS APE 50 (2012) Suspensions Release the rear brake pipe from the suspension arm. Undo the joint of the rear brake pipe from the sus- pension arm. Remove the pipe. CAUTION PREPARE A CONTAINER SUITABLE FOR COLLECTING BRAKE FLUID. Remove the retainer spring. Remove, from the suspension arm, the brake line from the brake distributor.
Page 314
MSS APE 50 (2012) Suspensions Undo the fixing bolt of the suspension arm to the frame. CAUTION DURING THIS OPERATION, SUPPORT THE REAR SUS- PENSION ARM. Remove the bolt and its nut. Remove the rear suspension arm from the frame. REFITTING: Position the suspension arm in its housing on the frame.
Page 315
MSS APE 50 (2012) Suspensions Tighten the fixing bolt of the suspension arm to the frame. Locking torques (N*m) Rear suspension arm - Frame 44.1 ± 4.9 Nm Insert, in the appropriate hole on the suspension arm, the brake line from the brake distributor. Apply the retainer spring.
Page 316
MSS APE 50 (2012) Suspensions Snap the rear brake pipe into place on the sus- pension arm. Snap the parking brake transmission into place on the suspension arm. Refit the wheel hub from the semi-axle. CAUTION INSERT NEW OIL IN THE BRAKING SYSTEM. DO NOT RECOVER THE PREVIOUS ONE.
Page 317
MSS APE 50 (2012) Suspensions INSPECTION AND CHECKS ON THE REAR SHOCK ABSORBERS: Visually inspect the shock absorbers and check that there are no signs of deterioration and fluid leaks. Firmly push down on the rear of the vehicle to ver- ify that there is no abnormal resistance or noise.
Page 318
INDEX OF TOPICS HASSIS Tracking ID-422/tukxi/04/2013...
Page 319
MSS APE 50 (2012) Chassis Windscreen LEGENDA: 1. Vetro parabrezza 2. Bordo laterale 3. Bordo inferiore 4. Angolare Removal PREPARATION: Before removing the windscreen, it is necessary to make provisions for the following equipment: - Cutter; - Adhesive tape; - Steel wire with handle for removing glass. CH - 319 Tracking ID-422/tukxi/04/2013...
Page 320
MSS APE 50 (2012) Chassis Remove the upper central dashboard. Remove the edge. Remove the wiper blade by undoing the relative fixing nut. In order to avoid damaging the paintwork, apply the adhesive tape along the entire perimeter of the windscreen.
Page 321
MSS APE 50 (2012) Chassis Remove the gasket residues. Position the steel wire between the windscreen and the chassis. Slide the steel wire all along the windscreen so as to remove it permanently. CAUTION IT IS NECESSARY TO PERFORM THIS OPERATION WITH TWO PEOPLE, ONE FROM INSIDE THE CAB AND THE OTHER FROM THE OUTSIDE.
Page 322
MSS APE 50 (2012) Chassis - Recommended product for fixing the windscreen. CAUTION WHEN REFITTING ALWAYS USE NEW GASKETS. Recommended products THIO BOSTIK 80 Adhesive sealing compound Remove the residues of the adhesive and the pre- existing window using mechanical tools, blades or abrasive elements.
Page 323
MSS APE 50 (2012) Chassis Degrease the edge of the new pane with ethyl al- cohol. Position the glass and centre it with respect to the edge, upper and lower, of the frame that houses the pane, observing proper distances. Check that the distance of the pane from the edge of the housing frame is the same on both sides.
Page 324
MSS APE 50 (2012) Chassis Make sure that a period of 30' minimum and 4h maximum has elapsed from the moment the pri- mer was applied, to insert the cartridge in the appropriate gun, which should be connected to a compressed air unit.
Page 325
MSS APE 50 (2012) Chassis Side windows KEY: 1. Right complete window 2. Left complete window 3. Arm 4. M5 nut 5. Hinge 6. Rivet 7. Washer 8. Washer 9. Profile 10.Spring line 11.Strip 12.Screw 13.Bolt 14.Washer 15.Gasket 16.Plate 17.Spring 18.Screw CH - 325 Tracking ID-422/tukxi/04/2013...
