- Page 1 INSTALLATION & OPERATION INSTRUCTIONS Guardian Alert Model #35911 v9.3...
- Page 2 PLEASE READ THIS MANUAL COMPLETELY AND SAVE IT FOR REF- ERENCE. Thank you for choosing FreedomAlert ® – the most unique Personal Emergency Response System in the world, and covered by both US and Canadian patents. FreedomAlert is your personal link to Family, Friends, or Emergency Personnel when needed.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Overview of the FreedomAlert .............. Contents of FreedomAlert kit ..............4 Limitation of Liability ................5 Installing the Batteries ................6 Connecting the Base Unit Power Connection ................8 Telephone Connections ..............8 How to Handle VoIP & DSL ............9 Location of Base Unit ..............10 Base Unit Options &... -
Page 4: Contents Of Freedomalert Kit
Contents of the FreedomAlert Kit: The items below are included with your FreedomAlert . Pendant Base Unit Rechargeable Li-Ion Special Pendant Batteries - Pieces Rechargeable AA Batteries - 4 Pieces Belt Clip AC Adapter Wrist / Walker / Wheelchair strap Phone Cord Screwdriver... -
Page 5: Limitation Of Liability
LogicMark LLC as a result of any cause whatsoever, regardless of whether or not such loss, damage, or personal injury was caused by or contributed to by LogicMark’s negligence to any degree or failure to perform... -
Page 6: Installing The Batteries
Pendant for a second. NOTE: These white batteries are very special batteries that are not available at your local store. See Specification on page 28 for more details, or contact LogicMark to purchase replacement batteries. FreedomAlert ®... - Page 7 Place the extra Pendant battery into the front charging area of the Base unit so that it will charge and be ready when its time to swap the batteries around. The LED on the right side will glow red when charg- ing and green when fully charged.
-
Page 8: Connecting The Base Unit
Connecting the Base Unit Power Connection Simply plug in the AC Adapter in to the nearest elec- trical outlet. Plug the other end of the AC power adapter into the Base unit. You need to push the plug into the opening in the Base unit and twist 90’ clockwise to lock in place. -
Page 9: How To Handle Voip & Dsl
FreedomAlert system to the traditional phone line. For more information on using the FreedomAlert product with your VoIP system, visit our website at www.LogicMark.com and view the FAQ under the OUR PRODUCTS tab. How to Handle DSL: If your home has DSL... -
Page 10: Location Of Base Unit
Locating the Base Unit: For best results and longest range, locate the Base unit in an area away from household appliances which could present electrical interference. These include microwave ovens, televisions, electric mixers or blenders, hairdryers, wifi routers or other cordless phones. Do not place on a metal surface. -
Page 11: Programming The Unit
How does the Base unit know when to go to the next number? The base unit will first dial the first number in the “Friends” list. About 20 seconds into the conversation, the Base unit will interrupt the call and announce “This is an emergency call. -
Page 12: Telephone Number Programming Worksheet
Step 1: Write out the numbers you are wanting to program into the system. Below we will refer to Number 1 as the first number, Number 2 as the second number etc. Include area-codes and a 1 or 9 if they are needed for dialing. Step 2: Establish a phone connection with a friend or family member - or with your cell phone. - Page 13 1. Completely fill out this worksheet before starting to program telephone numbers. 2. Call a friend or family member on your telephone. 3. Slide switch to LEARN MODE [voice prompt – Learn Mode] 4. Enter: 1234 [voice prompt – one, two, three, four, programming mode] 5.
