Summary of Contents for GAS GAS MC Boy 50
- Page 1 MANUAL DEL USUARIO USER MANUAL MANUEL D’ENTRETIEN LIBRETTO D’USO BETRIEBSANLEITUNG...
- Page 3 USER MANUAL USER MANUAL...
-
Page 5: Acknowledgements To The Purchaser
GAS GAS thanks you for the trust you have placed in us. We are delighted that you have selected the MC Boy 50 / EC Boy 50 motorcycle and we would like to welcome you to the GAS GAS family. -
Page 6: Important Warning
Important warning Read this Manual carefully. It contains all the necessary information for your safety, and that of others, as well as guaranteeing the correct conservation and maintenance of the GAS GAS motorcycle you have just acquired. All of the necessary instructions for the correct driving and handling of this vehicle are set out below. -
Page 7: Table Of Contents
Stopping the motorcycle Brake circuit - Bleeding Running-in period Front fork - Oil level Transmission oil - Checking the level Lubrication -Filling Identification -Changing Guarantee manual MC Boy 50 cooling system - Checking/filling EC Boy 50 cooling system - Checking... -
Page 8: Quick Guide To Maintenance
Quick guide to maintenance ENGINE Specifications Description EC Boy-50 MC Boy-50 Displacement / power cc/CV 49.38 / 5 49.38 / 12 Type Two-stroke single cylinder, layer admission directly to crankcase Number of cylinders 1 (one) Bore and stroke 39 x 41.8 mm Cooling system Liquid 2% mixture ratio... -
Page 9: Fuel - Petrol/Oil Mixture
Fuel – Petrol/oil mixture The motorcycle is fitted with a two-stroke internal combustion engine. This type of engine requires a mixture of petrol and oil. To ensure the correct working of the engine, the following are recommended: - Use high quality petrol, with an octane rating equal to or above 90 (RON + MON)/2 or 98 (RON). -
Page 10: Fuel Tap
Before starting the engine - Open the fuel tap. Note: - If the engine is cold then pull the choke upwards (A) and, then, rotate it a turn to the left or the right to secure it in place. Once the engine is turning over regularly at idle speed, return the choke (A) to the rest position. -
Page 11: Starting The Engine
Starting the engine Kick the start-pedal (A) in the direction shown by the arrow until the engine starts. Warning: once the engine is running, fold the kick starter into the engine. Stopping the engine -With the throttle grip in rest position (engine idle), press stop button (A) until the engine stops. -
Page 12: Riding The Motorcycle
Riding the motorcycle - To ride the motorcycle simply accelerate, this will activate the automatic clutch system. Stopping the motorcycle - Release the throttle lever. - Use the front (A) and rear (B) brakes. Warning: Depending on circumstances and ground surface, it may be better to use the front or rear brakes independently. -
Page 13: Running-In Period
Running-in period Transmission oil – Checking the Care of the engine during the first hours level of use is vital for obtaining the best from If the motorcycle has been used your motorcycle. recently, wait a few minutes before checking the Therefore, we recommend: level. -
Page 14: Filling
Transmission oil – Changing - Start the engine and keep it running until it warms up, then stop the engine. To drain out the used oil, remove the oil release plug (A) located underneath the engine. - Replace the drain plug using a new seal washer. Tighten to 20 Nm. -
Page 15: Mc Boy 50 Cooling System - Checking/Filling
MC Boy - 50 cooling system – Checking/filling The MC Boy-50 is fitted with a liquid cooling system. Warning: If the motorcycle has just been used, wait a few minutes before opening the radiator cap. Risk of burns! - Rotate the cap (A) anti-clockwise and remove it. - The level of coolant should be at the lower edge of the filler neck of the radiator, below the position of the cap seal. -
Page 16: Carburettor - Adjusting Throttle Cable
Carburettor – Adjusting throttle cable The throttle lever cable should have a free play of between 2 to 3 mm. If necessary, adjust as described below: - Raise the dust guard (A) on the throttle lever cable. - Turning the threaded terminal (B) to the right increases the play of the cable, and turning it to the left reduces the play. -
Page 17: Spark Plugs - Inspecting
