Alarm SAF BNx000 Operating And Installation Instruction Manual

Beacon power supply
Hide thumbs Also See for BNx000:
Table of Contents

Advertisement

Quick Links

Beacon Power Management System Installation Manual
Model Numbers:
BN4-003-APD8F-UL
BN4-003-APD8-UL
BN4-004-APD8F-UL
BN4-004-APD8-UL
BN6-003-APD8F-UL
BN6-003-APD8-UL
BN6-004-APD8F-UL
BN6-004-APD8-UL
*May also be used for any Beacon Power Management System that includes any combination of the following boards:
Model Numbers:
APD8F-BD
APD8-BD
BN4-000-UL
BN6-000-UL
BN8-000-UL
BN10-000-UL
This Installation manual is made up of the following separate Installation Instructions for the Power Supply
and Advanced Power Distribution Module.
52-296 - Installation Instructions for Beacon Power Supply - pp. 2-28
52-325 - Installation Instructions for Beacon Power Supply - Addendum A - p. 29
52-254 - Installation Instructions for APD Module - pp. 30-53
AlarmSaf
65A Industrial Way, Wilmington, MA 01887-3499, USA, Toll Free: 800-987-1050, Voice: 978-658-6717, Fax: 978-658-8638, www.alarmsaf.com
Order Numbers:
10009
10007
10010
10008
10021
10019
10022
10020
Order Numbers:
02828
02827
10001
10013
10025
10034
Model Numbers:
BN8-003-APD8F-UL
BN8-003-APD8-UL
BN8-004-APD16F-UL
BN8-004-APD16-UL
BN10-003-APD8F-UL
BN10-003-APD8-UL
BN10-004-APD16F-UL
BN10-004-APD16-UL
Model Numbers:
BN4-004-APD16-UL
BN10-004-APD16-UL
BN64-013-APD16-UL
BN64-0013-APD16F-UL
Order Numbers:
10031
10030
10029
10028
10040
10039
10038
10037
Order Numbers:
10058
10061
10077
10078

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BNx000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alarm SAF BNx000

Summary of Contents for Alarm SAF BNx000

  • Page 1 Beacon Power Management System Installation Manual Model Numbers: Order Numbers: Model Numbers: Order Numbers: BN4-003-APD8F-UL 10009 BN8-003-APD8F-UL 10031 BN4-003-APD8-UL 10007 BN8-003-APD8-UL 10030 BN4-004-APD8F-UL 10010 BN8-004-APD16F-UL 10029 BN4-004-APD8-UL 10008 BN8-004-APD16-UL 10028 BN6-003-APD8F-UL 10021 BN10-003-APD8F-UL 10040 BN6-003-APD8-UL 10019 BN10-003-APD8-UL 10039 BN6-004-APD8F-UL 10022 BN10-004-APD16F-UL 10038 BN6-004-APD8-UL...
  • Page 2 Beacon Power Supply Installation Instructions 2.8.2012 Beacon Power Supply Operating and Installation Instruction Manual Model: BNx000 52-296 Rev B05 Page 1 of 27 AlarmSaf 65A Industrial Way, Wilmington, MA 01887 978 658 6717 www.alarmsaf.com...
  • Page 3 Beacon Power Supply Installation Instructions 2.8.2012 I. Warnings and Notices WARNING - To reduce the risk of fire or electric shock, do not expose this product to rain or moisture. WARNING – Risk of electric shock. Installation and service should be made by qualified service personnel and should conform to all local codes.

  • Page 4: Table Of Contents

    1 Introduction 2 Applicable Standards / Documents 3 System Overview 6-13 3.1 Electrical Ratings and Specifications 3.2 BNx000 Connector Descriptions and Electrical Ratings 3.2.1 Terminal and Connector Illustration 3.3 AC Input Connection 9 - 10 3.4 Accessory Board Connectors (ABC) 3.5 ABC Buss Voltage Selection...

  • Page 5: Introduction

    Section 1 Introduction The Beacon Line of power supplies (BNx000) is an of off-line switching power supply product line designed for use in the access control and fire industries by the Systems Integrator. They accept several accessory boards designed to increase the functionality of the basic power supply.

  • Page 6: Applicable Standards / Documents

    Beacon Power Supply Installation Instructions 2.8.2012 Section 2 Applicable Standards / Documents NFPA Standards NFPA 72 National Fire Alarm Code NFPA 70 National Electrical Code NFPA 731 Standard for the Installation of Electronic Premises Security Systems US Standards UL 294 Access Control System Units UL 1481 Power Supplies for Fire Protective Signaling System Other Standards MEA Listed...

