- Page 1 MANUAL DEL USUARIO USER MANUAL MANUEL D’ENTRETIEN LIBRETTO D´USO BETRIEBSANLEITUNG...
- Page 3 USER MANUAL USERMANUAL...
-
Page 5: Acknowledgements To The Purchaser
GAS GAS thank you for the trust you have placed in us. By choosing a new GAS GAS TXT Boy 2006 you have become part of the great GAS GAS family and, as a user of the number one manufacturer of off-road motorbikes, you deserve to receive the best treatment we can offer you both in our post-sales relations and in the explanations we offer in this manual. -
Page 6: Important Warning
However, GAS GAS Motos, S.A. reserves the right to make modifications without any prior warning to consumers and without incurring any additional obligations in so doing. Your local dealer will... -
Page 7: Table Of Contents
Contens Carburettor Acknowledgements to the purchaser - Adjusting throttle cable Important warning - Adjusting idle speed Quick Guide to Maitenance Spark plugs - Inspecting Fuel-Petrol/oil mixture Air Filter - Cleaning Fuel tank Front brake fluid - Checking Fuel tap Rear brake fluid - Checking Gear shift Clutch lever - Adjusting Before starting the engine... -
Page 8: Quick Guide To Maitenance
Quick Guide to Maintenance Coolant liquid Coolant liquid -30ºC Crankcase oil (10w40) 500 cc. Spark plug CHAMPION RN11YCC / NGK BPR5ES. Electrode separation 0.6 mm. Forks suspension oil SAE 5 (Summer) SAE 2.5 (Winter) Fork suspension oil quantity 200 cm Shock absorber spring length 96 mm Front wheel pressure Standard 0.400 bar... -
Page 9: Fuel-Petrol/Oil Mixture
Fuel – Petrol/oil mixture The motorcycle is fitted with a two-stroke internal combustion engine. This type of engine requires a mixture of petrol and oil. To ensure the correct working of the engine, the following are recommended: - Use high quality petrol, with an octane rating equal to or above 90 (RON + MON)/2 or 98 (RON). -
Page 10: Fuel Tap
Gear shift The motorcycle has a two- speed gearbox, which may be selected manually when the motorcycle is stationary, by moving the lever A in a horizontal direction, as shown by the arrow. Note: Select the gear according to the characteristics of the track. -
Page 11: Before Starting The Engine
Before starting the engine Warning: Before starting the engine, check that the gear lever is in neutral (see instructions in the section Gear lever , page 10) - Open the fuel tap. Note: - If the engine is cold, move choke A upwards, as shown by the arrow, until it clicks into place (vertical). -
Page 12: Stopping The Engine
Riding your motorcycle - Select the gear according to the characteristics of the track. - To change gear, the motorcycle should be stationary. Stopping the engine - With the throttle lever in rest Stopping the motorcycle position (engine idling), move the - Release the throttle lever. -
Page 13: Running-In Period
Running-in period Care of the engine during the first Transmission oil – hours of use is vital for obtaining Checking the level the best from your motorcycle. If the motorcycle has been Therefore, we recommend: used recently, wait a few minutes before - Strictly observe the oil and petrol ratios checking the level. -
Page 14: Topping Up
Tr a n s m i s s i o n o i l – C h a n g i n g - Start the engine and keep it running until it warms up, then stop the engine. - Drain off the used oil. To do so, remove the drain plug A located on the lower part of the engine (visible through the opening of the oil sump casing). -
Page 15: Clutch System- Checking
C l u t c h s y s t e m - C h e c k i n g The clutch system is hydraulic. Regularly check the level of fluid through the transparent window A on the tank. - Position the lever so that the tank cover is horizontal. -
Page 16: Coolant System - Checking/Topping Up
Coolant system – Checking/topping up To reach the radiator cap, proceed as follows: - Undo the bolts shown by the arrow and remove the fuel tank cover and the rear seat unit. - Carefully lift and remove the fuel tank. Warning: If the motorcycle has just been used, wait a few minutes before opening the radiator cap. -
Page 17: Carburettor - Adjusting Throttle Cable
Carburettor - Adjusting throttle cable The throttle lever cable should have a free play of between 2 to 3 mm. If necessary, adjust as described. - Raise the dust guard A on the throttle lever cable. - Turning the threaded terminal B to the right increases the play of the cable, and turning it to the left reduces the play. -
Page 18: Spark Plugs - Inspecting