Page 326
MSS APE 50 (2012) Chassis Removal Undo the fixing nuts of the arm to the glass. Remove the arm and its bolts. Offset the upper part of the gasket. Undo the fixing screws of the glass to the door. CAUTION SUPPORT THE GLASS FROM THE OUTSIDE.
Page 327
MSS APE 50 (2012) Chassis Remove the glass and the strip underneath. Undo the fixing screws and remove the spring and the plate locking the glass to the door. Refitting Position the strip as shown in the figure. From the outside, place the upper part of the glass in its seat.
Page 328
MSS APE 50 (2012) Chassis Tighten the fixing screws of the glass to the door. CAUTION SUPPORT THE GLASS FROM THE OUTSIDE. Reposition the gasket in its seat. Fit the arm on the glass using the relative bolts. Tighten the fixing nuts of the arm to the glass. CH - 328 Tracking ID-422/tukxi/04/2013...
Page 329
MSS APE 50 (2012) Chassis Lightly tighten the screws and fix the spring and the plate locking the glass to the door. Position the arm under the spring so that the glass closes tightly. Fully tighten the fixing screws of the spring to the door.
Page 330
MSS APE 50 (2012) Chassis Rear window KEY: 1. Glass 2. Gasket Removal PREPARATION: Before removing the rear screen, it is necessary to make provisions for the following equipment: - Metal levers for removing windows; - Stiff rope for installing windows. Working from inside the cab, insert the small metal levers between the gasket and the seat of rear screen, so as to push the latter towards the out-...
Page 331
MSS APE 50 (2012) Chassis Proceed along the width of the rear screen until the lower part is fully released. CAUTION SUPPORT THE REAR SCREEN FROM THE OUTSIDE. Remove the rear screen. Refitting Apply the gasket on the rear screen. Insert the stiff rope in the sealing gasket groove.
Page 332
MSS APE 50 (2012) Chassis Insert the rear screen in its seat, making sure that the two ends of the stiff rope are positioned inside the cab. Pull the stiff rope and simultaneously press the rear screen evenly from the outside so that it is positioned properly in its seat.
Page 333
MSS APE 50 (2012) Chassis 2. Cowl 3. Elastic plate 4. Upper gasket 5. Lower gasket 6. Screw 7. Plate 8. Belt REMOVAL: Remove the rear view mirror by undoing the fixing nut. Undo the fixing screw and remove the upper cowl. Remove the plate underneath.
Page 334
MSS APE 50 (2012) Chassis From inside the cab, undo the fixing screw of the bumper. Offset the bumper in order to release the fixing of the door to the frame. Undo the fixing screws of the belt to the cab. Remove the belt and its plate.
Page 335
MSS APE 50 (2012) Chassis Undo the fixing bolts of the door to the cab. CAUTION DURING THIS OPERATION, SUPPORT THE DOOR. Remove the complete door. REFITTING: Support the door and tighten the fixing bolts of the door to the cab. Refit the plate on the chassis.
Page 336
MSS APE 50 (2012) Chassis Tighten the fixing screw and refit the upper cowl. Tighten the fixing screw inside the cab and lock the bumper. Tighten the fixing screws and refit the belt with its plate. Pannelli REMOVAL: Remove the plate locking the glass to the door. Undo the fixing screws of the storage pouch.
Page 337
MSS APE 50 (2012) Chassis Remove the storage pouch. Using a lever, detach the panel, along its entire perimeter, from the door. CAUTION BE CAREFUL NOT TO DAMAGE THE PANEL AND THE DOOR. Remove the door panel. REFITTING: Replace the double-sided tape placed in the lower end of the panel.
Page 338
MSS APE 50 (2012) Chassis Apply the panel in its seat, by pressing lightly on the bottom so that the double-sided tape is stably fixed to the door. Tighten the fixing screws and lock the storage pouch. Refit the plate locking the glass to the door. Serratura e maniglie KEY: 1.