  • Page 7: System Overview

    Beacon Power Supply Installation Instructions 2.8.2012 Section 3 System Overview 3.1 Electrical Ratings and Specifications Manufactured By AlarmSaf 65A Industrial Way Wilmington, MA 01887 Tel: 978.658.6717; 800.987.1050 www.alarmsaf.com Model Numbers (Board Only) BN4000, BN6000, BN8000, BN10000 Full product list available at www.alarmsaf.com Electrical Ratings Input Voltage All Models: 102-138VAC (120VAC Nominal) or 240VAC nominal (with proper...

  • Page 8: Bnx000 Connector Descriptions And Electrical Ratings

    Beacon Power Supply Installation Instructions 2.8.2012 3.2 BNx000 Connector Descriptions and Electrical Ratings Terminal / Description Rating Connector 102-138VAC (120VAC Nominal) or 5-Pin AC Line connector 240VAC Nominal with appropriate jumper AC PWR CONNECT setting (see page 18) 12 or 24VDC @ 14A Maximum or to...

  • Page 9: Terminal And Connector Illustration

    Beacon Power Supply Installation Instructions 2.8.2012 3.2.1 BNx000 Terminal and Connector Illustration 52-296 Rev B05 Page 8 of 27 AlarmSaf 65A Industrial Way, Wilmington, MA 01887 978 658 6717 www.alarmsaf.com...

  • Page 10: Ac Input Connection

     Locate the VAC SELECT jumper (J5)  Verify that J5 is in the UP position for 120 VAC input The BNx000 will also operate with a 240 VAC (195-264VAC at 50 or 60Hz) input. For 240 VAC input:  Reposition the VAC SELECT jumper (J5) in the DOWN position or remove it before energizing the power supply.

  • Page 11: General Information

    CAUTION: The ABC-01 and ABC-02 cables are used on older BNx000 boards (PCB#: 38-118 REV A02 or earlier) that have a 6-pin ABC connector. DO NOT USE these cables on newer BNx000 boards (PCB # 38-118 REV A03A or later) that have an 8-pin ABC connector or damage to the system could occur.

  • Page 12: Abc Buss Voltage Selection

    Because older BNx000 boards (PCB#: 38-118 REV A02 or earlier) do not have a Buss Select Fuse, always check the position of this fuse setting when installing a new BNx000 Board (PCB # 38-118 REV A03A or later) into an existing system.

  • Page 13: Fai Input Terminals

    Beacon Power Supply Installation Instructions 2.8.2012 3.7 FAI Input Terminals The FAI input connection for the BNx000 is made through TB3. The FAI input allows complete flexibility in connection options:  Normally Open Contact (switching positive voltage)  Normally Open Contact (switching DC common) ...

  • Page 14: Fault Reporting Terminals

    Beacon Power Supply Installation Instructions 2.8.2012 3.8 Fault Reporting Terminals The Fault Reporting relay connection is made through TB4. Separate Form C relays are provided for AC Faults and System Faults. Connections are marked on the PCB. Six Fault terminals are available: 1.

  • Page 15: Installation

    2.8.2012 Section 4 Installation 4.1 Mounting The BNx000 is for wall mounting only, using #8 hardware minimum in four locations. Use an appropriate fastening system for the mounting surface. CAUTION: Remove all power from the system before installation Cabinet Mounting: 1.

  • Page 16: Wiring

     For 12VDC connect one battery to the terminals  For 24VDC connect two batteries in series to the terminals Note: Connecting batteries in parallel does not allow the BNx000 to supervise the entire battery set for presence. CAUTION: A lead-acid battery has the capability of producing extremely high current.
  • Page 17 Beacon Power Supply Installation Instructions 2.8.2012 4.2 Wiring (continued) 4.2.6 FAI Wiring Locate the FAI Input terminal block (TB3) and remove the terminal block from the header. Connect the wiring for the FAI input to the terminal block. The PC board is labeled with the connections and polarity (See also section 3.2).

  • Page 18: Operating The Bnx000

    Operating the BNx000 5.1 Output Voltage Selection Before powering a system containing a BNx000, the output voltage switch (S1 - Voltage Select) must be set for the proper output voltage or damage to the system could occur. Do not change the switch setting while the unit is powered or damage to the system may occur.

