Table of contents
About Compact Disc Digital Audio... ....................................................... 2
Front panel ................................................................................................... 3
Display .......................................................................................................... 6
Remote Control ........................................................................................... 7
Rear panel, PCD 3 ....................................................................................... 8
Rear panel, PDT 3 ...................................................................................... 10
Unpacking ................................................................................................. 12
Set-up and installation .............................................................................. 13
Installing the spikes (optional) ................................................................ 13
Removing the transport screws ............................................................. 14
Location .................................................................................................... 15
A word about cables .............................................................................. 15
A word about balanced output ........................................................... 15
Audio connections, PCD 3 ..................................................................... 15
Audio connections, PDT 3 ...................................................................... 16
Power supply connection ...................................................................... 16
master power switch ............................................................................... 16
Installing batteries in the Remote Control ............................................ 16
Basic operation ......................................................................................... 17
Loading a CD .......................................................................................... 17
Playing all tracks on a CD ...................................................................... 17
Beginning play with a track other than the first track ......................... 17
Replaying a track .................................................................................... 18
Skipping to another track ....................................................................... 18
Searching for a passage on the CD ..................................................... 18
Beginning play in the middle of a track ............................................... 18
The "pause" function ............................................................................... 19
Repeating all tracks on the CD ............................................................. 19
Stopping play ........................................................................................... 19
Programming ............................................................................................. 20
Entering a program ................................................................................. 20
Replaying a selection in the program .................................................. 20
Skipping to another selection in the program ..................................... 21
Searching for a passage in the program ............................................. 21
The "pause" function ............................................................................... 21
Repeating all tracks in a program ......................................................... 21
Stopping play ........................................................................................... 21
Care and maintenance ........................................................................... 22
Cleaning the PCD 3/PDT 3 ..................................................................... 22
Caring for the Remote Control .............................................................. 22
Caring for Compact Discs ...................................................................... 22
Specifications, PCD 3 ................................................................................ 23
Pin assignments, male XLR balanced analog output ......................... 23
Specifications, PDT 3 ................................................................................. 24
Pin assignments, male XLR digital output ............................................. 24
Troubleshooting ......................................................................................... 25
Service ....................................................................................................... 27
1
Advertisement
Table of Contents
Related Manuals for PROCEED PCD 3
Summary of Contents for PROCEED PCD 3
-
Page 1: Table Of Contents
Repeating all tracks in a program ............21 Stopping play ................... 21 Care and maintenance ................22 Cleaning the PCD 3/PDT 3 ..............22 Caring for the Remote Control .............. 22 Caring for Compact Discs ..............22 Specifications, PCD 3 ................23 Pin assignments, male XLR balanced analog output ...... -
Page 2: About Compact Disc Digital Audio
About Compact Disc Digital Audio… To most people, a Compact Disc (CD) looks like a small, silver phonograph record. In fact, there are some important differences between records and CDs. The information on a phonograph record is contained within its grooves. -
Page 3: Front Panel
When the master power switch on the rear panel is in the "|" (on) position, pressing this button takes the PCD 3/PDT 3 out of “standby” mode, turns the Display on, and makes the PCD 3/PDT 3 ready to play a CD. Pressing the button again puts the PCD 3/PDT 3 in standby mode and clears any previously programmed sequence of selections. - Page 4 pause While a CD is playing, pressing this button suspends play; pressing it again resumes play at the point where pause was first pressed. The LED above the pause button lights while play is suspended. next Pressing this button while a CD is playing suspends play, “skips” to the next track on the CD (or the next track in a programmed sequence), and begins playing that track.
- Page 5 12 repeat Pressing this button before or during play causes all tracks on the CD (or all selections in a programmed sequence) to repeat indefinitely. To cancel this function, press repeat again. The LED above the repeat button lights while the repeat function is active.
-
Page 6: Display
Display TRACK INDEX TRACK Before play begins, this part of the Display shows the total number of tracks on the CD. During play, this part of the Display shows the number of the track in play. While play is suspended using pause, it shows the track that was playing when play was suspended. -
Page 7: Remote Control
Pressing a track number during play, then pressing PLAY, skips to that track and begins play, then continues playing tracks on the CD in order. 11 Projection lens Infrared (IR) commands from the Remote Control to the PCD 3/PDT 3 are transmitted through this lens. -
Page 8: Rear Panel, Pcd 3
This switch turns the PCD 3 on and off. The switch must be in the "|" (on) position for the PCD 3 to operate. (See "Set-up and installation.") PRECAUTION NEVER operate the master power switch without first making sure that power is turned off to your receiver, integrated amplifier, or preamplifier/power amplifier. - Page 9 AC power cord This cord supplies AC power to the PCD 3. (See "Set-up and installation.") Fuse This holder contains the main fuse for the PCD 3. If the fuse ever needs to be replaced, contact your Proceed dealer.
-
Page 10: Rear Panel, Pdt 3
FIRE, REPLACE ONLY WITH THE SAME TYPE OF FUSE: 25 WATTS VOLTS A, 250V PROCEED ® PDT 3 master made in u.s.a. power master power This switch turns the PDT 3 on and off. The switch must be in the "|"... - Page 11 (See "Set-up and installation.") AC power cord This cord supplies AC power to the PDT 3. (See "Set-up and installation.") Fuse This holder contains the main fuse for the PDT 3. If the fuse ever needs to be replaced, contact your Proceed dealer.