S p a r k p l u g s - I n s p e c t i n g The electrode separation is from 0.6 to 0.7 mm. Air Filter - Cleaning A clean air filter not only improves engine performance but also prolongs its useful life. -
Page 19: Front Brake Fluid - Checking
Front brake fluid - Checking The level is correct if it falls within the upper half of the transparent window A. If not, top up with a recommended brake fluid. R e a r b r a k e f l u i d - C h e c k i n g The level is correct if it falls within the min and max marks on the tank. -
Page 20: Clutch Lever - Adjusting
Clutch lever - Adjusting The clutch lever should have a maximum play of 3 mm. To adjust, proceed as follows: - Adjust the maximum turn of the lever using bolt A, to suit the driver. - Adjust the play of the lever using bolt B. Warning: Maintain the clutch lever with the play shown, otherwise the performance and useful life of... -
Page 21: Rear Wheel - Centre Alignment
Rear wheel – Centre alignment The rear axle has easily graduated eccentrics for this operation. To ensure perfect wheel alignment, make sure that the marks of both eccentrics are in the same position on both sides. Master link - Checking The master link of the chain has an elastic locking clip. -
Page 22: Tyre Pressures - Checking
Tyre pressures - Check Check tyre pressures order to obtain the holding possible. Front tyre pressure: 0.450 bar - standard 0.420 bar - competition Rear tyre pressure: 0.350 bar - standard 0.300 bar - competition Brake pads - Checking The brake pads, both front and rear, should be checked for wear periodically, in order to enable you to brake effectively... -
Page 23: Brake Circuit - Bleeding
Brake circuit - Bleeding If the system has been dismounted for repair, or if faults are detected in the brake system, the air in the hydraulic circuit can be removed the bleeders A. Once the air has been removed from the system, replace the rubber cap on the bleeder to prevent dirt from entering the system. -
Page 24: Lubrication
Lubrication Clean and lubricate frequently with oil: - The joints of the clutch and front brake levers. Lubrication Clean and lubricate frequently with oil: - The joint and spring of the foot pegs. - Page 25 Lubrication Clean and lubricate frequently with oil: - The secondary chain. Lubrication Clean and lubricate frequently with oil: - The joint of the kick-start pedal.
-
Page 26: Identification
Lubrication Identification The serial number of the Clean and lubricate frequently with oil: motorcycle is engraved on the steering stem. - The axle of the secondary chain tensor. This number should match that which appears in the accompanying documents. Lubrication Clean and lubricate frequently with oil: - The throttle lever, especially after washing... -
Page 27: Warranty Terms And Conditions
Warranty terms of the manufacturer GAS GAS Motos, S.A. The company GAS GAS MOTOS, S.A. (hereafter referred to as “GG”), with this present document guarantees the consumer, the purchaser of a vehicle manufactured by GG, that both the materials and the manufacturing are free of defects in accordance with the highest standards of quality. - Page 28 Obligation of the purchaser GG will have the right to reject any claims under Warranty in the event that: a) the purchaser has failed to submit the vehicle to any of the inspections and/or maintenance work required in the Users’ Manual, or has exceeded the date set for such inspections or maintenance work.
- Page 29 consequence of the defects (for example, communication costs, accommodation expenses, car hire costs, public transport costs, breakdown truck fees,, courier costs, etc.), as well as other financial losses (for example, those caused by the loss of the use of the vehicle, loss of income, time lost, etc.) f) any acoustic or aesthetic phenomenon that does not significantly affect the condition or use of the motorcycle (for example, small or hidden imperfections, noise or vibrations that are normal in use, etc.) g) phenomena that are the result of the ageing of the vehicle (for example, discolouring of painted or metallic coated...
- Page 32 RECOMIENDA EL USO DE ACEITE: RECOMMENDS THE USE OF OIL: RECOMMANDE L’USAGE DE L’HUILE: CONSIGLIA L’USO D’OLIO: EMPFIEHLT DEN GEBRAUCH VON ÖL: JUNIO / JUNE / JUIN / GIUGNO / JUNI 2006 C/ UNICEF nº 17 · Poligon Industrial Torremirona · 17190 Salt (Girona) SPAIN · Tel: +34 902 47 62 54 Fax: +34 902 47 61 60 E-mail: officegg @ gasgasmotos.es / partsgg @ gasgasmotos.es...