  • Page 19: Visual Indicators

    5.2.4 J5 (VAC SELECT) This jumper selects the AC input voltage to be used to power the BNx000. The power supply is factory set for 120 VAC input (J5 in the UP position). Move the jumper to the DOWN position or remove it to operate the power supply with 240 VAC input.
  • Page 20  Missing battery (If Battery Presence is enabled) 5.3.4 REV BAT (D27) This LED lights when a battery set is connected to the BNx000 in a reverse polarity. This LED will be accompanied by the SYS TBL LED and a blown battery fuse (F4 - BAT) 5.3.5 DC1 (D13)

  • Page 21: Troubleshooting

    BNx000 is incorrect Verify that a good battery set of the proper Bad / Incorrect Battery Set voltage is connected to the BNx000 Blown output or battery fuse Verify all fuses are intact - Check wiring (F2, F3, or F4))

  • Page 22: Specifications

    Beacon Power Supply Installation Instructions 2.8.2012 Section 6 Specifications 6.1 Electrical Specifications 6.1.1 Input Voltage 102-138VAC (120VAC Nominal) or 195.5-264.5 (240VAC Nominal) @ 50-60Hz 6.1.2 Input Power Model dependent - See Sec. 3.1 6.1.3 Output Voltage 12 or 24VDC Nominal 6.1.4 Output Current Model dependent - See Sec.
  • Page 23 FAI Input Connection Methods 2.8.2012 APPENDIX A, PAGE 1 FAI Input Connection Methods The Beacon FAI input is the most flexible we have yet seen in the industry. It may be activated by any common means found in the access and fire industry. When activated, this input will disable the Beacon DC2 output and enable the DC3 output.

  • Page 24: Appendix A - Fai Input

    FAI Input Connection Methods 2.8.2012 APPENDIX A, PAGE 2 FAI Input Connection Methods (continued) "Open collector" connection EXTERNAL POWER - EXTERNAL POWER - OPEN OPEN COLLECTOR INPUT INPUT COLLECTOR EXTERNAL POWER + Internal source External source NAC connection FROM NAC LOOP FROM NAC LOOP NOT E FAI JUMPER LOCAT ION...

  • Page 25: Appendix B - About The Accessory Board Connector

    ABC Buss General Information 2.8.2012 APPENDIX B, PAGE 1 About the Accessory Board Connector The AlarmSaf Accessory Board Connector (ABC) allows plug-in system expansion using compatible AlarmSaf accessory boards. The ABC is capable of carrying both primary and secondary voltages (if applicable), DC common, fault status, and fire alarm interface status. Products can be daisy-chained together, maintaining voltage, fault, FAI, and DC common continuity throughout the chain.
  • Page 26 ABC Buss General Information 2.8.2012 APPENDIX B, PAGE 2 About the Accessory Board Connector (continued) Voltage Busses (B1 and B2) The voltage busses (B1 and B2) are carried on pins 5-8 of the ABC. B1 is the primary voltage, and should typically be the higher of the two voltages in a dual voltage system. The B1 and B2 (if used) voltages are distributed through the accessory boards connected to the ABC.
  • Page 27 ABC Buss General Information 2.8.2012 APPENDIX B, PAGE 3 About the Accessory Board Connector (continued) Fire Alarm Interface (FAI) Status Buss The FAI status buss carries FAI activation signals on systems utilizing a Fire Alarm Interface. This buss is used to control outputs on compatible accessory boards. See the documentation for the accessory boards in the system to determine FAI capability.

  • Page 28: Glossary

    Glossary 2.8.2012 Glossary See “Accessory Board Connector” Accessory Board Connector Connector present on some AlarmSaf power supplies and accessory boards, allowing plug-in expansion of the system Accessory Board An AlarmSaf product for use with AlarmSaf power supplies containing an ABC connector. These boards allow plug-in expansion of the functionality of the system.
  • Page 29 Beacon Power Supply Installation Instructions - Addendum A Compatible Fire Device List The following Fire devices have been determined to be compatible with the AlarmSaf Beacon Line of power supplies. Access Control devices used must be verified for a compatible voltage range. Nominal Voltage Voltage Range Manufacturer...

  • Page 30: Rev B

    +IN 1- +IN 2- +IN 3- +IN 4- SET S1 THRU S8 +IN 5- +IN 6- +IN 7- +IN 8- FOR EITHER POSITIVE, NEGATIVE, OR ISOLATED TRIP +IN 1- +IN 2- +IN 3- +IN 4- +IN 5- +IN 6- +IN 7- +IN 8- C D X C D X C D X...