Spark plugs – Inspecting The electrode separation is from 0.6 ~ 0.7 mm 0.6 to 0.7 mm. Air Filter – Cleaning A clean air filter not only improves engine performance but also prolongs its useful life. It should therefore be cleaned regularly. To reach the air filter, proceed as follows: - Remove the bolt indicated by the arrow, remove the seat by pulling it backwards to dislodge it from its forward... -
Page 18: Front Brake Fluid - Checking
Front brake fluid – Checking The level is correct if it falls within the upper half of the transparent window (A). If not, top up with a recommended brake fluid. 3 mm max. Front brake lever – Adjusting The front brake lever should have a maximum play of 3 mm. -
Page 19: Rear Wheel - Centre Alignment
Chain slack – Checking Rear wheel – Centre alignment Adjust chain tension with the The rear axle has easily eccentrics so that the slack in the graduated eccentrics for this tensed zone is 1.5 cm. operation. To ensure perfect wheel alignment, make sure that the marks of both eccentrics are in the same position on both sides. -
Page 20: Tyre Pressures - Checking
Tyre pressures – Checking Check tyre pressures regularly in order to obtain the best road holding possible. INFLATION PRESSURES: EC BOY-50 Front wheel: 0.8 BAR / 11.5 PSI Rear wheel: 0.8 BAR / 11.5 PSI MC BOY-50 Brake pads – Checking Front wheel: 0.9 BAR / 13 PSI The brake pads, both front and rear, Rear wheel: 0.8 BAR / 11.5 PSI... -
Page 21: Brake Circuit - Bleeding
Brake circuit – Bleeding If the system has been dismantled for repair, or if faults are detected in the brake system, the air in the hydraulic circuit can be removed using the bleeders (A). Once the air has been removed from the system, replace the rubber cap on the bleeder to prevent dirt from entering the system. -
Page 22: Lubrication
Lubrication Clean and lubricate frequently with oil: -The joint and spring of the foot pegs. Lubrication Clean and lubricate frequently with oil: -The joints of the clutch and front brake levers. Lubrication Clean and lubricate frequently with oil: - The joint of the kick-start pedal. -
Page 23: Identification
Lubrication Lubrication Clean and lubricate frequently with Clean and lubricate frequently with oil: oil: - The secondary chain. - The throttle lever, especially after washing the motorcycle with high-pressure hoses. Identification The serial number of the motorcycle is engraved on the steering tube. This number should match that which appears in the accompanying documents. -
Page 24: Guarantee Manual
Warranty terms of the manufacturer GASGAS Motos, S.A. The company GAS GAS MOTOS, S.A. (hereafter referred to as “GG”), with this present document guarantees the consumer, the purchaser of a vehicle manufactured by GG, that both the materials and the manufacturing are free of defects in accordance with the highest standards of quality. - Page 25 Obligation of the purchaser GG will have the right to reject any claims under Warranty in the event that: a) the purchaser has failed to submit the vehicle to any of the inspections and/or maintenance work required in the Users’ Manual, or has exceeded the date set for such inspections or maintenance work.
- Page 26 other environmental impact, or inadequate cleaning with inappropriate products e) any damages caused as a result of the defects, as well as any expenses incurred either directly or indirectly as a consequence of the defects (for example, communication costs, accommodation expenses, car hire costs, public transport costs, breakdown truck fees,, courier costs, etc.), as well as other financial losses (for example, those caused by the loss of the use of the vehicle, loss of income, time lost, etc.) f) any acoustic or aesthetic phenomenon that does not significantly affect the condition or use of the motorcycle (for example,...
- Page 28 Notes Notes...
- Page 29 Notes Notes...
- Page 32 RECOMIENDA EL USO DE ACEITE: RECOMMENDS THE USE OF OIL: RECOMMANDE L’USAGE DE L’HUILE: CONSIGLIA L’USO D’OLIO: EMPFIEHLT DEN GEBRAUCH VON ÖL: JUNIO / JUNE / JUIN / GIUGNO / JUNI 2006 C/ UNICEF nº 17 · Poligon Industrial Torremirona · 17190 Salt (Girona) SPAIN · Tel: +34 902 47 62 54 Fax: +34 902 47 61 60 E-mail: officegg @ gasgasmotos.es / partsgg @ gasgasmotos.es...
