14. Parts list

Item # Part #
1 EKK1D CASE ASSEMBLY
2 EKK1J FRONT COVER
3 EKJ62 AIR BLOCKAGE PLATE
4 EKJ09 BRACKET
5 EKJ64 JUNCTION BOX
50 EW000 SCREW M4X12
51 EW001 SCREW W/W ASHER M4X10
52 EW002 COATING SCREW M4X10
53 EW003 SCREW M4X10
54 EC00X NYLONE CLAMP
101 EKK1N BURNER ASSEMBLY
102 EKK1Y COMBUSTION CHAMBER
103 EKK1F MANIFOLD
104 EKK25 FAN MOTOR
105 EKK1W GAS VALVE ASSEMBLY
106 EKK0E FLAME ROD
107 EKK0F IGNITER ROD
108 EKK1E GAS INLET
109 EKK34 BURNER PLATE
110 EKK1P DAMPER
111 EK270 FAN DAMPER
112 EKN61 ROD CAP
113 EKK2Z GAS INLET RING
114 EKK2V BURNER WINDOW
115 EKK2W ROD HOLDER GASKET
116 EKK32 ROD HOLDER
117 EKK0G BURNER HOLDER GASKET
118 EKK2D PRESSURE PORT
119 EKK2N URETHAN TUBE
120 EKK2Y MANIFOLD GASKET
121 EKK20 GFI PLATE
122 EKK1B IGNITER PLATE
123 EM167 WIRE CLAMP 60
150 EW003 SCREW M4X10
151 EW002 COATING SCREW M4X10
152 EKK37 SCREW M4X12
153 EW004 HEX HEAD SCREW M4X12
154 EW005 HEX HEAD SCREW M4X8
155 EW006 SCREW M4X10
156 EW00B SCREW M3X8
157 EW008 SCREW M3X10
401 EKK1X HEAT EXCHANGER ASSEMBLY
FLOW
402 EKK0T
W/FLOW SENSOR
403 EKK0U BYPASS VALVE
404 EKK1U WATER INLET
405 EKK1V WATER OUTLET
Description
ADJUSTMENT VALVE
68
Common parts for other units
TKJr
TKJr
TKJr
TKJr, OS, SP, TH1
TK2, TKD20, TK1S, OS, SP, TM1, TM199, TH1
TK2, TKD20, TK1S, OS, SP, TM1, TM199, TH1
TK2, TKD20, TKJr , TK1S, OS, SP, TM1, TM199, TH1
TH1
SP
SP
SP
OS, SP
OS, SP
OS, SP
SP
TKJr, TK1S, OS, SP, TH1
OS, SP
OS, SP
OS, SP
OS, SP
OS, SP
SP
SP
OS, SP
TK2, TKD20, TKJr , TK1S, OS, SP, TM1, TM199, TH1
TK2, TKD20, TKJr , TK1S, OS, SP, TM1, TM199, T-H1
TK2, TKD20, TKJr , TK1S, OS, SP, TM1, TM199, T-H1
OS, SP
TK2, TKD20, SP, TH1
TK2, TKD20, OS, SP, TH1
TK2, TKD20, OS, SP, TH1
SP
TK2, TKJr , TK1S, OS, SP, TM1, TM199
OS, SP
OS, SP
CONFIDENTIAL
T-K3 Servi c e Manual
Ver. 1.05