-
Page 12: Unpacking
Unpacking Carefully open the shipping carton and remove the contents. You should have: Proceed PCD 3/PDT 3 Four spikes Hex key Remote control Owner’s manual Save the shipping carton and all packing material. Though it may be inconvenient to store, it’ll come in handy for shipping if you move, or if the unit needs to be shipped for service. -
Page 13: Set-Up And Installation
Installing the spikes 3. The PCD 3/PDT 3 is shipped so that it rests solidly on two wide "feet," (optional) positioned under the front and back of the unit. -
Page 14: Removing The Transport Screws
You may choose instead to install the spikes in a triangular arrangement: Three spikes, mounted in a triangular pattern Install the spikes one at a time. Using the supplied hex key, remove the screw securing the foot to the base of the unit. Insert the threaded end of the spike through the hole in the foot, then turn it clockwise until it's hand-tight. -
Page 15: Location
Audio connections, PCD 3 9. Using a pair of high-quality audio cables, connect the left and right outputs of the PCD 3 to the left and right “CD” inputs of your receiver, integrated amplifier, or preamplifier. Make sure to connect the left output of the PCD 3 to the left input of the receiver, integrated amplifier, or preamplifier, and likewise for the right channel. -
Page 16: Audio Connections, Pdt 3
NEVER connect the PDT 3's digital output to PHONO inputs. Power supply connection 12. Connect the power supply cord of the PCD 3/PDT 3 to an unswitched convenience outlet (like those on the rear panel of many audio components). If you connect the PCD 3/PDT 3 directly to a wall outlet, make sure that the outlet has polarized sockets. -
Page 17: Basic Operation
Basic operation In this section, you’ll learn how to: Load a CD; Play all tracks on a CD; Begin play with a track other than the first track; Replay a track; Skip to another track; Find a particular passage on the CD; Begin play in the middle of a track;... -
Page 18: Replaying A Track
2. Press play to begin playing that track (followed by the remaining tracks on the CD). Replaying a track To return to the beginning of a track while it is playing, press play. Play will be suspended briefly, then that track will replay followed by the remaining tracks on the CD. -
Page 19: The "Pause" Function
The "pause" function To suspend play while a CD is playing, press pause. The LED above the pause button will light while play is suspended. To resume play, press pause again. To hold play at the beginning of a CD or track (for faster cueing), press pause before pressing play. -
Page 20: Programming
Rather than playing an entire CD, you may choose to play only certain selections. To do this, you'll need to create a “program” and store it in the PCD 3/PDT 3's memory. The memory will accept up to twenty entries. -
Page 21: Skipping To Another Selection In The Program
Skipping to another next and prev function in the normal way, except that they move selection in the program forward and backward among the selections in the program. Tracks that aren’t included in the program are skipped. If you use the numbered buttons on the Remote Control to select a track that isn’t part of the current program, the error LED will flash. -
Page 22: Care And Maintenance
Care and maintenance Cleaning the PCD 3/PDT 3 To clean your PCD 3/PDT 3, use a soft cloth moistened with plain water. Don’t apply water, dusting sprays, solvents, abrasives, or cleaning fluids directly to the cabinet. Make sure that the remote sensor window on the front panel of the unit and the Remote Control’s projection lens are kept clean and dust-... -
Page 23: Specifications, Pcd 3
Specifications, PCD 3 Frequency response: 10 Hz – 20 kHz +0dB, -0.2dB Total harmonic distortion (THD): 0.004% @ 1 kHz, 0dB Dynamic range: 104dB (or better) Signal-to-noise ratio: 107dB Channel separation: 120dB Intermodulation distortion (SMPTE IMD): 0.008% Digital-to-analog conversion: Two precision 20-bit DACs... -
Page 24: Specifications, Pdt 3
Specifications, PDT 3 Direct digital output, RCA: SPDIF standard format Direct digital output, XLR: AES/EBU standard format Direct digital output, ST: AT&T standard format Direct digital output, TOSLINK: EIAJ standard format Mains voltage: 120 V U.S. service Mains frequency: 50/60 Hz Power consumption: 21W @ 120V, 60 Hz Shipping weight:... -
Page 25: Troubleshooting
The PCD 3/PDT 3's fuse is blown (contact your Proceed dealer). 2. The PCD 3/PDT 3 won’t play a CD inserted in the player. The CD is inserted upside down. A track number has been programmed that doesn’t exist on the CD. - Page 26 The Remote Control is at the wrong angle relative to the PCD 3/PDT 3, and the PCD 3/PDT 3 can’t receive the signal. The sensor window on the front panel of the PCD 3/PDT 3 is dirty or blocked. The Remote Control’s projection lens is dirty.
-
Page 27: Service
“Troubleshooting” section, contact your Proceed dealer. Your dealer will tell you what to do next. It’s important that your Proceed product be serviced only by an authorized Proceed service facility. This will ensure that proper repairs are made, and that your Proceed warranty stays in effect throughout... - Page 28 MADRIGAL AUDIO LABORATORIES, INC. 2081 South Main Street, P.O. Box 781 Middletown, Connecticut 06457 USA Telephone: (203) 346-0896 or 344-9300 Fax: (203) 346-1540 630107 ©1992 Madrigal Audio Laboratories, Inc. All rights reserved. Printed in U.S.A...