Page 339
MSS APE 50 (2012) Chassis 2. Handle 3. Cotter pin 4. Left safety lock box 5. Screw d3.5x9.5 6. Spring 7. Protection 8. Handle 9. TCB screw 3.5x19 10.Washer 4.5x12x1 11.Button covering 12.Self-tapping screw 4.2x16 13.Cowl 14.Elastic plate HANDLE REMOVAL: Remove the door panel.
Page 340
MSS APE 50 (2012) Chassis With the aid of a hammer and a punch, remove the pin. Remove the handle and the spring. LEFT SAFETY LOCK REMOVAL: Undo the fixing screws of the left safety lock. Remove the left safety lock. N.B.
Page 341
MSS APE 50 (2012) Chassis RIGHT DOOR CLOSING CYLINDER REMOVAL: Undo the locking nut of the cylinder. Remove the locking nut and the washer. From the outside remove the right door closing cylinder. RIGHT DOOR CLOSING CYLINDER REFIT- TING: Insert the cylinder in the appropriate slot on the right door.
Page 342
MSS APE 50 (2012) Chassis Insert the washer and tighten the locking nut. LEFT SAFETY LOCK REFITTING: Tighten the fixing screws and lock the safety lock to the left door. HANDLE REFITTING: Insert the handle with its spring in the appropriate slot on the door.
Page 343
MSS APE 50 (2012) Chassis Using a rubber hammer, insert the pin. Insert the cotter pin. CAUTION USE A NEW COTTER PIN. Position the external handle, supporting it, of the door in its seat. CAUTION BEFORE FULLY TIGHTENING THE SCREWS, PERFECTLY CENTRE THE HANDLE.
Page 344
MSS APE 50 (2012) Chassis Longitudinal adjustments Act on the bolts fixing the door to make the vertical adjustment. Rain seal SEAL GASKET REMOVAL: Lift the glass and remove the external glass gasket along the entire perimeter. CH - 344 Tracking ID-422/tukxi/04/2013...
Page 345
MSS APE 50 (2012) Chassis Remove the upper and lower gaskets of the door. SEAL GASKET INSTALLATION: Remove the film of the double-sided tape to the door gaskets, both lower and upper. Position the gaskets properly along the entire pe- rimeter of the door.
Page 346
MSS APE 50 (2012) Chassis Position the glass seal properly along the entire perimeter of its housing. Press lightly making sure it is set uniformly. CAUTION BE SURE TO POSITION THE GLASS GASKET ALONG THE OUTER PERIMETER. Front bumper KEY: 1.
Page 347
MSS APE 50 (2012) Chassis KEY: 1. Flat washer 4.2x12x1 2. Gasket 3. Self-tapping screw M3.5x13 4. Panel REMOVAL: Undo the fixing screws of the bumper at the base of the door. CH - 347 Tracking ID-422/tukxi/04/2013...
Page 348
MSS APE 50 (2012) Chassis Remove the bumper from the base of the door. Undo the fixing screw, located inside the cab, from the bumper. Undo the external screw. Remove the side bumper. Also repeat the operations from the other side of the vehicle.
Page 349
MSS APE 50 (2012) Chassis REFITTING: Position the side bumper into place, taking care that it completely covers the fixing bolt of the door to the frame. Tighten the fixing screw. Tighten the fixing screw inside the cab and lock the side bumper.
Page 350
MSS APE 50 (2012) Chassis Rear bumper KEY: 1. Rear bumper 2. Rivet 3. Strip REMOVAL: Remove the rear lights. Undo the bolts that secure the bumper to the frame. CH - 350 Tracking ID-422/tukxi/04/2013...
Page 351
MSS APE 50 (2012) Chassis Remove the rear bumper. REFITTING: Approach the bumper to the chassis and lock it by screwing the fixing bolts. Refit the rear lights. Mudguards KEY: 1. Mudguard CH - 351 Tracking ID-422/tukxi/04/2013...
