3Com SuperStack II Switch 1100 ATM Quick Installation Manual page 3

Step 3:
Use the slotted screws attached to the ATM
Expansion Module to fix the module firmly into place
as shown in Figure 3.
Figure 3 Securing the ATM Expansion Module
Step 4:
Connect the Switch with the installed ATM Expansion
Module, see Figure 4, to the ATM network.
Figure 4 The Installed ATM Expansion Module
For more information on installation, please
refer to Chapter 7 of the ATM Expanion Module
User Guide.
3