  • Page 31: Symbol Definitions

    APD8(F) Installation Instructions 10/9/2007, 12:19:29 PM I. Warnings and Notices WARNING - To reduce the risk of fire or electric shock, do not expose this product to rain or moisture WARNING - This installation and all servicing should be made by qualified service personnel and should conform to all local codes NOTICE - This equipment shall be installed in a manner which prevents unintentional operation from employees or other personnel working about the...
  • Page 32 APD8(F) Installation Instructions 10/9/2007, 12:19:29 PM Table of Contents Section Page I. Warnings and Notices 1 Introduction 2 Applicable Standards / Documents 3 System Overview 3.1 Electrical Ratings and Specifications 3.2 Connector Descriptions and Electrical Ratings 3.3 Control Power and Lock Power Input Connections 3.4 Zone Inputs 3.5 Zone Outputs 3.6 FACP Input...

  • Page 33: Introduction

    APD8(F) Installation Instructions 10/9/2007, 12:19:29 PM Section 1 Introduction The APD8(F) is an access control power distribution system providing eight relay controlled, individually protected outputs. The ADP8 provides Class-2 power limited outputs via PTC protection, while the APD8F uses fuse protected outputs. Either system can be operated from 12V or 24V AC or DC and features independently programmable outputs, a variety of input option modes, Fire Alarm Interface and visual status indication.

  • Page 34: Applicable Standards / Documents

    APD8(F) Installation Instructions 10/9/2007, 12:19:29 PM Section 2 Applicable Standards / Documents NFPA Standards NFPA 72 National Fire Alarm Code NFPA 70 National Electrical Code NFPA 731 Standard for the Installation of Electronic Premises Security Systems US Standards UL 294 Access Control System Units Canadian Standards CAN/CSA-C22.2 No.

  • Page 35: System Overview

    APD8(F) Installation Instructions 10/9/2007, 12:19:29 PM Section 3 System Overview 3.1 Electrical Ratings and Specifications Manufactured By AlarmSaf Tel: 800 987 1050 65A Industrial Way Tel: 978 658 6717 Wilmington, MA 01887 Fax: 978 658 8638 www.alarmsaf.com Model Numbers (Board-Level) APD8, APD8F Electrical Ratings Input Voltage...
  • Page 36 APD8(F) Installation Instructions 10/9/2007, 12:19:29 PM 3.2 APD8(F) Connector Descriptions and Electrical Ratings Terminal / Connector Description Rating TB7 - Power Inputs and FACP AUX Output CTRL+ Control Power Positive Input 10V-30V AC or DC - 0.4A at 12VDC, 0.2A at 24VDC Maximum CTRL- Control Power Common Input LOCK+...

  • Page 37: Control Power And Lock Power Input Connections

    APD8(F) Installation Instructions 10/9/2007, 12:19:29 PM 3.3 Control Power and Lock Power Input Connections The APD8(F) has two separate power inputs - a control power input, and a lock power input. Using two separate power inputs allows total separation of lock and control power sources. Typically, this is not required, and jumpers J1 and J2 should remain in.

  • Page 38: Zone Inputs

    APD8(F) Installation Instructions 10/9/2007, 12:19:29 PM 3.4 Zone Inputs Each Zone Output has a corresponding Zone Input. Each Zone Input provides on/off control for its associated output. Inputs are programmable for a variety of input types, including: Normally Open Dry Contact - Positive Switching Normally Closed Dry Contact - Positive Switching Normally Open Dry Contact - Negative Switching Normally Closed Dry Contact - Negative Switching...

  • Page 39: Facp Input

    APD8(F) Installation Instructions 10/9/2007, 12:19:29 PM 3.6 FACP Input The APD8(F) has two FAI inputs, one which accepts a voltage input, and one that accepts a dry contact input. Consult the appropriate section below for Terminal Connections for the type of connection being used.

  • Page 40: Fusing

    APD8(F) Installation Instructions 10/9/2007, 12:19:29 PM 3.8 Fusing The APD8F contains eight replacable fuses - one for each output zone. When replacing these fuses, only the equivalent type and rating are to be used. The APD8F utilizes commonly available automotive blade-type fuses (Type ATC). All fuses are rated at 3A (ATC-3). Only the APD8F contains fuses.

  • Page 41: Installation

    APD8(F) Installation Instructions 10/9/2007, 12:19:29 PM Section 4 Installation 4.1 Mounting The APD8(F) line is available in either board-level or cabinet level versions. NOTE - For UL compliance, if the APD8(F) is mounted in an unprotected area, a Tamper Switch must be used.

  • Page 42: Wiring

    APD8(F) Installation Instructions 10/9/2007, 12:19:29 PM 4.2 Wiring 4.2.1 Wire Routing All wiring must be installed in accordance with NFPA70, NFPA72, and all local code requirements. Power Limited wiring requires that power limited and non-power limited wiring remain physically separated. Any power limited circuit entering the enclosure must remain at least one quarter inch (¼”) away from any non-power limited circuit wiring.