Page 352
MSS APE 50 (2012) Chassis 2. Flat washer 16x6.5x1.5 3. Screw TE M6x18 4. Mudguard 5. Screw 6. Rivet 7. Rivet 8. Bracket 9. Splash guard 10.Flat washer 4.2x12x1 11.Plate 12.Protective cover 13.Protective cover FRONT MUDGUARD REMOVAL: Remove the side bumper from both sides of the vehicle.
Page 353
MSS APE 50 (2012) Chassis Undo the fixing screws and remove the horn. FRONT MUDGUARD REFITTING: Tighten the fixing screws and refit the horn. Approach the mudguard to the chassis and attach the electrical connection of the horn. From inside the cab tighten the fixing screws and lock the mudguard.
Page 354
MSS APE 50 (2012) Chassis REAR MUDGUARD REMOVAL: Lift the vehicle using the lift. Undo the fixing nuts of the rear wheel. CAUTION MAKE SURE THAT THE SIDE ARMS OF THE LIFT ARE CORRECTLY WELDED AND POSITIONED IN CORRE- SPONDENCE WITH THE LIFTING POINTS. Remove the rear wheel.
Page 355
MSS APE 50 (2012) Chassis Refit the rear wheel and tighten its nuts. Locking torques (N*m) Rear wheel- Drum 24 ± 4 Nm Rear body KEY: 1. Handle 2. Rear hatch 3. Handle 4. Cotter pin 5. Pin 6. Washer 7.
Page 356
MSS APE 50 (2012) Chassis REAR HATCH REMOVAL: Remove the fixing bolt of the cable to the dropside. Remove the fixing bolt to the rear hatch and re- move the cable. Repeat these operations also for the cable located on the other side of the hatch. With the aid of a screwdriver, remove the locking ring of the pin of the handle.
Page 357
MSS APE 50 (2012) Chassis Remove the handle and its washer underneath. Also repeat the operations for the handle located on the other side. Remove the lower cotter pin locking the hinge. With the aid of a hammer and a punch, remove the pin.
Page 358
MSS APE 50 (2012) Chassis REAR HATCH REFITTING: Position the rear hatch in its seat correctly in order to align the holes for the insertion of the locking pins to the hinges. Using a rubber hammer insert the pins. Insert the cotter pins locking the pins. N.B.
Page 359
MSS APE 50 (2012) Chassis Insert the fixing ring and the washer. Also repeat the operations for the handle located on the other side of the deck. Fit the cable to the dropside tightening the fixing bolt with its washer. Lock the cable to the rear hatch by tightening the fixing bolt with its washer.
Page 360
MSS APE 50 (2012) Chassis Replacing the exhaust KEY: 1. Kat silencer 2. Gasket 3. Toothed washer 6.6x11x0 4. M6 nut 5. Hexagonal screw 6. 13.75x8.15x4.5 flexible washer 7. Flat washer 8.2x20x2.5 REMOVAL: Lift the vehicle using the lift. Disconnect the cap from the spark plug. CAUTION MAKE SURE THAT THE SIDE ARMS OF THE LIFT ARE CORRECTLY WELDED AND POSITIONED IN CORRE-...
Page 361
MSS APE 50 (2012) Chassis Remove the retainer clamp of the pipe to the cleaner. Disconnect the rubber hose from the cleaner. Undo the nut of the locking ring of the carburettor to the admission joint. Partially eject the carburettor with cleaner from the admission joint in order to facilitate the removal of the cooling hood.
Page 362
MSS APE 50 (2012) Chassis Undo the screws fastening the cooling hood to the engine. Remove the cooling hood. Undo the fixing screws of the silencer to the engine support. Undo the fixing nuts of the silencer to the engine head.
Page 363
MSS APE 50 (2012) Chassis Remove the left rear wheel. To access the remaining fixtures of the silencer, it is necessary to offset the fitting of the cleaner; for this, unscrew the fixing screws of the support bridge of the joint. Remove the bridge.
Page 364
MSS APE 50 (2012) Chassis Remove the rubber sleeve from the silencer. For the extraction of the silencer it is necessary to lower the engine. Hold the engine with a workshop jack. Undo the fixing screw of the engine support brack- et to the frame.
