Smart-RTC
Recommended settings for room set
temperature 22°C
Panel heating (35/28 °C)
(floor, wall, ceiling)
Low-temperature radiators (45/38 °C)
Radiators (55/45 °C)
To achieve optimum regulation, select as small a controlling
range as possible between the minimum and maximum return
temperature. Automatic operating mode switching makes it
Elimination of faults:
Building too hot
Building is not heating up
Reference room is hot,
but individual rooms (e.g. bathroom) too cold
Reference room is not
reaching the room set temperature,
but individual rooms (e.g. bathroom) are hot
Start-up must be performed in accordance with the installation
and operating instructions of the heat pump manager.
EN-6
Minimum return temperature
22 °C
25 °C
30 °C
possible to set an external temperature above which heating
operation is blocked.
Measure 1
Reduce room set temperature
Raise room set temperature,
increase volume flow
Carry out hydraulic equalisation (reduce
volume flow in the reference room)
Carry out hydraulic equalisation (raise
volume flow in the reference room)
452114.66.73 · FD 9306
Maximum return temperature
30 °C
40 °C
50 °C
Measure 2
Reduce minimum return temperature
Raise maximum return temperature
Raise minimum return temperature.
This can lead to the room set temperature in
the reference room being periodically
overshot.
Raise maximum return temperature