-
Page 14: Adding Additional Pendants To The System
Adding Additional Pendants to the System. FreedomAlert comes with one Pendant. If you want to add addtional pendants to your system - follow the directions here. If not, skip this section. The Pendant’s unique ID code should already be learned into the Base unit when it came from the factory. -
Page 15: Operating The Freedomalert
Operating the FreedomAlert: Operating the Pendant. The Pendant is simple in operation - having one main Blue button - and a smaller Gray button on the back. The Blue button on the front is the main button to push for a full second to initiate a call. -
Page 16: Lanyard, Belt Clip Or Wrist-Strap
Lanyard, Belt Clip or Wrist Strap. FreedomAlert comes with 3 accessories for carrying the pendant . You can carry the Pendant using the Lanyard. You can slide the Pendant in the Belt Clip, or you can use the Wrist-strap as a means to carry the Pendant. Note that the Wrist-Strap can also be used as a way to attach the Pendant to a wheel chair. -
Page 17: Battery Check
3 or 4 weeks before needing to be charged - it is then time to replace both the Pendant batteries. Note: This is a very unusual battery not available at most outlets. Order replacement batteries from LogicMark as directed on page 27. -
Page 18: System Check
System Check: The button on the bottom of the pendant case which is used to perform the BATTERY CHECK, will also perform a SYSTEM CHECK. Press and hold this button for more than four (4) seconds. One of the following announce- ments will be made. -
Page 19: Emergency Dialing Using The Panic Button
We highly recommend that you perform this System Check at least twice a month to confirm that your system is working properly and that the pendant and base unit are in good communication and that the base unit can get a dial tone. It is also recommended to perform this system check after a lightening storm that could damage the base unit which is plugged into the phone line. -
Page 20: Water Resistance
Water Resistance: FreedomAlert will resist occasional splashes from water - i.e as in the shower. However, it should never be submerged or exposed to water continuously. Periodic Testing / Maintenance It is highly recommended that you preform a full System Check (see page 18) at least twice a month. -
Page 21: Troubleshooting Guide
TROUBLESHOOTING GUIDE What if I can’t get the FreedomAlert to work? Step 1 – Push the gray RESET button with a pen at the back of the base unit (next to the power cord). Check the system. If it is now working skip the remaining steps. - Page 22 a wireless radio link. They must be synchronized to work together. They should have already been synchronized at the factory, but resetting this is simple. What to do: Push the red Code Learn button at the back of the Base unit for a second. You will hear “Syncronizing Mode”.
-
Page 23: General Warnings And Precautions
Base unit or the Pendant will void the warranty and may damage the unit or prevent it from working properly. 6. Do not use any power source other than that supplied from LogicMark, LLC specifically for this product. Use of any other power source could damage your unit or make it unsafe. -
Page 24: Warranty
FreedomAlert equipment. The equipment is designed to communicate with the contact list of your choice as well as emergency 911 operators and LogicMark LLC is not and shall not be responsible for ambulance, police or other emergency response time or that any response will be provided by the anyone on your contact list including the emergency 911 response center. - Page 25 LogicMark LLC’s negligence to any degree or failure to perform any obligation or strict products liability, such liability will be limited to an amount paid by the Purchaser to LogicMark LLC for the product, or to the sum of $300.00, whichever is greater.
- Page 26 OUT OF WARRANTY REPAIRS If the warranty period has expired or if you are not the original owner of the product, LogicMark, LLC will at its option either (1) replace this product with a functionally similar (but not necessarily identical) refurbished product or (2) repair the original product and return it to the original consumer/purchaser after payment of repair/replacement charges has been received.
- Page 27 Replacement Parts / Optional Accessories: Rechargable Li-Ion Special Pendant Batteries Pieces Part #35917 $15.00 Rechargable AA Batteries 4 Pieces Part #35918 $15.00 Lock Box Extra Pendants Part #30913 $34.95 Part #35915 $119.95 All prices include shipping and handling to the 50 United States. Add an additional $7.00 for Canadian shipments.
-
Page 28: Product Specifications
Number of Pendants/Base Unit 16 Pendants can be programmed to one Base unit. Pendant Batteries 3.6 (or 3.7) volt 500 mAh Li-Ion size 10440. (2 pieces) Should be replaced very 2 years Purchase replacements from LogicMark Operating Temperature 32˚ to 120˚ F. (0˚ to 49˚ C). 8625 Hampton Way;...