Page 365
MSS APE 50 (2012) Chassis Lower the engine by operating on the workshop jack. CAUTION ACT WITH EXTREME CAUTION ON THE WORKSHOP JACK. Remove the silencer. REFITTING: Reposition the silencer in its seat. CAUTION BEFORE PROCEEDING WITH THE REPLACEMENT OF PARTS, MAKE SURE YOU HAVE CORRECTLY PLACED THE SILENCER MATCHING THE FIXING HOLES.
Page 366
MSS APE 50 (2012) Chassis Tighten the fixing nuts of the silencer to the engine head. Locking torques (N*m) Silencer - Engine head 5.9 ± 1 Nm Tighten the fixing screws of the silencer to the en- gine support. Locking torques (N*m) Silencer - Engine support 23.6 ±...
Page 367
MSS APE 50 (2012) Chassis Insert the sleeve on the secondary air system box cover. Tighten the cover with the silencer on the secon- dary air system box cover. Insert and lock the new retaining clips on the rub- ber sleeve, silencer side and secondary air system box cover side.
Page 368
MSS APE 50 (2012) Chassis Tighten the fixing screws and lock the cooling hood to the engine. Lift the engine by operating on the workshop jack. Insert the bracket to the chassis. Repeat these operations to also release the other side of the engine support from the frame.
Page 369
MSS APE 50 (2012) Chassis Refit the cap on the spark plug. Refit the carburettor on the admission joint. Tighten the nut of the ring and lock the carburettor to the admission joint. Refit the rubber hose on the cleaner and secure it using a new clamp.
MSS APE 50 (2012) Chassis Correctly reposition the fitting of the cleaner and tighten the fixing screws of the supporting bridge of the fitting to the frame. Refit the left rear wheel. Light unit KEY: 1. Front mask 2. Front mask grille 3.
Page 372
MSS APE 50 (2012) Chassis FRONT LIGHT UNIT REMOVAL: Disconnect the electrical wiring of the front head- light. Undo the fixing screws of the headlamp internal cover. Remove the internal cover of the headlamp. Remove the electrical connections from the head- lamp.
Page 373
MSS APE 50 (2012) Chassis Remove the bulb. Press the headlamp towards the outside to release CAUTION WHEN CARRYING OUT THIS OPERATION, ANOTHER PERSON SUPPORTING THE HEADLAMP FROM THE OUT- SIDE IS NEEDED. Remove the headlamp from the outside. Undo the fixing screws of the transparent of the turn indicator.
Page 374
MSS APE 50 (2012) Chassis Remove the transparent of the turn indicator. Remove the bulb holder. Remove the electrical connections from the bulb holder. FRONT LIGHT UNIT REFITTING: Reconnect the electrical connections on the bulb holder. CH - 374 Tracking ID-422/tukxi/04/2013...
Page 375
MSS APE 50 (2012) Chassis Insert the bulb holder in its seat. CAUTION PAY ATTENTION THAT THE PIN ON THE INSIDE OF THE BULB HOLDER FITS PERFECTLY INTO THE HOLE IN THE HOUSING ON THE MASK. Fit the transparent of the turn indicator and lock it with the fixing screws.
Page 376
MSS APE 50 (2012) Chassis Reconnect the electrical connections to the head- lamp present on the cover. Tighten the fixing screws of the headlamp internal cover. Reconnect the electrical wiring of the front head- light. Adjust the light beam of the headlights. FRONT MASK REMOVAL Unscrew the locking screws of the belt of the door in order to access the fixing of the mask.
Page 377
MSS APE 50 (2012) Chassis Undo the fixing screw located on the upright of the door side frame. From inside the cab, undo the fixing screws of the mask. Disconnect all electrical cables of the front light unit. Remove the mask with the front light unit. Remove the headlights and the turn indicators.
Page 378
MSS APE 50 (2012) Chassis Tighten the fixing screw located on the upright of the door side frame. Tighten the fixing screws of the belt of the door. REAR LIGHT UNIT REMOVAL: Undo the fixing screws of the rear light transparent. Remove the transparent.