  • Page 43: Operating The Apd8(F)

    APD8(F) Installation Instructions 10/9/2007, 12:19:29 PM Section 5 Operating the APD8(F) 5.1 Power Separation Jumper Settings The APD8(F) gives the installer the ability to electrically isolate the Control power from the Zone Output power. This can be helpful in installations where noise-sensitive devices would be affected by lock noise.

  • Page 44: Output Configuration Jumper Settings

    APD8(F) Installation Instructions 10/9/2007, 12:19:29 PM INPUT ZONE CONFIGURATION SWITCH Switch # Neg. Trip Pos. Trip Ext. Trip +IN 1- 1 (N) ON (Closed) OFF (Open) OFF (Open) 2 (NI) ON (Closed) OFF (Open) ON (Closed) 3 (N) ON (Closed) OFF (Open) OFF (Open) 4 (P)

  • Page 45: Troubleshooting

    APD8(F) Installation Instructions 10/9/2007, 12:19:29 PM 5.5 Troubleshooting Condition Possible Cause Solution J1 and J2 set incorrectly See Section 5.1 Verify power is present on the power input terminals. If J1 and J2 are No power input removed, BOTH power inputs must be powered.

  • Page 46: Specifications

    APD8(F) Installation Instructions 10/9/2007, 12:19:29 PM Section 6 Specifications 6.1 Electrical Specifications 6.1.1 Input Voltage 10-30V AC or DC 6.1.2 Input Power 0.4A@12VDC / 0.2A@24VDC maximum control current + 8A maximum output current 6.1.3 Output Voltage Dependent on Input Voltage 6.1.4 Total Output Current 8A Maximum 6.1.5 Zone Output Current...

  • Page 47: Configuring The Zone Inputs For Any Application

    APD8(F) Installation Instructions 10/9/2007, 12:19:29 PM Appendix A Configuring The Zone Inputs For Any Application Each zone of the APD8(F) has a set of DIP switches associated with its input. These switches configure the input for use with a variety of signal types, including: Normally Open Dry Contact - Positive Switching Normally Closed Dry Contact - Positive Switching Normally Open Dry Contact - Negative Switching...
  • Page 48 APD8(F) Installation Instructions 10/9/2007, 12:19:29 PM NO Contact NC Contact Open Collector +IN 1- +IN 1- +IN 1- +IN 1- +IN 1- +IN 1- The trip source MUST be common grounded to the APD8(F)’s control power source. Positive Trip Negative Trip Isolated Voltage Trip EXTERNAL EXTERNAL...

  • Page 49: Appendix B Using The Zone Outputs

    APD8(F) Installation Instructions 10/9/2007, 12:19:29 PM Appendix B Using The Zone Outputs The APD8(F)’s outputs can be used in a variety of configurations, allowing flexibility and compatability with virtually any application. Each output can individually be set up for disconnect on FAI, no action on FAI, or Dry Contact Output (no action on FAI) by setting the Zone Output Configuration jumpers for each zone (See Section 5.3).

  • Page 50: Using The Facp Input And Facp Aux Output Terminals

    APD8(F) Installation Instructions 10/9/2007, 12:19:29 PM Appendix C Using The FACP Input and FACP AUX Output Terminals The APD8(F) has two FACP inputs which can be used to drop power to selected outputs when activated. One of the FACP inputs is for connection to a voltage source trip, while the other is for connection to a NO contact trip or open collector trip.

  • Page 51: Appendix D Sample Applications

    APD8(F) Installation Instructions 10/9/2007, 12:19:29 PM Appendix D Sample Applications Using a Beacon Power Supply’s FAI Input to activate the APD8(F)’s FACP Input Beacon To provide greater flexibility of options for FAI trip options, the APD8(F) can be slaved NO Contact AC Power to a Beacon Power Supply’s FAI action.
  • Page 52 APD8(F) Installation Instructions 10/9/2007, 12:19:29 PM Using an output as a constant power source Egress PIR Keypad Zone 2 is connected to release a doorstrike when an egress PIR sees a valid target. Power + Power + Power - Power - Zone 1 provides constant power to the egress PIR through the ‘C’...
  • Page 53 APD8(F) Installation Instructions 10/9/2007, 12:19:29 PM “Daisy-Chaining” FACP Inputs Between Multiple APD8(F) boards APD8(F) CTRL+ CTRL- LOCK+ LOCK- FACP Activating the FACP input of the top APD8(F) transfers its FACP AUX output. OUT1 OUT2 OUT3 OUT4 OUT5 OUT6 OUT7 OUT8 These contacts then activate the FACP dry FACP contact input of the bottom APD8(F).
