INSTALLATION OF CL5010 LOCKS CONTINUED
14 Connect the cables, storing any excess cable within the door.
Then install the batteries.
15 Fit the back plate over the fixing plate using the 4 socket head screws.
16 Fit the cylinder cover and outside handle to the front plate.
17 Fit the inside handle to the back plate.
18 The inside handle will now retract the latchbolt. The outside handle will turn freely
without retracting the latch. Enter the factory Master Code #1234. The Blue LED will
flash and the outside handle will now retract the latch.
19 FITTING THE STRIKE PLATE
Position the strike plate on the doorframe so that the aperture lines up with the flat of the
latchbolt, and NOT the plunger. Mark the positions of the fixing screws and draw around
the aperture of the strike plate. Chisel out the aperture to 15mm
latchbolt. Fix the strike plate to the surface of the frame using only the top fixing screw.
Gently close the door and check that the latchbolt enters the aperture easily, and is held
without too much 'play'. When satisfied, draw around the outline of the strike plate,
remove it and cut a rebate to enable the strikeplate to lie flush with the surface. Re-fix
the strike plate using both screws.
N.B. The plunger beside the latchbolt deadlocks it to protect against manipulation or
'shimming'. The strike plate must be accurately installed so that the plunger CANNOT
enter the aperture when the door is closed, even when it is slammed shut.
8

INSTALLATION OF CL5010BB

1 Lightly mark a height line on the edge
2 Keeping the drill level and straight, drill
3 ") deep to receive the
( /
5
3 Keeping the drill level and straight, drill
4 Put the latch into the hole and, holding it
and both faces of the door and on the
door jamb, to indicate the top of the lock
when fitted. Crease the template along
one of the dotted lines (60mm (2
70mm (2 3 ") latch) and tape it to the
/
4
door with the top in line with the height
line. Mark the holes to be drilled. Mark
the centre line of latch on to the door
edge. Apply the template to the other
side of the door precisely against the
height line and the centre line of latch
mark. Mark the holes to be drilled again.
(See diagram A, page 6).
a 25mm (1") hole in the centre of the
door edge to accept the latch.
the holes in the door face. Drill from
both sides of the door to increase
accuracy and to avoid damage to the
other side when a drill goes right
through.
square to the door edge, draw around
the faceplate. Starting with the top and
bottom cuts, chisel a rebate to allow the
latch face to flush with the door edge.
(See diagram B on page 6 ).
3 ") or
/
8