Page 379
MSS APE 50 (2012) Chassis From the rear, remove the protective cap of the electrical wiring. Disconnect the electrical wiring of the light. Remove the rear light. REAR LIGHT UNIT REFITTING: Reinsert the rear light in its housing on the bumper. CH - 379 Tracking ID-422/tukxi/04/2013...
Page 380
MSS APE 50 (2012) Chassis Reconnect the electrical wiring of the rear light. Refit the rubber cap on the connector. Refit the transparent of the light and lock it by tight- ening the fixing screws. CH - 380 Tracking ID-422/tukxi/04/2013...
Page 381
MSS APE 50 (2012) Chassis KEY: 1. Internal light 2. Screw From inside the cab, disconnect the transparent. Disconnect the electrical connections and remove the bulb. CH - 381 Tracking ID-422/tukxi/04/2013...
Page 382
MSS APE 50 (2012) Chassis Undo the fixing screws and remove the internal light. INTERNAL COURTESY LIGHT REFITTING: Refit the internal light in its seat and lock it by tight- ening its fixing screws. Refit the bulb and reconnect the electrical connec- tions.
MSS APE 50 (2012) Chassis Instrument panel REMOVAL: The following steps describe how to properly re- move the dashboard and various components. Remove the negative battery terminal clamp (-). Disconnect the electric connection for the cigarette lighter. Undo the two side fixing screws of the upper cen- tral dashboard.
Page 384
MSS APE 50 (2012) Chassis Remove the ash tray. Undo the central fixing screw and remove the up- per central instrument panel. Undo the fixing screws of the edge. Remove the edge. CH - 384 Tracking ID-422/tukxi/04/2013...
Page 385
MSS APE 50 (2012) Chassis From under the instrument panel, unscrew and re- move the connection of the odometer. On the rear wheel, loosen the adjusting nut of the brake transmission. From the brake lever on the handlebar, remove the transmission of the front brake.
Page 386
MSS APE 50 (2012) Chassis Disconnect the electrical connections of all the switches. Press from inside the handlebar coverage, remove all the switches. Remove the central bulb from the instrument pan- Remove all remaining side lamps from the instru- ment panel. CH - 386 Tracking ID-422/tukxi/04/2013...
Page 387
MSS APE 50 (2012) Chassis Remove the handlebar cover and undo the fixing nut of the instrument panel. Remove the instrument panel. N.B. TO REMOVE THE INSTRUMENT PANEL ONLY, IT IS NOT NECESSARY TO REMOVE THE HANDLE COVER; IT IS POSSIBLE TO REMOVE THE FIXING NUT BY ACTING UN- DER THE HANDLEBAR.
Page 388
MSS APE 50 (2012) Chassis Remove the rubber tube of the window washer. Undo the fixing screw of the dashboard. Using a suitable lever release the dashboard from the cab, removing the rubber plugs. Remove the dashboard from the cab. N.B.
Page 389
MSS APE 50 (2012) Chassis Undo the fixing screws of the upper central cover. Remove the upper central cover. Offset the carpet on the floor and undo the screws holding the lower central cover. Remove the lower central cover. CH - 389 Tracking ID-422/tukxi/04/2013...
Page 390
MSS APE 50 (2012) Chassis Undo the fixing screws and remove the sun screens. REFITTING: Tighten the fixing screws and refit the sun screens. Reposition the lower central cover in its seat cov- ering all transmissions and lock it by tightening the fixing screws.
Page 391
MSS APE 50 (2012) Chassis Reposition the dashboard in its seat inside the cab, inserting the air tube in its lower part. Press the rubber plugs in their seats to fix the dashboard. Tighten the fixing screw and lock the dashboard. Pass the rubber hose through the appropriate hole on the dashboard to the and reconnect it properly to the window washer.
Page 392
MSS APE 50 (2012) Chassis Pass the electrical cables inside the hole on the dashboard. Refit the instrument panel on the cover of the han- dlebar and lock it by screwing the relative nut. Reposition all the bulbs in the instrument panel. CAUTION MATCH THE NUMERICAL INSTRUCTIONS ON THE WIR- ING OF THE BULBS WITH THOSE ON THE INSTRUMENT...
Page 393
MSS APE 50 (2012) Chassis Reconnect the electrical connections of all the switches. Correctly reposition the cover in its seat above the handlebar and lock it by tightening the fixing screws. Refit on the appropriate lever on the handlebar the transmission of the front brake.
Page 394
MSS APE 50 (2012) Chassis Reposition the internal edge of the cab. Tighten the fixing screws and lock the edge. Tighten the central screw of the upper dashboard. Tighten the side fixing screws of the upper dash- board to the edge. CH - 394 Tracking ID-422/tukxi/04/2013...
Page 395
MSS APE 50 (2012) Chassis Refit the ash tray. Connect the electric connection for the cigarette lighter. Connect the negative battery terminal clamp (-). Sedili - Cinture di sicurezza KEY: 1. Bolt CH - 395 Tracking ID-422/tukxi/04/2013...
Page 396
MSS APE 50 (2012) Chassis 2. Cushion 3. Seat back 4. Clip REMOVAL: Undo the fixing bolts of the seat. Remove the seat. Lever with your hands, disconnect the seat back from the cab and remove the clips underneath. REFITTING: Apply the clips and the seat back in its seat inside the cab.
Page 397
MSS APE 50 (2012) Chassis Lock the seat back by pushing it until it clicks. Place the seat in place. Tighten the fixing bolts and lock the seat. CH - 397 Tracking ID-422/tukxi/04/2013...
Page 399
MSS APE 50 (2012) Chassis REMOVAL: Lift the vehicle using the lift. Close the valve underneath the tank. CAUTION MAKE SURE THAT THE SIDE ARMS OF THE LIFT ARE CORRECTLY WELDED AND POSITIONED IN CORRE- SPONDENCE WITH THE LIFTING POINTS. Remove the retainer clamp of the fuel pipe.
Page 400
MSS APE 50 (2012) Chassis Tighten the fixing screws and remove the front clamp. Unscrew the fixing screws and remove the rear clamp. Carefully lower the workshop jack and remove the fuel tank. Empty the tank. REFITTING: Position the tank in its seat supporting it with a workshop jack.
Page 401
MSS APE 50 (2012) Chassis Tighten the fixing screws and lock the front clamp. Replace the rubber hose on the tap and secure it using a new clamp. N.B. ALWAYS USE NEW CLAMPS. Open the fuel cock. CH - 401 Tracking ID-422/tukxi/04/2013...
Page 402
MSS APE 50 (2012) Chassis Batterie KEY: 1. Battery 2. Tray 3. Belt 4. Breather tube 5. Rivet 6. Plate 7. Battery cable 8. Battery cable REMOVAL: Disconnect the strap to release the battery. CH - 402 Tracking ID-422/tukxi/04/2013...
Page 403
MSS APE 50 (2012) Chassis Undo the nut and disconnect the positive battery cable (+). Undo the nut and disconnect the negative battery cable (-). Remove the battery, lifting it upwards. REFITTING: Reposition the battery in its seat. Connect the negative battery cable (-). Connect the positive battery cable (+).
Page 404
MSS APE 50 (2012) Chassis Attach the belt to the appropriate hook to lock the battery. CH - 404 Tracking ID-422/tukxi/04/2013...
Page 405
INDEX OF TOPICS DELIVERY Tracking ID-422/tukxi/04/2013...
Page 406
MSS APE 50 (2012) Pre-delivery CAUTION (FOR VEHICLES EQUIPPED WITH "MARELLI" ALTERNATOR): AT THE TIME OF INSTALLING THE BATTERY ON THE VEHICLE OR IN THE EVENT OF STARTING WITH AN AUXILIARY BAT- TERY AND STEERING WHEEL CABLES, TAKE GREAT CARE TO NOT INVERT THE POLARITY': THIS RESULTS IN A FAST BURNING OF THE BATTERY-ALTERNATOR CONNECTING CABLE WITH RISK OF FIRE.
Page 407
MSS APE 50 (2012) Pre-delivery General inspection Vehicle external appearance Check for any damage to the exterior of the vehi- cle. - Body Painting - Mouldings - Glass windows - Exterior mirrors - Headlamp glass - Bumper External bodywork Open and close the door with key. Open and close each door with the internal lock.
Page 408
MSS APE 50 (2012) Pre-delivery 9. Adjust mirrors aiming. Internal vehicle cleaning Carry out the following operations: 1. Remove any trace of grease or dirt off the inter- nal surfaces. 2. Completely remove all plastic covers from seats, sun screens, instruments panel. 3.
Page 409
MSS APE 50 (2012) Pre-delivery Tyre pressure Tyre pressure Check inflation pressure. Adjust inflation pressure of each tyre to the pre- scribed value. Tyre pressure is also indicated on the specific ad- hesive label affixed to the vehicle. TYRE PRESSURE Specification Desc./Quantity Rear tyre pressure...
Page 410
MSS APE 50 (2012) Pre-delivery Horn operation Check if the horn sounds every time you press the button. Wipers operation Operation of windscreen wiper and washer Check that: - The windshield wipers work smoothly. - The washer fluid is sprayed in the centre of the windscreen.
MSS APE 50 (2012) Pre-delivery Turn signals operation Check the operation of the external turn indicators (left and right). External lights Check the operation of the following external lights: - Headlamps, high and low beams. - Rear lights and stop lights. - License plate lights.
MSS APE 50 (2012) Pre-delivery Warning lights Warning lights (instrument panel) Check the operation of warning lights. (The ignition switch must be set to "ON "). Oil pressure warning light Low fuel warning light Turn indicator flashing Light warning lights Chassis inspection Perform an integrity check of the lower part of the body.
Page 413
MSS APE 50 (2012) Pre-delivery Leakages Check for any fluid leaks from the following com- ponents: - Engine - Transmission - Differential - Fuel pipe - Fuel tank and filler plug Engine housing inspection Battery connections Check the following: - Corroded or loose connections. - Battery terminals unthreaded due to loosening.
MSS APE 50 (2012) Pre-delivery Wait for a minute for the idle to stabilise. Without ever operating the accelerator and using the appropriate flow screw, bring the engine speed to 1350 ±100 rpm. Operate the throttle grip by slowly speeding up the engine to a speed of 4000 rpm.
Page 415
MSS APE 50 (2012) Pre-delivery Remove the filler plug with the control rod from the upper part of the differential crankcase. WARNING DO NOT REMOVE THE OIL COVER IMMEDIATELY AFTER AN ACTIVITY WITH THE ENGINE AT FULL SPEED AND/OR WITH THE ENGINE RUNNING. THE HEATED OIL MAY LEAK, WITH THE RISK OF BURNING.
Page 416
MSS APE 50 (2012) Pre-delivery Brake pedal adjustment Operation of the service and parking brake - The vehicle must brake in a straight line. - Park the vehicle on a slope and operate the park- ing brake. The vehicle must remain in position. - The lever of the parking brake must rise from 6 to 10 notches when a force of 20 kg is applied.
MSS APE 50 (2012) Pre-delivery Road test Operation of the engine at minimum and ac- celerator partial opening At idle Note the idle with engine fully warmed up. For partially open throttle The performance must be regular and free of breaks.
Page 418
INDEX OF TOPICS TEMP SHEET Tracking ID-422/tukxi/04/2013...
Page 419
MSS APE 50 (2012) Time-sheet Engine Engine, assembly COMPLETE ENGINE Code Action Duration 001001 ENGINE FROM THE FRAME - RE- PLACEMENT 001032 ENGINE SUPPORT - REPLACE- MENT 003016 ENGINE SUPPORT FRONT BUF- FERS - REPLACEMENT 003017 ENGINE SUPPORT REAR BUFFER - REPLACEMENT 003052 IGNITION TIMING...
Need help?
Do you have a question about the MSS APE 50 2012 and is the answer not in the manual?
Questions and answers
